Allen Bradley PLC 1771-IFE / 1771IFE

China Allen Bradley PLC 1771-IFE / 1771IFE supplier
Allen Bradley PLC 1771-IFE / 1771IFE supplier Allen Bradley PLC 1771-IFE / 1771IFE supplier Allen Bradley PLC 1771-IFE / 1771IFE supplier Allen Bradley PLC 1771-IFE / 1771IFE supplier Allen Bradley PLC 1771-IFE / 1771IFE supplier Allen Bradley PLC 1771-IFE / 1771IFE supplier

Large Image :  Allen Bradley PLC 1771-IFE / 1771IFE

Product Details:

Place of Origin: Made in USA
Brand Name: PLC Module
Certification: All goods we supply with 1 year warranty!
Model Number: Allen Bradley PLC 1771-IFE / 1771IFE

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $1512.00 (USD/PCS)
Packaging Details: 100% New packaging
Delivery Time: IN STOCK; 2-4 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 3 PCS
Detailed Product Description

1771-IFE technical data PDF download 1771-IFE Rockwell Analog Input Module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: Bulletin 1771 · PLC-5 input modules

1771-IFE is a Analog input module for the 1771 I/O chassis used by PLC-5 and PLC-2 processors. The module takes voltage or current per input, set by configuration jumpers, but all inputs must be either single-ended or differential: mixing the two on one card is not allowed.

Field connections land on the 1771-WA wiring arm, the 10-terminal arm that swings up to the module so the arm can stay wired while the module is swapped.


Product Specifications 1771-IFE (PDF)
 Catalog number
 1771-IFE
 Product type
 Analog input module
 Number of inputs
 Not published
 Input signal
 Voltage or current, set per input by configuration jumper
 Module series
 Not published
 1771 chassis compatibility
 Any 1771 chassis, series A and B
 Lifecycle status
 Discontinued
 Discontinued date
 31 May 2017
 Replacement category
 Engineering Replacement
 UPC
 612598002214
 Country of origin
 Not published
 Field wiring arm
 1771-WA, 10 terminal

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1771-IN045 (module specifications) and 1785-UM664 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1771-IFE 1771-IFE

What the module does in a 1771 rack

1771-IFE is a Analog input module for the 1771 I/O chassis used by PLC-5 and PLC-2 processors. The module takes voltage or current per input, set by configuration jumpers, but all inputs must be either single-ended or differential: mixing the two on one card is not allowed.

The slot it occupies is one 1771 slot, and the input image it claims is fixed by the module series: Not published. That number decides how much of the processor input table the rack consumes, not how many wires the panel brings in.

Signal level is Voltage or current, set per input by configuration jumper. Nothing in the module is software configurable, so the field device has to match the printed range before the module is ordered.

Wiring, keying and the 1771-WA arm

Field connections land on the 1771-WA wiring arm, the 10-terminal arm that swings up to the module so the arm can stay wired while the module is swapped.

Keying bands in the chassis connector must line up with the slots on the module board. 1771 chassis are keyed per module type precisely so a 120 V AC module cannot be pushed into a slot wired for a 24 V DC module.

Backplane current comes from the chassis supply, so the load of every module in the rack has to be added up before a rack is repopulated with these cards.

Published data table use for the /C series: 8 input image bits, 8 output image bits, 22 read block words and 39 write block words, with unrestricted addressing in series A and B chassis.

Chassis compatibility and addressing

Chassis compatibility is published per module series: Any 1771 chassis, series A and B. Series A modules fit the superseded 1771-A1, -A2 and -A4 chassis as well as the current A1B to A4B and AM1/AM2 chassis.

Some 32-point and isolated cards can only be placed under 1-slot or 2-slot addressing rules, so the addressing mode of the chassis has to be confirmed before a mixed rack is built.

Lifecycle and replacement

Rockwell lists 1771-IFE as Discontinued, replacement category Engineering Replacement.

The published discontinued date is 31 May 2017.

The family replacement path is a 1756 or 1794 migration, which means the field wiring, the wiring arms and the addressing scheme all change. Buying the same catalog number is usually cheaper than re-terminating a panel.

Rockwell specifically warns against using this module with a 1771-AL PLC-2/20 or 2/30 local adapter, and says the A/B simulation jumper has to be reset when a series A or B card is replaced by a /C.

Buying a used module

Ask for a photo of the label side and the wiring arm. A module removed without its arm has to be re-keyed and re-wired, which is where most of the cost of a used card actually sits.

Check the module series letter against the chassis series: an A-series card in an A1B chassis works, but the reverse combination is what produces "module not recognised" faults.

These are static-sensitive cards. A unit shipped loose without conductive foam is a risk, whatever the price.

FAQ — 1771-IFE

How many inputs does 1771-IFE have?

Not published, on the published 1771 data sheet.

What input signal does 1771-IFE accept?

Voltage or current, set per input by configuration jumper.

Which 1771 chassis will accept 1771-IFE?

Any 1771 chassis, series A and B.

Is 1771-IFE still available from Rockwell?

No. It is listed as Discontinued with replacement category Engineering Replacement.

What is the discontinued date of 1771-IFE?

31 May 2017.


Data sources. Point counts, input signal ranges and chassis codes come from the 1771 technical data sheets (1771-TD180 for DC, 1771-TD041 and 1771-IN082 for the 24 V AC module, 1771-IN046 and 1771-IN051 for analog); lifecycle dates, UPC and country of origin come from the Rockwell product page for the catalog number. Where Rockwell has withdrawn the catalog page, the field is marked Not published rather than guessed. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
