Allen Bradley PLC 1756-IA16 / 1756IA16

China Allen Bradley PLC 1756-IA16 / 1756IA16 supplier
Allen Bradley PLC 1756-IA16 / 1756IA16 supplier Allen Bradley PLC 1756-IA16 / 1756IA16 supplier Allen Bradley PLC 1756-IA16 / 1756IA16 supplier Allen Bradley PLC 1756-IA16 / 1756IA16 supplier Allen Bradley PLC 1756-IA16 / 1756IA16 supplier

Large Image :  Allen Bradley PLC 1756-IA16 / 1756IA16

Product Details:

Place of Origin: Made in USA
Brand Name: Rockwell
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1756-IA16 / 1756IA16

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $252.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 5 PCS
Detailed Product Description


1756-IA16 technical data PDF download 1756-IA16 ControlLogix 16 Point 120V AC Input Module | Rockwell

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC Automation

The 1756-IA16 (also written 1756IA16) is the 16-point 120 V AC input module: 120 V AC at 50/60 Hz, 13 mA per point, backplane 100 mA at 5.1 V DC and 2 mA at 24 V DC, isolation 250 V continuous basic inputs to backplane, 125 V basic group to group, and no isolation between individual inputs within a group (1756-IN064).

Two groups of eight is the wiring model. Each group can be fed from a different 120 V source — two control transformers, two phases, or a machine section with its own isolator — and the 125 V group-to-group barrier keeps them apart. Within a group the eight points share a common and are not isolated from each other.

The backplane figure is the one that surprises people: sixteen points at the same 100 mA at 5.1 V DC as the 8-point IA8D. Twice the channels for the same chassis load, which is why the IA16 is usually the first AC input card specified once a panel needs more than eight 120 V signals.

At 13 mA per point the input current is lower than the IA8D's 16 mA, and that is the honest trade: slightly less immunity to field leakage, in exchange for double the density and group isolation. The 2 mA at 24 V DC is also half the IA8D's draw.

1756-IB16
16 sinking inputs, 10...31.2 V DC 10 mA, backplane 100 mA, UPC 612598171293
In stock
1756-IB16D
16 diagnostic inputs, 10...30 V DC 13 mA, backplane 150 mA
In stock
1756-IB16I
16 isolated inputs, 10...30 V DC 10 mA, backplane 135 mA
In stock
1756-IB16IF
16 fast peer-control inputs, 10...30 V DC 5 mA, backplane 275 mA
In stock
1756-IB16ISOE
16 sequence-of-events inputs, 10...55 V DC 5.1 mA, backplane 320 mA
In stock
1756-IB32
32 sinking inputs, 10...31.2 V DC 5.5 mA, backplane 120 mA, UPC 612598171309
In stock
1756-IC16
16 inputs, 30...60 V DC, backplane per 1756-IN062
In stock
1756-IG16
16 TTL inputs, backplane per 1756-IN062
In stock
1756-IV16
16 inputs, 48 V DC, backplane per 1756-IN062
In stock

 Application
 Discrete input
 Brand Name
 Rockwell (Rockwell)
 Cat Num
 1756-IA16
 Communication
 Backplane (producer/consumer)
 Display
 —
 Enclosure
 None (open-style)
 Interface
 Removable terminal block
 Mounting
 Chassis slot
 Number Of Channels
 16
 Standard
 CE, UL, CSA, RCM
 Sub Brand
 ControlLogix
 Type
 Digital Input Module
 UNSPSC
 —

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1756-TD003 (module specifications) and 1756-IN062 (DC digital I/O installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1756-IA16 module product photograph 1756-IA16 label product photograph 1756-IA16 terminal side product photograph

Where the module sits in a typical system

The IA16 is the default 120 V AC input card for a machine with sixteen to twenty-four field signals: limit switches, selector switches, pressure and float contacts, and the auxiliary contacts that feed the safety and status logic.

Its group isolation is what makes it usable on a panel with two separate control transformers. Group 0 on one feed and group 1 on another is a wiring arrangement the module explicitly supports; the IA8D cannot do it and the IA16I can, but only at 125 V.

Where each point must stand alone — different returns, different circuits, a mix of 120 V and low-level signals — the isolated IA16I is the correct part, and the extra cost buys the individual barrier plus a higher 15 mA input current.

