1785-L60B is a 1785-L60B Rockwell PLC-5/60 Processor. It carries 64 K words of user memory and drives up to 3072 (any mix) or 3072 in + 3072 out discrete points, which is the number that decides whether a line can stay on this platform or has to be migrated.
The controller mounts in the leftmost slot of a 1771 chassis and takes rack 0. The published capacity is 24 (0-27) racks and 93 chassis in total, which includes the rack the controller itself occupies.
| 1785-ACC5LA | PLC-5 accessory kit | IN STOCK |
| 1785-ACC5LB | PLC-5 accessory kit | IN STOCK |
| 1785-CHBM | ControlNet backup cartridge | IN STOCK |
| 1785-ENET | PLC-5 Ethernet interface module | IN STOCK |
| 1785-L26B | PLC-5/26 protected processor, 16 K words | IN STOCK |
| 1785-L40C15 | PLC-5 ControlNet 1.5 processor, 48 K words | IN STOCK |
| 1785-L40C | PLC-5 ControlNet 1.25 processor, 48 K words | IN STOCK |
| 1785-L46C15 | PLC-5/46C ControlNet 1.5 protected processor | IN STOCK |
| 1785-L40E | PLC-5/40E Ethernet processor, 48 K words | IN STOCK |
| 1785-L60B | PLC-5/60 processor, 64 K words | IN STOCK |
| 1785-L60L | PLC-5/60L processor with extended local I/O | IN STOCK |
| 1785-L80C | PLC-5 ControlNet 1.25 processor, 100 K words | IN STOCK |
| 1785-L80B | PLC-5/80 processor, 100 K words | IN STOCK |
| 1785-L80C15 | PLC-5 ControlNet 1.5 processor, 100 K words | IN STOCK |
| 1785-L80E | PLC-5/80E Ethernet processor, 100 K words | IN STOCK |
| 1785-L86B | PLC-5/86 protected processor, 100 K words | IN STOCK |
| 1785-M100 | 100 K word memory module | IN STOCK |
| 1785-ME16 | 16 K word EEPROM memory cartridge | IN STOCK |
| 1785-ME32 | 32 K word EEPROM memory cartridge | IN STOCK |
| 1785-ME64 | 64 K word EEPROM memory cartridge | IN STOCK |
| 1785-RC | Relay cartridge, edit and force monitoring | IN STOCK |
Catalog number |
1785-L60B |
Product type |
PLC-5 programmable controller |
Processor |
1785-L60B Rockwell PLC-5/60 Processor |
Maximum user memory |
64 K words |
Total I/O, any mix |
3072 (any mix) or 3072 in + 3072 out |
Communication ports |
4 DH+/Remote I/O (adapter or scanner), 1 serial port configurable for RS-232/423 and RS-422A |
Maximum I/O racks |
24 (0-27) |
Maximum I/O chassis |
93 |
Lifecycle status |
Discontinued |
Discontinued date |
31 December 2015 |
Replacement category |
Engineering Replacement |
UPC |
Not published |
Country of origin |
Not published |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1785-UM012 (module specifications) and Rockwell literature library (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
1785-L60B is a 1785-L60B Rockwell PLC-5/60 Processor. It carries 64 K words of user memory and drives up to 3072 (any mix) or 3072 in + 3072 out discrete points, which is the number that decides whether a line can stay on this platform or has to be migrated.
Communication is fixed in hardware on this model: 4 DH+/Remote I/O (adapter or scanner), 1 serial port configurable for RS-232/423 and RS-422A. There is no slot to add a different network card later, so the network you plan around is the network you buy.
The controller mounts in the leftmost slot of a 1771 chassis and takes rack 0. The published capacity is 24 (0-27) racks and 93 chassis in total, which includes the rack the controller itself occupies.
Wiring is by the standard PLC-5 terminal blocks and battery assembly; the processor keeps its program in RAM with battery backup, so the battery condition is the first thing to check on any unit pulled from a panel.
Each program file on a /60 is limited to 56 K words and each data table file to 32 K words, per the published specification notes.
Rockwell lists 1785-L60B as Discontinued with a replacement category of Engineering Replacement.
The published discontinued date is 31 December 2015.
The processor family was wound down through the 2010s, so the practical replacement path is a Logix migration rather than a drop-in card. That means the ladder has to be re-hosted, and every 1771 rack in the cell has to be re-thought, not just the CPU.
These processors survive where a line was never re-engineered: water treatment, cement, pulp and paper, older automotive press lines and packaging machines with 1771 racks still in service.
The common failure pattern is not the CPU logic but the battery, the power supply and the backplane connectors, which is why buyers usually want a spare processor of the same catalog number rather than a rebuilt one.
Ask for the series and firmware revision printed on the label, and for a photo of the battery date code. A unit that has sat unpowered for years may still be fine, but a leaking battery will have corroded the board.
Confirm the catalog number exactly. The suffix matters: a /40E is not a /40B, and a ControlNet 1.5 processor will not run a program written for a 1.25 unit without a firmware review.
What is the memory and I/O capacity of 1785-L60B?
64 K words words of user memory and 3072 (any mix) or 3072 in + 3072 out total I/O, any mix, per the 1785-UM012 system table.
Is 1785-L60B still sold by Rockwell?
No. It is listed as Discontinued with replacement category Engineering Replacement.
What are the communication ports on 1785-L60B?
4 DH+/Remote I/O (adapter or scanner), 1 serial port configurable for RS-232/423 and RS-422A.
Can I use 1785-L60B with 1771 I/O racks?
Yes. It is designed for 1771 chassis, up to 24 (0-27) racks and 93 chassis per the published specification.
What should I check before buying a used 1785-L60B?
Series and firmware revision, battery condition and date code, and the exact catalog suffix.
