1784-PCM2 is the narrowest cable in the family: it connects a PCMK card to a PLC-2 processor and nothing else.
The cable ships with a loopback connector, which is used for the diagnostic test described in 1784-IN022: cable plus loopback proves the card and the lead before a processor is involved.
| 1784-U2DN | USB to DeviceNet adapter, PCMCIA-era replacement | IN STOCK |
| 1784-U2CN | USB to ControlNet adapter cable | IN STOCK |
| 1784-SD2 | Industrial 2 GB Secure Digital card | IN STOCK |
| 1784-SD1 | Industrial 1 GB Secure Digital card | IN STOCK |
| 1784-PKTXD | DH+ / RIO / DH-485 dual channel PCI card | IN STOCK |
| 1784-PKTCS | ControlNet 1.5 PC card | IN STOCK |
| 1784-PCM6 | DH+ cable, 8-pin mini-DIN | IN STOCK |
| 1784-PCM5 | PLC-5 / PCMCIA DH+ cable | IN STOCK |
| 1784-PCM4 | DH-485 cable for SLC 5/01 to 5/03 | IN STOCK |
| 1784-PCM2 | PLC-2 cable for the PCMK card | IN STOCK |
| 1784-PCIDS | DeviceNet PCI scanner card | IN STOCK |
| 1784-PCICS | ControlNet PCI scanner card | IN STOCK |
| 1784-PCIC | ControlNet PCI card, redundant media | IN STOCK |
| 1784-PCD1 | DeviceNet PCMCIA interface cable | IN STOCK |
| 1784-PCC1 | ControlNet PCMCIA interface cable | IN STOCK |
| 1784-CP8 | 62-pin D-shell to 3-pin Phoenix adapter | IN STOCK |
| 1784-CP7 | CP / CP5 to PLC-5 DIN adapter | IN STOCK |
| 1784-CP6 | KT / KT2 / KL to PLC-5 cable, 3.05 m | IN STOCK |
| 1784-CP14 | DH-485 cable, Phoenix to RJ45, 3.2 m | IN STOCK |
| 1784-CP11 | PLC-5 serial programming cable | IN STOCK |
| 1784-CP10 | PLC-5 serial programming cable | IN STOCK |
| 1784-CP | PLC-3 communication cable | IN STOCK |
Catalog number |
1784-PCM2 |
Product type |
PLC-2 communication cable for the PCMK card |
Connects to |
PLC-2 processor |
Cable total length |
3.16 m (10.4 ft) |
Loopback connector |
Supplied with the cable |
Country of origin |
United States of America |
Warranty |
1 year |
Publication |
1784-IN022 |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1784-IN022 (module specifications) and 1784-IN022 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
1784-PCM2 is the narrowest cable in the family: it connects a PCMK card to a PLC-2 processor and nothing else.
Because the PLC-2 port is unlike the DH+ ports on later processors, this lead cannot stand in for a PCM4 or a PCM5; the catalog number has to match the processor family.
Total length is about 3.16 m, with the usual pod in the middle and the wedges that carry its weight.
No current Rockwell product page is published for this catalog number; the cable exists in the documentation as 1784-PCM2/B in 1784-IN022.
Treated as discontinued with the rest of the PCM family. The PLC-2 itself is long out of production.
Programming and diagnostics of a PLC-2 from a laptop with the PCMK card — a rare but still encountered requirement in plants that never replaced the controller.
The loopback test is the other real use: proving a PCMK card and cable are good before blaming a processor.
Ask whether the loopback connector is included; without it the cable's own diagnostic is unavailable and a buyer loses the only test that isolates the card from the lead.
Check the processor-end connector shell and the pod, as with every cable in this family.
What does 1784-PCM2 connect?
1784-PCM2 is the narrowest cable in the family: it connects a PCMK card to a PLC-2 processor and nothing else.
Is 1784-PCM2 still available from Rockwell?
No current Rockwell listing; treated as discontinued.
What replaces 1784-PCM2?
No successor is named; the PLC-2 itself is out of production.
Where does 1784-PCM2 sit in the system?
Programming and diagnostics of a PLC-2 from a laptop with the PCMK card — a rare but still encountered requirement in plants that never replaced the controller.
What should I check before buying 1784-PCM2?
The loopback connector, the processor-end shell and the pod.
