Allen Bradley PLC 1762-OV32T / 1762OV32T

China Allen Bradley PLC 1762-OV32T / 1762OV32T supplier
Allen Bradley PLC 1762-OV32T / 1762OV32T supplier Allen Bradley PLC 1762-OV32T / 1762OV32T supplier Allen Bradley PLC 1762-OV32T / 1762OV32T supplier Allen Bradley PLC 1762-OV32T / 1762OV32T supplier Allen Bradley PLC 1762-OV32T / 1762OV32T supplier Allen Bradley PLC 1762-OV32T / 1762OV32T supplier

Large Image :  Allen Bradley PLC 1762-OV32T / 1762OV32T

Product Details:

Place of Origin: Made in MALAYSIA
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1762-OV32T / 1762OV32T

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $205.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 20 PCS
Detailed Product Description

1762-OV32T technical data PDF download 1762-OV32T Rockwell MicroLogix 1200 expansion module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: MicroLogix 1200 / 1762

1762-OV32T is a 1762 expansion module for the MicroLogix 1200 and 1500: 32 point 24v dc sink output module.

Expansion modules clip onto the controller bus and appear as extra I/O in the same data files, with no special programming. A 1200 brick carries up to six of them, and the platform is still orderable — most 1762 I/O is listed Active Mature rather than discontinued, which is unusual for a controller family this old.

1762-IQ8OW8 8 Point 24V DC Input / Relay Output Module IN STOCK
1762-IR4 4 Channel RTD / Resistance Input Module IN STOCK
1762-OW8 8 Point VAC/VDC Relay Output Module IN STOCK
1762-OA8 8 Point 120/240V AC Output Module IN STOCK
1762-OB8 8 Point 24V DC Source Output Module IN STOCK
1762-OB32T 32 Point 24V DC Source Output Module IN STOCK
1762-IQ32T 32 Point 24V DC Sink/Source Input Module IN STOCK
1762-IF4 4 Channel Current/Voltage Analog Input Module IN STOCK
1762-IQ8 8 Point 24V DC Sink/Source Input Module IN STOCK
1762-IA8 8 Point 120V AC Input Module IN STOCK
1762-OX6I 6 Point 24V DC Isolated High Current Relay Output Module IN STOCK
1762-OV32T 32 Point 24V DC Sink Output Module IN STOCK
1762-OB16 16 Point 24V DC Source Output Module IN STOCK
1762-OF4 4 Channel Analog Output Module IN STOCK
1762-IT4 4 Channel Thermocouple/mV Input Module IN STOCK

Product Specifications 1762-OV32T (PDF)
 Catalog number
 1762-OV32T
 Description
 32 Point 24V DC Sink Output Module
 Channels
 32 sinking dc outputs
 Class
 Expansion I/O module, MicroLogix 1200 / 1500 system
 Bus power
 +5V dc and +24V dc from the system power supply
 Dimensions
 90 mm high (110 mm with mounting tabs), 87 mm deep, 40 mm wide
 Shipping weight
 260 g with carton
 Heat dissipation
 3.4 W
 Power supply distance
 6 modules maximum from the supply
 Operating temperature
 0…55 °C
 Storage temperature
 -40…85 °C
 Humidity
 5…95 %, non-condensing
 Vibration
 10…500 Hz, 5 g
 Shock
 30 g operating
 Lifecycle status
 Active Mature
 UPC
 612598849918
 Estimated lead time
 5 days
 Publication
 1762-UM003

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1762-UM003 (module specifications) and 1761-SG001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1762-OV32T 1762-OV32T 1762-OV32T

What the module adds

32 sinking dc outputs on the 32 point 24v dc sink output module.

The module is a bus device: it takes +5V dc and +24V dc from the controller supply, reports into the controller's input and output image, and is configured from the programming software rather than by switches. Analog modules are calibrated in software, not with potentiometers.

Bus loading and placement

Every module draws from the same 5V and 24V budget. Heat dissipation for this module is 3.4 W, which is the number to add to the controller figure when the enclosure is sized.

Power supply distance rating is six: a module may not sit more than six modules away from the system power supply. In a full six-module line that is automatically satisfied; in a longer line built on a 1500 system the placement has to be checked.

Current draw is published per module in the manual and has to be summed before the module count is frozen. Adding a seventh relay output module to a panel that is already at its 24V limit is the usual way an expansion goes wrong.

Wiring and environment

Dimensions are 90 mm high, 110 mm including mounting tabs, 87 mm deep and 40 mm wide, at 260 g shipping weight. Two M4 or #8 screws per module is the panel method; DIN rail works but panel mounting is preferred where vibration is present.

Operating temperature is 0…55 °C, storage -40…85 °C, humidity 5…95 % non-condensing, vibration 5 g over 10…500 Hz, shock 30 g. The module is UL 508 listed, C-UL certified and CE compliant, and rated Class I Division 2 for hazardous locations when installed per the manual.

Commissioning an analog module

Analog inputs and outputs are configured per channel: input range, filter frequency and data format. The default configuration is not necessarily the range the sensor uses, so a module that reads zero is often simply configured for the wrong range rather than faulty.

RTD and thermocouple modules need the sensor type set per channel as well. Recording the channel configuration in the panel documentation saves the next engineer a trip.

Availability

Lifecycle status on the Rockwell product page: Active Mature, with a published lead time of 5 days where the page lists one. That makes 1762 I/O a live spare line even though the controllers it plugs into are discontinued.

For a new machine the same functions exist in the Micro800 expansion range, but the modules are not interchangeable — different bus, different terminal base.

FAQ — 1762-OV32T

What does 1762-OV32T provide?

32 Point 24V DC Sink Output Module.

Which controllers accept 1762-OV32T?

MicroLogix 1200 and MicroLogix 1500 systems.

Is 1762-OV32T still available from Rockwell?

Lifecycle status: Active Mature.

How much heat does 1762-OV32T add?

3.4 W.

How far from the power supply can 1762-OV32T sit?

Six modules maximum, the published distance rating.


Data sources. Channel description and lifecycle come from the Rockwell product page of the catalog number; heat dissipation is taken from the module table in 1762-UM001, temperature, humidity, vibration, shock, dimensions and weight from the expansion module specification in 1762-UM003. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