Commissioning in five steps

  1. Check the module's published input current against the field device's leakage. A 120 V AC input at 13 mA will hold off a two-wire sensor that leaks a few milliamps; a low-current module will not. Input current is an immunity figure, not a burden.
  2. Decide the common arrangement before wiring, because the isolation table is per module and not per family. The IA16 has two groups of eight with 125 V between them, the IA8D has no isolation between its inputs at all, and the IA16I isolates every point — but only at 125 V.
  3. Confirm the nominal voltage against the published window, not against the panel label. The IA32 accepts 74...132 V AC, so it works on a 110 V nominal supply with deep brownout; a 240 V circuit needs the IM16I.
  4. Respect 60 °C as the surrounding-air limit and mount the module in a slot where the chassis airflow is unobstructed; every rating in 1756-IN064 is quoted at that ambient.
  5. Terminate on the 1756-TBNH or 1756-TBSH removable terminal block with 0.33...2.1 mm² (22...14 AWG) wire rated 90 °C or better, and 1.2 mm maximum insulation.

Diagnostics: status indicators

Three bi-colour indicators plus the alphanumeric display cover almost every commissioning fault, so most problems are resolved at the panel without a laptop.

 Indicator State Meaning and first action
 Check 2 250 V to the backplane Double the barrier published on the IA8D and the OA8 — worth having when the field circuit and the chassis reference sit on different legs.
 Check 3 13 mA per point Less leakage immunity than the 16 mA IA8D, and still enough to hold off most two-wire proximity sensors.
 Check 4 Same 100 mA backplane as the IA8D Sixteen points for the same 5.1 V DC draw — the density argument for this module.
 Check 5 T4A temperature code 60 °C maximum surrounding air, as published for the whole 120 V AC input group.

Specifications per Rockwell publication 1756-IN062 (ControlLogix DC Digital I/O Modules installation instructions); module behaviour per 1756-UM058 and technical data 1756-TD002 and 1756-IN050.

Replacing a AC input module of an earlier generation

For 16 individually isolated 120 V AC inputs, use 1756-IA16I at 15 mA per point.

For 32 inputs in one slot with a 74...132 V AC window, use 1756-IA32.

For 240 V AC signals, use 1756-IM16I, which publishes 250 V isolation to the backplane and input-to-input.

Which ControlLogix EtherNet/IP module to specify

  • 1756-IA16 — 16 inputs at 120 V AC, 13 mA per point, two groups of eight with 125 V group-to-group isolation.
  • 1756-IA16I — 16 inputs individually isolated from each other, 120 V AC at 15 mA.
  • 1756-IA32 — 32 inputs in one slot, 74...132 V AC at 15 mA, the widest input window in the family.
  • 1756-IA8D — 8 inputs at 120 V AC with the highest input current, 16 mA per point.
  • 1756-IM16I — 16 isolated inputs at 240 V AC, the only 240 V AC input module published.
  • 1756-IN16 — 16 inputs at 10...30 V AC, 25 mA maximum per point.

FAQ — 1756-IA16 ControlLogix 16 Point 120V AC Input Module | Rockwell

What is the 1756-IA16?

A 16-point 120 V AC input module, 13 mA per point, backplane 100 mA at 5.1 V DC and 2 mA at 24 V DC.

How is it isolated?

250 V continuous basic inputs to backplane and 125 V basic between the two groups, with no isolation between the eight points inside a group.

How many groups does it have?

Two groups of eight, each with its own common, so two separate 120 V AC feeds can be used on one module.

How much current does each input draw?

13 mA at 120 V AC.

Is its backplane current higher than the 8-point module?

No. Both draw 100 mA at 5.1 V DC, so sixteen points cost the same chassis current as eight.

Can it take 240 V AC?

No. It is published at 120 V AC, and the group-to-group barrier is 125 V. Use 1756-IM16I for 240 V.

What is the maximum surrounding air temperature?

60 °C, with a North American temperature code of T4A.

What terminal block does it use?

The 1756-TBNH or 1756-TBSH removable terminal block, 0.33...2.1 mm² (22...14 AWG) wire.

Which document publishes these ratings?

1756-IN064, the ControlLogix AC digital I/O installation instructions.


Data sources. Technical values on this page come from Rockwell publications 1756-TD003 (ControlLogix Communication Modules Specifications), 1756-IN050 (1756 EtherNet/IP Communication Modules, installation instructions), 1756-UM004 (ControlLogix EtherNet/IP Network Devices User Manual) and the manufacturer's product page for 1756-IA16. Values re-checked 15 November 2026.
