Allen Bradley PLC 1756-DMCF003 / 1756DMCF003

China Allen Bradley PLC 1756-DMCF003 / 1756DMCF003 supplier
Allen Bradley PLC 1756-DMCF003 / 1756DMCF003 supplier Allen Bradley PLC 1756-DMCF003 / 1756DMCF003 supplier Allen Bradley PLC 1756-DMCF003 / 1756DMCF003 supplier Allen Bradley PLC 1756-DMCF003 / 1756DMCF003 supplier Allen Bradley PLC 1756-DMCF003 / 1756DMCF003 supplier

Large Image :  Allen Bradley PLC 1756-DMCF003 / 1756DMCF003

Product Details:

Place of Origin: Made in USA
Brand Name: Rockwell
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1756-DMCF003 / 1756DMCF003

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $182.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 2 PCS
Detailed Product Description

1756-DMCF003 technical data PDF download 1756-DMCF003 / 1756DMCF003 Drive Comm Fibre Cable, 3 m

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC Automation

The 1756-DMCF003 (also written 1756DMCF003) is the three-metre pre-configured drive communication cable for the ControlLogix drive module family. Rockwell lists it in the installation instructions for the 1756-DMD30 and 1756-DMF30 alongside 1756-DMCF001, -DMCF010 and -DMCF030, at 1, 3, 10 and 30 metres.

It is not a SynchLink cable. The drive comm link runs on 62.5/125 µm glass at 820 nm infrared and 10 Mbps, terminated as one pair SC style and one pair ST style, with breakout cables to Belden 225362 or Mohawk M92021. SynchLink is the other link on the same module, on 200/230 µm hard-clad silica at 650 nm red and 5 Mbps, and it uses a different cable.

1756-DMCF001
1 m
In stock
1756-DMCF003
3 m
In stock
1756-DMCF010
10 m
In stock
1756-DMCF030
30 m
In stock
1756-DMAF
adapter
In stock

 Application
 Drive communication, fibre
 Brand Name
 Rockwell (Rockwell)
 Cat Num
 1756-DMCF003
 Type
 Pre-configured drive comm cable
 Sub Brand
 ControlLogix
 Mounting
 Panel, module to PMI chassis
 Interface
 One pair SC style, one pair ST style
 Length
 3 m
 Fibre
 62.5/125 µm glass
 Wavelength
 820 nm infrared
 Data Rate
 10 Mbps
 Maximum Run
 300 m with one splice or adapter
 Minimum Run
 1 m
 Breakout Cable
 Belden 225362 or Mohawk M92021
 UNSPSC
 32151705

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1756-TD003 (module specifications) and 1756-IN050 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1756-DMCF003 drive comm cable product photograph 1756-DMCF003, second view product photograph 1756-DMCF003, third view product photograph

Where the drive comm cable sits in a typical system

A drive module talks to two networks and the cable set differs for each. The DMCF family carries drive comm traffic between the module and a single PMI chassis; the 1403-CF family carries SynchLink synchronisation between modules. Ordering the wrong one is the most common mistake in this family, because both are fibre and both plug into the same faceplate area.

Length is the whole engineering decision for a pre-configured cable. The published limit is 300 m on either link with no more than one splice or adapter, and 1 m minimum — which rules out the obvious trick of coiling a long cable into a short cabinet run.

Pre-configured cables exist to remove field termination. Making an SC/ST breakout by hand in a panel is possible and rarely worth it: the modules are positioned by the chassis, the PMI chassis is positioned by the drive, and the distance between them is usually one of the four published lengths.

