1762-L24BXB is a MicroLogix 1200 24 point controller with (10) standard 24V dc and (4) fast 24V dc inputs, (5) relay outputs, (4) standard and (1) fast 24V dc FET outputs, powered from 24V dc, Class 2 SELV.
The 1200 sat between the fixed MicroLogix 1000 and the expandable 1500: a brick controller with a real expansion bus, six modules wide, and 4 KB of program memory. It was the standard answer for a small machine that needed more than a fixed brick but less than a rack.
| 1762-L24AWA | MicroLogix 1200 24 point controller | IN STOCK |
| 1762-L24AWAR | MicroLogix 1200 24 point controller | IN STOCK |
| 1762-L24BWA | MicroLogix 1200 24 point controller | IN STOCK |
| 1762-L24BWAR | MicroLogix 1200 24 point controller | IN STOCK |
| 1762-L24BXB | MicroLogix 1200 24 point controller | IN STOCK |
| 1762-L24BXBR | MicroLogix 1200 24 point controller | IN STOCK |
| 1762-L40AWA | MicroLogix 1200 40 point controller | IN STOCK |
| 1762-L40AWAR | MicroLogix 1200 40 point controller | IN STOCK |
| 1762-L40BWA | MicroLogix 1200 40 point controller | IN STOCK |
| 1762-L40BWAR | MicroLogix 1200 40 point controller | IN STOCK |
| 1762-L40BXB | MicroLogix 1200 40 point controller | IN STOCK |
| 1762-L40BXBR | MicroLogix 1200 40 point controller | IN STOCK |
Catalog number |
1762-L24BXB |
Description |
MicroLogix 1200 24 point controller |
Embedded I/O |
(10) standard 24V dc and (4) fast 24V dc inputs, (5) relay outputs, (4) standard and (1) fast 24V dc FET outputs |
Input power |
24V dc, Class 2 SELV |
Power supply range |
24V dc -15/+10 %, Class 2 SELV |
Dimensions |
90 mm high (104 mm with DIN latch open), 110 mm wide, 87 mm deep |
Shipping weight |
0.9 kg |
Heat dissipation |
17.0 W |
Expansion |
Up to six 1762 expansion I/O modules |
Communication |
RS-232 programming port, DF1 full duplex |
Memory |
4 KB program memory, Flash, no battery |
Operating temperature |
0…55 °C |
Storage temperature |
-40…85 °C |
Humidity |
5…95 %, non-condensing |
Lifecycle status |
Discontinued August 25, 2021 |
Replacement category |
Engineering Replacement |
UPC |
Not published |
Publication |
1762-UM001 |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1762-UM001 (module specifications) and 1761-SG001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
(10) standard 24V dc and (4) fast 24V dc inputs, (5) relay outputs, (4) standard and (1) fast 24V dc FET outputs on a 24 point brick.
The "R" suffix in the catalog number marks the version with a programming/HMI port, which lets a PanelView or a second serial device share the controller without unplugging the programming cable. Everything else in the brick is identical to the non-R version.
Variants ending in BX carry FET outputs instead of all-relay outputs. FET outputs switch dc only but last far longer than relay contacts under frequent cycling, so the BX versions are the choice for solenoid and lamp loads driven continuously.
Input power is 24V dc, Class 2 SELV. Heat dissipation of the brick alone is 17.0 W, which is the figure to use when sizing an enclosure: the expansion modules add their own dissipation on top.
The 1200 will carry up to six 1762 expansion modules. The system power budget is finite: 5V dc and 24V dc current drawn by the modules has to be validated against the controller's allowance before the count is fixed, and the manual provides a worksheet for exactly that.
On 24V dc powered units the power supply common is internally connected to chassis ground; on the ac units the 24V dc sensor supply common is. Neither is isolated, which matters when the panel also has a separate instrument supply.
Program memory is 4 KB in Flash. There is no battery and no retention window to manage: the program survives a dead supply indefinitely, which removes the routine battery task that the SLC 500 platform needed.
The RS-232 port runs DF1 full duplex and is the programming path; RSLogix 500 is the tool. The same port carries DH-485 or Modbus RTU with the appropriate protocol setting, and the R versions add the second port for an HMI.
Dimensions are 90 mm high — 104 mm with the DIN latch open — by 110 mm wide, 87 mm deep, at a shipping weight of 0.9 kg. Panel mounting with two screws per unit is the method for high-vibration sites; DIN rail is the everyday method.
Operating range is 0…55 °C, storage -40…85 °C, humidity 5…95 % non-condensing. The controller is rated for Class I Division 2 when installed per the manual.
1762-L24BXB was discontinued on August 25, 2021 with an Engineering Replacement as the replacement category. The MicroLogix 1200 platform ended as a whole between August and October 2021, with dates differing by catalog number.
The functional successor is the Micro800 family — different programming tool, different terminal layout, different expansion bus. In an existing panel the choices are a tested spare, a documented migration, or a like-for-like unit from stock.
What I/O does 1762-L24BXB have?
(10) standard 24V dc and (4) fast 24V dc inputs, (5) relay outputs, (4) standard and (1) fast 24V dc FET outputs.
What power supply does 1762-L24BXB need?
24V dc, Class 2 SELV.
How many expansion modules can 1762-L24BXB carry?
Up to six 1762 expansion I/O modules.
Is 1762-L24BXB still available from Rockwell?
No. Discontinued August 25, 2021; replacement category Engineering Replacement.
What does the R suffix mean on 1762-L24BXB?
A programming/HMI port in addition to the programming port — a second serial port for a panel device.
