Allen Bradley PLC 1783-SFP100FX / 1783-SFP100FX

China Allen Bradley PLC 1783-SFP100FX / 1783-SFP100FX supplier
Allen Bradley PLC 1783-SFP100FX / 1783-SFP100FX supplier Allen Bradley PLC 1783-SFP100FX / 1783-SFP100FX supplier Allen Bradley PLC 1783-SFP100FX / 1783-SFP100FX supplier Allen Bradley PLC 1783-SFP100FX / 1783-SFP100FX supplier Allen Bradley PLC 1783-SFP100FX / 1783-SFP100FX supplier

Large Image :  Allen Bradley PLC 1783-SFP100FX / 1783-SFP100FX

Product Details:

Place of Origin: Made in USA
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1783-SFP100FX / 1783-SFP100FX

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $278.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 5 PCS
Detailed Product Description

1783-SFP100FX technical data PDF download 1783-SFP100FX Rockwell Stratix 100FX SFP Transceiver

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: Stratix 5700 / 8000 / 8300 / 2000 · 1783

1783-SFP100FX is a Stratix fibre SFP transceiver: 100BASE-FX multimode fibre at 1310 nm.

It is the part that turns an empty SFP cage on a Stratix switch into a working fibre link — and the part most often replaced after a lightning season.

1783-BMS20CL Stratix 5700, 20 ports, 16 copper + 2 combo + 2 SFP IN STOCK
1783-BMS20CGP Stratix 5700, 20 ports, gigabit combo IN STOCK
1783-BMS20CGL Stratix 5700, 20 ports, gigabit combo, Lite firmware IN STOCK
1783-BMS20CGPK Stratix 5700, 20 ports, gigabit combo, kit IN STOCK
1783-BMS06TA Stratix 5700, 6 copper ports IN STOCK
1783-BMS06TL Stratix 5700, 6 copper ports, Lite firmware IN STOCK
1783-BMS06TGA Stratix 5700, 4 copper + 2 gigabit copper IN STOCK
1783-BMS06SA Stratix 5700, 4 copper + 2 SFP IN STOCK
1783-BMS06SL Stratix 5700, 4 copper + 2 SFP, Lite firmware IN STOCK
1783-BMS06SGA Stratix 5700, 4 copper + 2 gigabit SFP IN STOCK
1783-BMS06SGL Stratix 5700, 4 copper + 2 gigabit SFP, Lite firmware IN STOCK
1783-MS06T Stratix 8000, 6 port chassis IN STOCK
1783-MS10T Stratix 8000, 10 port chassis IN STOCK
1783-RMS06T Stratix 8300, 6 port layer 3 IN STOCK
1783-RMS10T Stratix 8300, 10 port layer 3 IN STOCK
1783-EMS04T Stratix 6000, 4 port managed IN STOCK
1783-MX08T Stratix 8000 copper 8 port expansion IN STOCK
1783-MX08F Stratix 8000 fibre 8 port expansion IN STOCK
1783-MCF Stratix 8000 CompactFlash spare card IN STOCK
1783-RMCF Stratix 8300 CompactFlash spare card IN STOCK
1783-ETAP EtherNet/IP tap, 3 copper ports IN STOCK
1783-ETAP2F EtherNet/IP tap, 1 copper + 2 fibre IN STOCK
1783-SFP100FX 100FX multimode SFP, 2 km IN STOCK
1783-SFP100LX 100LX singlemode SFP, 10 km IN STOCK
1783-SFP1GSX 1000SX multimode SFP, 550 m IN STOCK
1783-SFP1GLX 1000LX singlemode SFP, 10 km IN STOCK
1783-US8T Stratix 2000, 8 copper ports, unmanaged IN STOCK
1783-US03T01F Stratix 2000, 3 copper + 1 fibre, unmanaged IN STOCK

Product Specifications 1783-SFP100FX (PDF)
 Catalog number
 1783-SFP100FX
 Description
 Stratix fibre SFP transceiver
 Optical type
 100BASE-FX multimode fibre
 Wavelength
 1310 nm
 Connector
 Dual LC
 Reach
 2 km
 Fibre
 62.5/125 µm, 500 MHz/km
 Digital optical monitoring
 Supported
 Estimated lead time
 45 days
 Lifecycle status
 Active
 Warranty
 1 year standard
 Publication
 1783-UM011

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1783-UM011 (module specifications) and 1783-SG001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1783-SFP100FX 1783-SFP100FX

Optics

100BASE-FX multimode fibre, 1310 nm, Dual LC connector, rated reach 2 km over 62.5/125 µm, 500 MHz/km.

The reach figure assumes the specified fibre. A link that works at 300 m on multimode will not work at 2 km because the switch negotiated something — the optic sets the distance, not the port.

Matching the far end

Both ends have to be the same optical type. A 100BASE-FX multimode SFP will not link to a 100BASE-LX singlemode port, whatever the connector looks like.

Keep a record of which cage holds which optic. Two identical switches with mixed SFPs is the most common cause of a link nobody can explain.

Digital optical monitoring

DOM exposes transmit power, receive power and temperature to the switch diagnostics, which turns a marginal link into a measured problem.

Use it before swapping hardware: a receive level 6 dB down on one port is usually the patch lead, not the transceiver.

Availability

Lifecycle status Active with a published estimated lead time of 45 days. These are orderable new, unlike the switches they plug into.

Because the transceiver outlives the chassis, buying new SFPs for a discontinued Stratix 5700 is normal practice — the switch is the scarce part.

Related parts

Stratix 5700 (1783-BMS…) and Stratix 8000/8300 chassis carry the cages; 1783-MX08F is the fibre expansion module for the 8000.

1783-SFP100FX and 1783-SFP100LX are the 100 Mbit pair; 1783-SFP1GSX and 1783-SFP1GLX the gigabit pair.

FAQ — 1783-SFP100FX

What fibre does 1783-SFP100FX need?

100BASE-FX multimode fibre over 62.5/125 µm, 500 MHz/km.

What reach does 1783-SFP100FX support?

2 km

What connector does 1783-SFP100FX use?

Dual LC

Is 1783-SFP100FX still orderable?

Yes. Lifecycle status Active, estimated lead time 45 days.

Can 1783-SFP100FX be mixed with another SFP type?

No. Both ends of the link must be the same optical type.


Data sources. Optical type, wavelength, connector, fibre core and reach come from the Rockwell product page of this catalog number. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