Choosing a length in four checks

  1. Budget the backplane before the slot is chosen: 1.35 A at 5.1 V DC and 3.0 mA at 24 V DC per module, 6.96 W maximum dissipation, added to every other module in the chassis.
  2. Mount the chassis in a suitable enclosure; the equipment is rated Pollution Degree 2, overvoltage Category II, 2000 m altitude, with an operating range of 0…60 °C.
  3. Separate the two fibre runs by type. Drive comm is 62.5/125 µm glass at 820 nm and 10 Mbps; SynchLink is 200/230 µm hard-clad silica at 650 nm and 5 Mbps. They are not the same cable.
  4. Respect the published limits: 300 m maximum on either link with no more than one splice or adapter, 1 m minimum, 10 nodes in a daisy chain or 256 in a star on SynchLink, one PMI chassis on drive comm.
  5. Treat insertion under power as live work. RIUP is supported, and the instructions still warn that an arc can send an erroneous signal to field devices.

Cable lengths and what the link will accept

A pre-configured cable has no diagnostics of its own; the decision is the catalogue number at the right length, and the limits below come from the drive module installation instructions.

 Catalog number  Length  When to specify
1756-DMCF001 1 m The published option for a 1 m run; order by length, not by cut-and-splice.
1756-DMCF003 3 m The published option for a 3 m run; order by length, not by cut-and-splice.
1756-DMCF010 10 m The published option for a 10 m run; order by length, not by cut-and-splice.
1756-DMCF030 30 m The published option for a 30 m run; order by length, not by cut-and-splice.
1756-DMAF adapter The published option for a adapter run; order by length, not by cut-and-splice.

Cable type, length and link limits per Rockwell publication 1756-IN577-EN-P and 1756-IN050.

Replacing a drive comm cable

A cable is a consumable. When drive comm drops out, the first checks are the DRIVE COMM OK indicator and the connector seating, and the practical spare is the same catalogue number at the length the panel was built with.

Do not substitute a SynchLink cable for a drive comm cable because it plugs in. The core size, the wavelength and the data rate all differ, and the failure shows up as an intermittent link that tests fine on a bench.

Longer runs belong to the published list, not to a splice: 1756-DMCF030 covers 30 m, and any run beyond 300 m is outside the specification regardless of cable quality.

Which drive comm cable to specify

  • 1756-DMD30 — the one-axis drive module for the SD3000 drive system, fibre-linked to the PMI chassis and SynchLink.
  • 1756-DMF30 — the same module for the SF3000 drive system; electrically identical, functionally not interchangeable.
  • 1756-DMCF001 / 003 / 010 / 030 — pre-configured drive comm cables at 1, 3, 10 and 30 m.
  • 1756-DMAF — the adapter for existing UDC/PMI fibre cables.
  • 1403-CF0xx — pre-configured SynchLink cables, 1 m to 250 m.

FAQ — 1756-DMCF003 / 1756DMCF003 Drive Comm Fibre Cable, 3 m

What is the 1756-DMCF003?

A three-metre pre-configured drive comm fibre cable for the ControlLogix drive module family.

Which modules use it?

The 1756-DMD30 and 1756-DMF30 drive modules, and the PMI chassis they connect to.

What fibre does it carry?

62.5/125 µm glass at 820 nm infrared, 10 Mbps, one pair SC and one pair ST.

Is it the same as a SynchLink cable?

No. SynchLink uses 200/230 µm hard-clad silica at 650 nm red and 5 Mbps.

What other lengths are available?

1756-DMCF001 at 1 m, 1756-DMCF010 at 10 m and 1756-DMCF030 at 30 m.

What is the maximum run?

300 m with no more than one splice or one adapter, and 1 m minimum.

Which breakout cables are named?

Belden 225362 or Mohawk M92021.

What is the difference between DMCF and 1403-CF?

DMCF is the drive comm cable; 1403-CF is the SynchLink cable, listed from 1 m to 250 m.


Data sources. Technical values on this page come from Rockwell publications 1756-IN577 (ControlLogix Drive Module, catalog numbers 1756-DMD30 and 1756-DMF30, installation instructions - cable list on page 8) and the manufacturer's product page for 1756-DMCF003. Values re-checked 16 November 2026.
