1783-BMS06SL is a DIN rail managed switch designed to sit in the control cabinet on the same 24V dc bus as the controllers — 6 ports.
Lite firmware limits the ring and routing feature set. Where a fibre ring is part of the architecture, standardise on the Full build and treat Lite units as spares for Lite positions only.
| 1783-BMS20CL | Stratix 5700, 20 ports, 16 copper + 2 combo + 2 SFP | IN STOCK |
| 1783-BMS20CGP | Stratix 5700, 20 ports, gigabit combo | IN STOCK |
| 1783-BMS20CGL | Stratix 5700, 20 ports, gigabit combo, Lite firmware | IN STOCK |
| 1783-BMS20CGPK | Stratix 5700, 20 ports, gigabit combo, kit | IN STOCK |
| 1783-BMS06TA | Stratix 5700, 6 copper ports | IN STOCK |
| 1783-BMS06TL | Stratix 5700, 6 copper ports, Lite firmware | IN STOCK |
| 1783-BMS06TGA | Stratix 5700, 4 copper + 2 gigabit copper | IN STOCK |
| 1783-BMS06SA | Stratix 5700, 4 copper + 2 SFP | IN STOCK |
| 1783-BMS06SL | Stratix 5700, 4 copper + 2 SFP, Lite firmware | IN STOCK |
| 1783-BMS06SGA | Stratix 5700, 4 copper + 2 gigabit SFP | IN STOCK |
| 1783-BMS06SGL | Stratix 5700, 4 copper + 2 gigabit SFP, Lite firmware | IN STOCK |
| 1783-MS06T | Stratix 8000, 6 port chassis | IN STOCK |
| 1783-MS10T | Stratix 8000, 10 port chassis | IN STOCK |
| 1783-RMS06T | Stratix 8300, 6 port layer 3 | IN STOCK |
| 1783-RMS10T | Stratix 8300, 10 port layer 3 | IN STOCK |
| 1783-EMS04T | Stratix 6000, 4 port managed | IN STOCK |
| 1783-MX08T | Stratix 8000 copper 8 port expansion | IN STOCK |
| 1783-MX08F | Stratix 8000 fibre 8 port expansion | IN STOCK |
| 1783-MCF | Stratix 8000 CompactFlash spare card | IN STOCK |
| 1783-RMCF | Stratix 8300 CompactFlash spare card | IN STOCK |
| 1783-ETAP | EtherNet/IP tap, 3 copper ports | IN STOCK |
| 1783-ETAP2F | EtherNet/IP tap, 1 copper + 2 fibre | IN STOCK |
| 1783-SFP100FX | 100FX multimode SFP, 2 km | IN STOCK |
| 1783-SFP100LX | 100LX singlemode SFP, 10 km | IN STOCK |
| 1783-SFP1GSX | 1000SX multimode SFP, 550 m | IN STOCK |
| 1783-SFP1GLX | 1000LX singlemode SFP, 10 km | IN STOCK |
| 1783-US8T | Stratix 2000, 8 copper ports, unmanaged | IN STOCK |
| 1783-US03T01F | Stratix 2000, 3 copper + 1 fibre, unmanaged | IN STOCK |
Catalog number |
1783-BMS06SL |
Product family |
Stratix 5700 6 port managed switch |
Total ports |
6 ports |
Copper ports |
4 * 10/100 RJ45 |
SFP ports |
2 * 10/100 SFP |
Combination ports |
None |
Power input |
12…48V dc, Class 2 / SELV, 0.5 A |
Power consumption |
15 W maximum, 9.5 W at 24V dc and 40 °C |
Weight |
1.11 kg |
Mounting |
DIN rail (top hat rail) |
Firmware type |
Lite |
Lifecycle status |
Discontinued September 01, 2024 |
Replacement category |
Engineering Replacement |
Replacement product |
Not named on the product page |
Publication |
1783-UM011 |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1783-UM011 (module specifications) and 1783-SG001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
Copper: 4 * 10/100 RJ45. SFP: 2 * 10/100 SFP. Combination: None.
A combination port accepts either an RJ45 module or a Mini-GBIC, so the copper count and the fibre count cannot both be taken at face value on a unit where both are populated.
12…48V dc, Class 2 / SELV, 0.5 A; 15 W maximum, 9.5 W at 24V dc and 40 °C; DIN rail (top hat rail).
An alarm relay rated 1 A at 30V dc switches a panel lamp or a PLC input when the switch loses a supply or a monitored condition. That contact is often the only thing an operator sees when the network fails. A wide 12…48V dc range is deliberate: the switch runs from the same supply as the controllers.
Four copper ports and two 10/100 SFP cages run a small cell and a pair of fibre segments without a second device.
Managed switching inside a panel is about segmentation and diagnostics, not throughput. A cell/zone layout with IGMP snooping is what stops multicast I/O traffic from flooding every port in the cabinet.
Discontinued September 01, 2024, replacement category Engineering Replacement; the product page names no specific replacement product for this catalog number.
Existing units stay in service for years after a switch is retired. The practical questions are spare hardware and configuration backup — a replacement switch with no saved configuration is not a spare.
Ask for the firmware revision, the configuration export and a photograph of the label. On a managed switch these three matter more than cosmetic condition.
A unit pulled from a working line with a documented configuration is worth more than an unconfigured identical unit, and should be priced that way.
How many ports does 1783-BMS06SL have?
6 ports
What power does 1783-BMS06SL need?
12…48V dc, Class 2 / SELV, 0.5 A
Is 1783-BMS06SL still available from Rockwell?
No. Discontinued September 01, 2024; replacement category Engineering Replacement.
What replaces 1783-BMS06SL?
The product page lists Engineering Replacement without naming a specific replacement product.
What is 1783-BMS06SL used for?
Stratix 5700 6 port managed switch — a managed Ethernet switch for a control network.
