Allen Bradley PLC 1785-M100 / 1785M100

China Allen Bradley PLC 1785-M100 / 1785M100 supplier
Allen Bradley PLC 1785-M100 / 1785M100 supplier Allen Bradley PLC 1785-M100 / 1785M100 supplier Allen Bradley PLC 1785-M100 / 1785M100 supplier Allen Bradley PLC 1785-M100 / 1785M100 supplier Allen Bradley PLC 1785-M100 / 1785M100 supplier

Large Image :  Allen Bradley PLC 1785-M100 / 1785M100

Product Details:

Place of Origin: Made in USA
Brand Name: PLC Module
Certification: All goods we supply with 1 year warranty!
Model Number: Allen Bradley PLC 1785-M100 / 1785M100

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $1015.00 (USD/PCS)
Packaging Details: 100% New packaging
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 2 PCS
Detailed Product Description

1785-M100 technical data PDF download 1785-M100 Rockwell PLC-5 100 K Word Memory Module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: Bulletin 1785 · PLC-5 controllers, memory and accessories

1785-M100 is the 100 K word memory module of the PLC-5 family, the largest capacity Rockwell listed in this form.

The module seats in the controller's memory cartridge position; the processor battery backs the RAM it carries.

1785-ACC5LA PLC-5 accessory kit IN STOCK
1785-ACC5LB PLC-5 accessory kit IN STOCK
1785-CHBM ControlNet backup cartridge IN STOCK
1785-ENET PLC-5 Ethernet interface module IN STOCK
1785-L26B PLC-5/26 protected processor, 16 K words IN STOCK
1785-L40C15 PLC-5 ControlNet 1.5 processor, 48 K words IN STOCK
1785-L40C PLC-5 ControlNet 1.25 processor, 48 K words IN STOCK
1785-L46C15 PLC-5/46C ControlNet 1.5 protected processor IN STOCK
1785-L40E PLC-5/40E Ethernet processor, 48 K words IN STOCK
1785-L60B PLC-5/60 processor, 64 K words IN STOCK
1785-L60L PLC-5/60L processor with extended local I/O IN STOCK
1785-L80C PLC-5 ControlNet 1.25 processor, 100 K words IN STOCK
1785-L80B PLC-5/80 processor, 100 K words IN STOCK
1785-L80C15 PLC-5 ControlNet 1.5 processor, 100 K words IN STOCK
1785-L80E PLC-5/80E Ethernet processor, 100 K words IN STOCK
1785-L86B PLC-5/86 protected processor, 100 K words IN STOCK
1785-M100 100 K word memory module IN STOCK
1785-ME16 16 K word EEPROM memory cartridge IN STOCK
1785-ME32 32 K word EEPROM memory cartridge IN STOCK
1785-ME64 64 K word EEPROM memory cartridge IN STOCK
1785-RC Relay cartridge, edit and force monitoring IN STOCK

Product Specifications 1785-M100 (PDF)
 Catalog number
 1785-M100
 Product type
 PLC-5 memory module
 Storage capacity
 100 K words
 Lifecycle status
 Discontinued
 Discontinued date
 31 December 2012
 Replacement category
 Engineering Replacement
 UPC
 Not published
 Country of origin
 Not published

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1785-SG001 (module specifications) and Rockwell literature library (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1785-M100 1785-M100

ControlNet or DH+ channels and memory

1785-M100 is the 100 K word memory module of the PLC-5 family, the largest capacity Rockwell listed in this form.

It is a plug-in module: the controller recognises the fitted card type in status word 68, which is how a programmer tells a 100 K module from a 64 K one without opening the case.

Installing it in a PLC-5 chassis

The module seats in the controller's memory cartridge position; the processor battery backs the RAM it carries.

Fitting a module of a different size changes the memory available to the program file, so the project has to be re-sized before the module is swapped, not after.

Lifecycle and replacement

Rockwell lists 1785-M100 as Discontinued as of 31 December 2012, with Engineering Replacement as the category.

There is no modern memory cartridge that fits a PLC-5, so a used module is the only way to keep memory capacity on an existing processor.

Where these are still in use

These modules are bought to keep an existing PLC-5 alive after a memory fault, or to raise capacity on a processor that is being asked to carry a slightly larger program.

Because the module is passive, most of the risk sits in how it was stored: unseated pins and bent edge connectors are the usual defects.

Buying a used unit

Ask for the module in its anti-static packaging, and check the edge connector for bent or lifted pins before inserting it in a live controller.

Confirm the capacity marking on the label matches 100 K: a 64 K module fitted where a 100 K one is expected will simply show less memory, and that is easy to misread as a faulty processor.

FAQ — 1785-M100

What capacity is 1785-M100?

100 K words.

Is 1785-M100 still available new?

No. Rockwell lists it as Discontinued since 31 December 2012.

How does the controller identify the module?

The installed card type is reported in status word 68.

Can I fit a 1785-M100 to any PLC-5?

Only to controllers that accept a memory module of this form and support the capacity; check the processor's published memory option first.

What usually fails on a used module?

Bent edge connector pins and poor contact after long storage.


Data sources. Memory, I/O and channel figures come from the PLC-5 system specification table in 1785-UM012; lifecycle dates and UPC codes come from the Rockwell product page for the catalog number. Anything neither source prints is marked Not published. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
