Allen Bradley PLC 1756-BATM / 1756BATM

China Allen Bradley PLC 1756-BATM / 1756BATM supplier
Allen Bradley PLC 1756-BATM / 1756BATM supplier Allen Bradley PLC 1756-BATM / 1756BATM supplier Allen Bradley PLC 1756-BATM / 1756BATM supplier Allen Bradley PLC 1756-BATM / 1756BATM supplier Allen Bradley PLC 1756-BATM / 1756BATM supplier

Large Image :  Allen Bradley PLC 1756-BATM / 1756BATM

Product Details:

Place of Origin: Made in USA
Brand Name: Rockwell
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1756-BATM / 1756BATM

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $178.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 5 PCS
Detailed Product Description


1756-BATM technical data PDF download 1756-BATM ControlLogix Battery Module | Rockwell

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC Automation

The 1756-BATM (also written 1756BATM) is the ControlLogix battery module — the mounting and connection part that carries a 1756-BATA replacement battery assembly. Rockwell publishes it with an output of 20 mA max at 3.6 V DC and a function of battery backup, for use with ControlLogix 5560.

The module is discontinued: Rockwell announces that as of 18 July 2017 it is no longer available for sale, with no planned replacement. That makes it the oldest end-of-life item in this group, and the one most likely to be already missing from a rack that a customer is trying to bring back into service.

The pairing is the practical point: a module without a battery does nothing, and a battery without a module cannot be installed. Both halves are discontinued, and both are needed together, which is why a rack that still uses this arrangement is usually one outage away from a controller restart.

Published attributes: UPC 612598284764, function battery backup, temperature rating 0...60 °C (32...140 °F), country of origin multiple, one year standard warranty, installation instructions 1756-IN576, and an ATEX certification entry recorded as of 16 July 2026.

1756-BA2
Lithium battery assembly, Series B 1756-L6x only, end of life 2027-12-31, UPC 612598322152
Limited stock
1756-BATA
Replacement battery assembly for 1756-BATM, end of life 2027-12-31, UPC 612598284757
Limited stock
1756-BATM
Battery module, 20 mA max at 3.6 V DC, discontinued 2017-07-18, UPC 612598284764
Limited stock

 Application
 Controller battery backup
 Brand Name
 Rockwell (Rockwell)
 Cat Num
 1756-BATM
 Communication
 —
 Display
 —
 Enclosure
 —
 Interface
 Controller battery connector
 Mounting
 Inside controller / module
 Number Of Channels
 —
 Standard
 CE, UL
 Sub Brand
 ControlLogix
 Type
 Battery
 UNSPSC
 —

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1756-TD003 (module specifications) and 1756-IN576 (battery module installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1756-BATM battery module product photograph 1756-BATM module view product photograph 1756-BATM mounting detail product photograph

Where the module sits in a typical system

This module exists only for the controllers that use it, and those are an installed base, not a current selection. Its relevance in a quotation is almost always a repair or a refurbishment rather than a new build.

Where a customer is restoring an older ControlLogix rack, the module and the 1756-BATA assembly have to be sourced together. Supplying one and leaving the customer to find the other is how a repair becomes a second outage.

Because both parts are discontinued with no planned replacement, the honest advice in a quotation is that this is a bridge to a controller migration, not a permanent fix.

Commissioning in five steps

  1. Read the series letter on the controller label first. The 1756-BA2 title states 'L6X Ser B ONLY', so a Series A controller is a different battery — the wrong assembly either will not fit or will not be recognised.
  2. Replace the battery with the chassis de-energised and the controller powered down by the documented procedure, so the controller is not left relying on a battery that has just been removed.
  3. Dispose of the removed lithium assembly through the battery waste route. It is a lithium cell, not general electronic waste.
  4. Record the replacement date on the panel schedule. The assemblies carry a shelf life, so a spare kept in a stores bin for years is not the same as a spare bought for this outage.
  5. Because all three catalogue numbers are end-of-life or discontinued, check the current stock position before promising a delivery date to a customer.

Diagnostics: status indicators

Three bi-colour indicators plus the alphanumeric display cover almost every commissioning fault, so most problems are resolved at the panel without a laptop.

 Indicator State Meaning and first action
 Check 2 Discontinued since 2017 No sales since 18 July 2017 and no planned replacement. Anything found now is channel stock, so condition and age matter as much as part number.
 Check 3 Output rating 20 mA max at 3.6 V DC as published. It is a backup current, not a supply rail for the rack.
 Check 4 Installation document 1756-IN576 is the installation instruction for this module; fit it by that document, not by layout habit.
 Check 5 Hazardous location An ATEX certification entry is published for the module as of 16 July 2026. Where the rack sits in a classified area, the product label governs, not the catalogue page.

Lifecycle dates and attributes per the Rockwell product record for this catalogue number; battery data per 1756-TD001 / 1756-TD002 and installation instructions 1756-IN576 and 1756-IN050.

Replacing a 1756-BATM

No planned Rockwell replacement for the module, and none for its 1756-BATA assembly. The controller generation is the real migration path.

The module is not interchangeable with the 1756-BA2 battery assembly used by Series B 1756-L6x controllers — different arrangement, different parts.

For a rack already on a newer controller family, the backup arrangement is defined by that controller, and 1756-SG001 is the selection reference.

Which ControlLogix EtherNet/IP module to specify

  • 1756-BA2 — lithium battery assembly titled 'ControlLogix L6X Ser B ONLY'; fits Series B 1756-L6x controllers, end of life with a 31 December 2027 discontinued date.
  • 1756-BATA — replacement battery assembly for the 1756-BATM module; same end-of-life date, no planned replacement.
  • 1756-BATM — ControlLogix battery module, discontinued 18 July 2017, output 20 mA max at 3.6 V DC, installation instructions 1756-IN576.
  • 1756-TD001 — controller technical data, the cutsheet for the L6x battery assembly.
  • 1756-TD002 — battery cutsheet listed against the 1756-BATA replacement assembly.
  • 1756-SG001 — selection guide; use it to confirm which battery a given controller series takes.

FAQ — 1756-BATM ControlLogix Battery Module | Rockwell

What is the 1756-BATM?

The ControlLogix battery module that carries a 1756-BATA replacement battery assembly, with a published output of 20 mA max at 3.6 V DC.

Is it still available?

No. Rockwell publishes it as discontinued as of 18 July 2017, with no planned replacement. Only channel stock remains.

What battery goes inside it?

The 1756-BATA replacement battery assembly — the two are parts of one arrangement and both are discontinued.

What is the temperature rating?

0...60 °C (32...140 °F) as published.

Which controllers use it?

Rockwell lists the parent as ControlLogix 5560, so it belongs to that controller generation, not to current families.

Is there an installation instruction?

Yes — 1756-IN576 covers the module.

Is it certified for hazardous areas?

An ATEX certification entry is published as of 16 July 2026; the product label on the specific unit governs.

What replaces it?

Nothing at part level. The practical path is controller migration, and the module should be treated as a bridge rather than a permanent repair.


Data sources. Technical values on this page come from Rockwell publications 1756-TD003 (ControlLogix Communication Modules Specifications), 1756-IN050 (1756 EtherNet/IP Communication Modules, installation instructions), 1756-UM004 (ControlLogix EtherNet/IP Network Devices User Manual) and the manufacturer's product page for 1756-BATM. Values re-checked 15 November 2026.
