Allen Bradley PLC 1785-L46C15 / 1785L46C15

China Allen Bradley PLC 1785-L46C15 / 1785L46C15 supplier
Allen Bradley PLC 1785-L46C15 / 1785L46C15 supplier Allen Bradley PLC 1785-L46C15 / 1785L46C15 supplier Allen Bradley PLC 1785-L46C15 / 1785L46C15 supplier Allen Bradley PLC 1785-L46C15 / 1785L46C15 supplier Allen Bradley PLC 1785-L46C15 / 1785L46C15 supplier

Large Image :  Allen Bradley PLC 1785-L46C15 / 1785L46C15

Product Details:

Place of Origin: Made in USA
Brand Name: PLC Module
Certification: All goods we supply with 1 year warranty!
Model Number: Allen Bradley PLC 1785-L46C15 / 1785L46C15

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $8805.00 (USD/PCS)
Packaging Details: 100% New packaging
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 2 PCS
Detailed Product Description

1785-L46C15 technical data PDF download 1785-L46C15 Rockwell PLC-5/46C ControlNet 1.5 Protected Processor

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: Bulletin 1785 · PLC-5 controllers, memory and accessories

1785-L46C15 is a 1785-L46C15 Rockwell PLC-5/46C ControlNet 1.5 Protected Processor. It carries 48 K words of user memory and drives up to 2048 (any mix) or 2048 in + 2048 out discrete points, which is the number that decides whether a line can stay on this platform or has to be migrated.

The controller mounts in the leftmost slot of a 1771 chassis and takes rack 0. The published capacity is 16 (0-17) racks and 61 chassis in total, which includes the rack the controller itself occupies.

1785-ACC5LA PLC-5 accessory kit IN STOCK
1785-ACC5LB PLC-5 accessory kit IN STOCK
1785-CHBM ControlNet backup cartridge IN STOCK
1785-ENET PLC-5 Ethernet interface module IN STOCK
1785-L26B PLC-5/26 protected processor, 16 K words IN STOCK
1785-L40C15 PLC-5 ControlNet 1.5 processor, 48 K words IN STOCK
1785-L40C PLC-5 ControlNet 1.25 processor, 48 K words IN STOCK
1785-L46C15 PLC-5/46C ControlNet 1.5 protected processor IN STOCK
1785-L40E PLC-5/40E Ethernet processor, 48 K words IN STOCK
1785-L60B PLC-5/60 processor, 64 K words IN STOCK
1785-L60L PLC-5/60L processor with extended local I/O IN STOCK
1785-L80C PLC-5 ControlNet 1.25 processor, 100 K words IN STOCK
1785-L80B PLC-5/80 processor, 100 K words IN STOCK
1785-L80C15 PLC-5 ControlNet 1.5 processor, 100 K words IN STOCK
1785-L80E PLC-5/80E Ethernet processor, 100 K words IN STOCK
1785-L86B PLC-5/86 protected processor, 100 K words IN STOCK
1785-M100 100 K word memory module IN STOCK
1785-ME16 16 K word EEPROM memory cartridge IN STOCK
1785-ME32 32 K word EEPROM memory cartridge IN STOCK
1785-ME64 64 K word EEPROM memory cartridge IN STOCK
1785-RC Relay cartridge, edit and force monitoring IN STOCK

Product Specifications 1785-L46C15 (PDF)
 Catalog number
 1785-L46C15
 Product type
 PLC-5 programmable controller
 Processor
 1785-L46C15 Rockwell PLC-5/46C ControlNet 1.5 Protected Processor
 Maximum user memory
 48 K words
 Total I/O, any mix
 2048 (any mix) or 2048 in + 2048 out
 Communication ports
 ControlNet channel, DH+/Remote I/O channels, 1 serial port configurable for RS-232/423 and RS-422A
 Maximum I/O racks
 16 (0-17)
 Maximum I/O chassis
 61
 Lifecycle status
 Discontinued
 Discontinued date
 Not published
 Replacement category
 Engineering Replacement
 UPC
 Not published
 Country of origin
 Not published

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1785-UM041 (module specifications) and 1785-UM012 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1785-L46C15 1785-L46C15

ControlNet or DH+ channels and memory

1785-L46C15 is a 1785-L46C15 Rockwell PLC-5/46C ControlNet 1.5 Protected Processor. It carries 48 K words of user memory and drives up to 2048 (any mix) or 2048 in + 2048 out discrete points, which is the number that decides whether a line can stay on this platform or has to be migrated.

Communication is fixed in hardware on this model: ControlNet channel, DH+/Remote I/O channels, 1 serial port configurable for RS-232/423 and RS-422A. There is no slot to add a different network card later, so the network you plan around is the network you buy.

The /46 family is protected: 1785-UM012 names the /26, /46 and /86 as protected controllers, and the protection is enforced in firmware, so an unprotected program cannot simply be downloaded into it.

ControlNet 1.5 series with the protected-program feature of the /46 family.

Installing it in a PLC-5 chassis

The controller mounts in the leftmost slot of a 1771 chassis and takes rack 0. The published capacity is 16 (0-17) racks and 61 chassis in total, which includes the rack the controller itself occupies.

Wiring is by the standard PLC-5 terminal blocks and battery assembly; the processor keeps its program in RAM with battery backup, so the battery condition is the first thing to check on any unit pulled from a panel.

Lifecycle and replacement

Rockwell lists 1785-L46C15 as Discontinued with a replacement category of Engineering Replacement.

The processor family was wound down through the 2010s, so the practical replacement path is a Logix migration rather than a drop-in card. That means the ladder has to be re-hosted, and every 1771 rack in the cell has to be re-thought, not just the CPU.

Where these are still in use

These processors survive where a line was never re-engineered: water treatment, cement, pulp and paper, older automotive press lines and packaging machines with 1771 racks still in service.

The common failure pattern is not the CPU logic but the battery, the power supply and the backplane connectors, which is why buyers usually want a spare processor of the same catalog number rather than a rebuilt one.

Buying a used unit

Ask for the series and firmware revision printed on the label, and for a photo of the battery date code. A unit that has sat unpowered for years may still be fine, but a leaking battery will have corroded the board.

Confirm the catalog number exactly. The suffix matters: a /40E is not a /40B, and a ControlNet 1.5 processor will not run a program written for a 1.25 unit without a firmware review.

FAQ — 1785-L46C15

What is the memory and I/O capacity of 1785-L46C15?

48 K words words of user memory and 2048 (any mix) or 2048 in + 2048 out total I/O, any mix, per the 1785-UM012 system table.

Is 1785-L46C15 still sold by Rockwell?

No. It is listed as Discontinued with replacement category Engineering Replacement.

What are the communication ports on 1785-L46C15?

ControlNet channel, DH+/Remote I/O channels, 1 serial port configurable for RS-232/423 and RS-422A.

Can I use 1785-L46C15 with 1771 I/O racks?

Yes. It is designed for 1771 chassis, up to 16 (0-17) racks and 61 chassis per the published specification.

What should I check before buying a used 1785-L46C15?

Series and firmware revision, battery condition and date code, and the exact catalog suffix.


Data sources. Memory, I/O and channel figures come from the PLC-5 system specification table in 1785-UM012; lifecycle dates and UPC codes come from the Rockwell product page for the catalog number. Anything neither source prints is marked Not published. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
