Allen Bradley PLC 1762-L24AWAR / 1762L24AWAR

China Allen Bradley PLC 1762-L24AWAR / 1762L24AWAR supplier
Allen Bradley PLC 1762-L24AWAR / 1762L24AWAR supplier Allen Bradley PLC 1762-L24AWAR / 1762L24AWAR supplier Allen Bradley PLC 1762-L24AWAR / 1762L24AWAR supplier Allen Bradley PLC 1762-L24AWAR / 1762L24AWAR supplier Allen Bradley PLC 1762-L24AWAR / 1762L24AWAR supplier

Large Image :  Allen Bradley PLC 1762-L24AWAR / 1762L24AWAR

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1762-L24AWAR / 1762L24AWAR

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $335.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1762-L24AWAR technical data PDF download 1762-L24AWAR Rockwell MicroLogix 1200 24 point controller

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: MicroLogix 1200 / 1762

1762-L24AWAR is a MicroLogix 1200 24 point controller with (14) 120V ac digital inputs and (10) relay outputs, powered from 120/240V ac, with programming/HMI port.

The 1200 sat between the fixed MicroLogix 1000 and the expandable 1500: a brick controller with a real expansion bus, six modules wide, and 4 KB of program memory. It was the standard answer for a small machine that needed more than a fixed brick but less than a rack.

1762-L24AWA MicroLogix 1200 24 point controller IN STOCK
1762-L24AWAR MicroLogix 1200 24 point controller IN STOCK
1762-L24BWA MicroLogix 1200 24 point controller IN STOCK
1762-L24BWAR MicroLogix 1200 24 point controller IN STOCK
1762-L24BXB MicroLogix 1200 24 point controller IN STOCK
1762-L24BXBR MicroLogix 1200 24 point controller IN STOCK
1762-L40AWA MicroLogix 1200 40 point controller IN STOCK
1762-L40AWAR MicroLogix 1200 40 point controller IN STOCK
1762-L40BWA MicroLogix 1200 40 point controller IN STOCK
1762-L40BWAR MicroLogix 1200 40 point controller IN STOCK
1762-L40BXB MicroLogix 1200 40 point controller IN STOCK
1762-L40BXBR MicroLogix 1200 40 point controller IN STOCK

Product Specifications 1762-L24AWAR (PDF)
 Catalog number
 1762-L24AWAR
 Description
 MicroLogix 1200 24 point controller
 Embedded I/O
 (14) 120V ac digital inputs and (10) relay outputs
 Input power
 120/240V ac
 Power supply range
 100…240V ac -15/+10 % at 47…63 Hz
 Dimensions
 90 mm high (104 mm with DIN latch open), 110 mm wide, 87 mm deep
 Shipping weight
 0.9 kg
 Heat dissipation
 15.2 W
 Expansion
 Up to six 1762 expansion I/O modules
 Communication
 RS-232 programming port, DF1 full duplex, with programming/HMI port
 Memory
 4 KB program memory, Flash, no battery
 Operating temperature
 0…55 °C
 Storage temperature
 -40…85 °C
 Humidity
 5…95 %, non-condensing
 Lifecycle status
 Discontinued August 25, 2021
 Replacement category
 Engineering Replacement
 UPC
 Not published
 Publication
 1762-UM001

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1762-UM001 (module specifications) and 1761-SG001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

Part Description:
1762-L24AWAR 1762-L24AWAR 1762-L24AWAR 1762-L24AWAR 1762-L24AWAR

Point count and I/O mix

(14) 120V ac digital inputs and (10) relay outputs on a 24 point brick.

The "R" suffix in the catalog number marks the version with a programming/HMI port, which lets a PanelView or a second serial device share the controller without unplugging the programming cable. Everything else in the brick is identical to the non-R version.

Variants ending in BX carry FET outputs instead of all-relay outputs. FET outputs switch dc only but last far longer than relay contacts under frequent cycling, so the BX versions are the choice for solenoid and lamp loads driven continuously.

Power and loading

Input power is 120/240V ac. Heat dissipation of the brick alone is 15.2 W, which is the figure to use when sizing an enclosure: the expansion modules add their own dissipation on top.

The 1200 will carry up to six 1762 expansion modules. The system power budget is finite: 5V dc and 24V dc current drawn by the modules has to be validated against the controller's allowance before the count is fixed, and the manual provides a worksheet for exactly that.

On 24V dc powered units the power supply common is internally connected to chassis ground; on the ac units the 24V dc sensor supply common is. Neither is isolated, which matters when the panel also has a separate instrument supply.

Memory, ports and programming

Program memory is 4 KB in Flash. There is no battery and no retention window to manage: the program survives a dead supply indefinitely, which removes the routine battery task that the SLC 500 platform needed.

The RS-232 port runs DF1 full duplex and is the programming path; RSLogix 500 is the tool. The same port carries DH-485 or Modbus RTU with the appropriate protocol setting, and the R versions add the second port for an HMI.

Mounting and environment

Dimensions are 90 mm high — 104 mm with the DIN latch open — by 110 mm wide, 87 mm deep, at a shipping weight of 0.9 kg. Panel mounting with two screws per unit is the method for high-vibration sites; DIN rail is the everyday method.

Operating range is 0…55 °C, storage -40…85 °C, humidity 5…95 % non-condensing. The controller is rated for Class I Division 2 when installed per the manual.

Lifecycle and replacement

1762-L24AWAR was discontinued on August 25, 2021 with an Engineering Replacement as the replacement category. The MicroLogix 1200 platform ended as a whole between August and October 2021, with dates differing by catalog number.

The functional successor is the Micro800 family — different programming tool, different terminal layout, different expansion bus. In an existing panel the choices are a tested spare, a documented migration, or a like-for-like unit from stock.

FAQ — 1762-L24AWAR

What I/O does 1762-L24AWAR have?

(14) 120V ac digital inputs and (10) relay outputs.

What power supply does 1762-L24AWAR need?

120/240V ac.

How many expansion modules can 1762-L24AWAR carry?

Up to six 1762 expansion I/O modules.

Is 1762-L24AWAR still available from Rockwell?

No. Discontinued August 25, 2021; replacement category Engineering Replacement.

What does the R suffix mean on 1762-L24AWAR?

A programming/HMI port in addition to the programming port — a second serial port for a panel device.


Data sources. Embedded I/O, input power range, dimensions, weight, heat dissipation and the six-module expansion limit come from the controller tables in 1762-UM001. Discontinued dates, replacement category and UPC come from the Rockwell product page of each catalog number. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
