Allen Bradley PLC 1784-CP8 / 1784CP8

China Allen Bradley PLC 1784-CP8 / 1784CP8 supplier
Allen Bradley PLC 1784-CP8 / 1784CP8 supplier Allen Bradley PLC 1784-CP8 / 1784CP8 supplier Allen Bradley PLC 1784-CP8 / 1784CP8 supplier Allen Bradley PLC 1784-CP8 / 1784CP8 supplier Allen Bradley PLC 1784-CP8 / 1784CP8 supplier

Large Image :  Allen Bradley PLC 1784-CP8 / 1784CP8

Product Details:

Place of Origin: Made in USA
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1784-CP8 / 1784CP8

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $131.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1784-CP8 technical data PDF download 1784-CP8 Rockwell 62 Pin D-Shell to 3 Pin Phoenix Adapter

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: Bulletin 1784 · PC interface cards and cables

1784-CP8 is a short adapter rather than a cable: 62-pin D-shell on the card side, 3-pin Phoenix on the network side.

Both connector types are published: 62-pin D-shell and 3-pin Phoenix. There is no cable length to quote because the part adapts connectors at the card.

1784-U2DN USB to DeviceNet adapter, PCMCIA-era replacement IN STOCK
1784-U2CN USB to ControlNet adapter cable IN STOCK
1784-SD2 Industrial 2 GB Secure Digital card IN STOCK
1784-SD1 Industrial 1 GB Secure Digital card IN STOCK
1784-PKTXD DH+ / RIO / DH-485 dual channel PCI card IN STOCK
1784-PKTCS ControlNet 1.5 PC card IN STOCK
1784-PCM6 DH+ cable, 8-pin mini-DIN IN STOCK
1784-PCM5 PLC-5 / PCMCIA DH+ cable IN STOCK
1784-PCM4 DH-485 cable for SLC 5/01 to 5/03 IN STOCK
1784-PCM2 PLC-2 cable for the PCMK card IN STOCK
1784-PCIDS DeviceNet PCI scanner card IN STOCK
1784-PCICS ControlNet PCI scanner card IN STOCK
1784-PCIC ControlNet PCI card, redundant media IN STOCK
1784-PCD1 DeviceNet PCMCIA interface cable IN STOCK
1784-PCC1 ControlNet PCMCIA interface cable IN STOCK
1784-CP8 62-pin D-shell to 3-pin Phoenix adapter IN STOCK
1784-CP7 CP / CP5 to PLC-5 DIN adapter IN STOCK
1784-CP6 KT / KT2 / KL to PLC-5 cable, 3.05 m IN STOCK
1784-CP14 DH-485 cable, Phoenix to RJ45, 3.2 m IN STOCK
1784-CP11 PLC-5 serial programming cable IN STOCK
1784-CP10 PLC-5 serial programming cable IN STOCK
1784-CP PLC-3 communication cable IN STOCK

Product Specifications 1784-CP8 (PDF)
 Catalog number
 1784-CP8
 Product type
 Cable adapter
 Connector 1
 62-pin D-shell
 Connector 2
 3-pin Phoenix
 Used with
 1784-KT, 1784-KL, 1784-KT2 communication interface cards
 Function
 Adapts the card's 62-pin connector to a DH+ 3-pin plug
 Country of origin
 United States of America
 Warranty
 1 year
 Publication
 Rockwell literature library

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications Rockwell literature library (module specifications) and Rockwell literature library (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1784-CP8 1784-CP8

What it connects

1784-CP8 is a short adapter rather than a cable: 62-pin D-shell on the card side, 3-pin Phoenix on the network side.

It exists because the 1784-KT, -KL and -KT2 interface cards present a 62-pin connector while a DH+ link terminates on a 3-pin plug; without the adapter there is no way to join the two.

Interface and cabling

It is used with the KT, KL and KT2 cards specifically. It is not the adapter for the PCMK PCMCIA card — that route uses the PCM cables and the 1784-CP7.

Lifecycle and replacement

The Rockwell product page for this catalog number is no longer online, and no discontinued date is published there. It is treated here as a discontinued item: no current listing, no current lead time.

Because it is an adapter and not a cable, a failed unit is usually a broken latch or a bent pin rather than a conductor failure.

Where these are still in use

Keeping a 1784-KT, -KL or -KT2 card usable: the card is worthless for DH+ work without this adapter.

Service kits where the interface card was bought years ago and the adapter has gone missing.

Buying a used unit

Inspect the 62-pin D-shell for bent pins and the Phoenix plug for a cracked housing; both are mechanical failures that are obvious on inspection.

Confirm the card model it will serve — KT, KL or KT2 — since the adapter is specific to those cards' 62-pin connector.

FAQ — 1784-CP8

What does 1784-CP8 connect?

1784-CP8 is a short adapter rather than a cable: 62-pin D-shell on the card side, 3-pin Phoenix on the network side.

Is 1784-CP8 still available from Rockwell?

No current Rockwell listing; treated as discontinued.

What replaces 1784-CP8?

No successor is named; the interface cards it serves are also out of production.

Where does 1784-CP8 sit in the system?

Keeping a 1784-KT, -KL or -KT2 card usable: the card is worthless for DH+ work without this adapter.

What should I check before buying 1784-CP8?

The 62-pin pins and the Phoenix housing.


Data sources. Connector types, compatible interface cards and function come from Rockwell DH+ programming cable tables (1785-RM005 and 1785-TD026); no product page is currently published for this catalog number. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
