Allen Bradley PLC 1771-IXE / 1771IXE

China Allen Bradley PLC 1771-IXE / 1771IXE supplier
Allen Bradley PLC 1771-IXE / 1771IXE supplier Allen Bradley PLC 1771-IXE / 1771IXE supplier Allen Bradley PLC 1771-IXE / 1771IXE supplier Allen Bradley PLC 1771-IXE / 1771IXE supplier Allen Bradley PLC 1771-IXE / 1771IXE supplier

Large Image :  Allen Bradley PLC 1771-IXE / 1771IXE

Product Details:

Place of Origin: Made in USA
Brand Name: PLC Module
Certification: All goods we supply with 1 year warranty!
Model Number: Allen Bradley PLC 1771-IXE / 1771IXE

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $2448.00 (USD/PCS)
Packaging Details: 100% New packaging
Delivery Time: IN STOCK; 2-4 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 4 PCS
Detailed Product Description

1771-IXE technical data PDF download 1771-IXE Rockwell 8 Point Thermocouple Input Module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: Bulletin 1771 · PLC-5 input modules

1771-IXE is a 8-point thermocouple input module for the 1771 I/O chassis used by PLC-5 and PLC-2 processors. It reads thermocouples and millivolt sources directly, which removes the transmitters a 4-20 mA card would need at every zone of a furnace or an oven.

Field connections land on the 1771-WA wiring arm, the 10-terminal arm that swings up to the module so the arm can stay wired while the module is swapped.


Product Specifications 1771-IXE (PDF)
 Catalog number
 1771-IXE
 Product type
 8-point thermocouple input module
 Number of inputs
 8
 Input signal
 Thermocouple and millivolt
 Module series
 Not published
 1771 chassis compatibility
 Any 1771 chassis
 Lifecycle status
 Discontinued
 Discontinued date
 31 May 2017
 Replacement category
 Engineering Replacement
 UPC
 Not published
 Country of origin
 United States of America
 Field wiring arm
 1771-WA, 10 terminal

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1785-UM664 (module specifications) and Rockwell literature library (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1771-IXE 1771-IXE

What the module does in a 1771 rack

1771-IXE is a 8-point thermocouple input module for the 1771 I/O chassis used by PLC-5 and PLC-2 processors. It reads thermocouples and millivolt sources directly, which removes the transmitters a 4-20 mA card would need at every zone of a furnace or an oven.

The slot it occupies is one 1771 slot, and the input image it claims is fixed by the module series: 8. That number decides how much of the processor input table the rack consumes, not how many wires the panel brings in.

Signal level is Thermocouple and millivolt. Nothing in the module is software configurable, so the field device has to match the printed range before the module is ordered.

Wiring, keying and the 1771-WA arm

Field connections land on the 1771-WA wiring arm, the 10-terminal arm that swings up to the module so the arm can stay wired while the module is swapped.

Keying bands in the chassis connector must line up with the slots on the module board. 1771 chassis are keyed per module type precisely so a 120 V AC module cannot be pushed into a slot wired for a 24 V DC module.

Backplane current comes from the chassis supply, so the load of every module in the rack has to be added up before a rack is repopulated with these cards.

Cold junction compensation and thermocouple type are configured per channel, so a used card has to be checked for its stored configuration before it is trusted.

Chassis compatibility and addressing

Chassis compatibility is published per module series: Any 1771 chassis. Series A modules fit the superseded 1771-A1, -A2 and -A4 chassis as well as the current A1B to A4B and AM1/AM2 chassis.

Some 32-point and isolated cards can only be placed under 1-slot or 2-slot addressing rules, so the addressing mode of the chassis has to be confirmed before a mixed rack is built.

Lifecycle and replacement

Rockwell lists 1771-IXE as Discontinued, replacement category Engineering Replacement.

The published discontinued date is 31 May 2017.

The family replacement path is a 1756 or 1794 migration, which means the field wiring, the wiring arms and the addressing scheme all change. Buying the same catalog number is usually cheaper than re-terminating a panel.

Buying a used module

Ask for a photo of the label side and the wiring arm. A module removed without its arm has to be re-keyed and re-wired, which is where most of the cost of a used card actually sits.

Check the module series letter against the chassis series: an A-series card in an A1B chassis works, but the reverse combination is what produces "module not recognised" faults.

These are static-sensitive cards. A unit shipped loose without conductive foam is a risk, whatever the price.

FAQ — 1771-IXE

How many inputs does 1771-IXE have?

8, on the published 1771 data sheet.

What input signal does 1771-IXE accept?

Thermocouple and millivolt.

Which 1771 chassis will accept 1771-IXE?

Any 1771 chassis.

Is 1771-IXE still available from Rockwell?

No. It is listed as Discontinued with replacement category Engineering Replacement.

What is the discontinued date of 1771-IXE?

31 May 2017.


Data sources. Point counts, input signal ranges and chassis codes come from the 1771 technical data sheets (1771-TD180 for DC, 1771-TD041 and 1771-IN082 for the 24 V AC module, 1771-IN046 and 1771-IN051 for analog); lifecycle dates, UPC and country of origin come from the Rockwell product page for the catalog number. Where Rockwell has withdrawn the catalog page, the field is marked Not published rather than guessed. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
