Allen Bradley PLC 1756-A10 / 1756A10

China Allen Bradley PLC 1756-A10 / 1756A10 supplier
Allen Bradley PLC 1756-A10 / 1756A10 supplier Allen Bradley PLC 1756-A10 / 1756A10 supplier Allen Bradley PLC 1756-A10 / 1756A10 supplier Allen Bradley PLC 1756-A10 / 1756A10 supplier Allen Bradley PLC 1756-A10 / 1756A10 supplier Allen Bradley PLC 1756-A10 / 1756A10 supplier

Large Image :  Allen Bradley PLC 1756-A10 / 1756A10

Product Details:

Place of Origin: Made in USA
Brand Name: Rockwell
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1756-A10 / 1756A10

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $346.00 USD/PCS
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 5 PCS
Detailed Product Description


1756-A10 technical data PDF download 1756-A10 ControlLogix 10 Slot Chassis | Rockwell

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC Automation

The 1756-A10 (also written 1756A10) is the 10-slot ControlLogix chassis: capacity 10 slots, convection cooling, published minimum enclosure 50.8 x 76.2 x 20.3 cm (20 x 30 x 8 in.). It is the first size in the family where a dense line can be wired without splitting into two racks.

The backplane is passive. Power comes from a separately ordered 1756-PA75 or 1756-PB75 supply, or from a redundant pair through a 1756-PSCA2 chassis adapter on a /B (AC) or /C (DC) chassis.

The 76.2 cm minimum width is the number that matters in a panel design: the rack is wider than the cabinet door module grid of many standard enclosures, so the enclosure is usually chosen after the chassis, not before it.

Published record: UPC 612598129270, active lifecycle, country of origin multiple, one year warranty, drawings as 2-D PDF, DXF and 3-D STEP, publications 1756-SG001 and the chassis installation instructions.

1756-A4
4 slots, minimum enclosure 50.8 x 50.8 x 20.3 cm, UPC 612598129300
In stock
1756-A7
7 slots, minimum enclosure 50.8 x 60.9 x 20.3 cm, UPC 612598129317
In stock
1756-A10
10 slots, minimum enclosure 50.8 x 76.2 x 20.3 cm, UPC 612598129270
In stock
1756-A13
13 slots, minimum enclosure 60.9 x 76.2 x 20.3 cm, UPC 612598129287
In stock
1756-A17
17 slots, minimum enclosure 76.2 x 91.4 x 20.3 cm, UPC 612598129294
In stock

 Application
 Chassis / backplane
 Brand Name
 Rockwell (Rockwell)
 Cat Num
 1756-A10
 Communication
 —
 Display
 —
 Enclosure
 Open chassis, convection cooled
 Interface
 Backplane
 Mounting
 Panel, bracket supplied
 Number Of Channels
 —
 Standard
 CE, UL, cUL
 Sub Brand
 ControlLogix
 Type
 Chassis
 UNSPSC
 —

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1756-TD003 (module specifications) and 1756-IN005 (chassis installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1756-A10 chassis view 1 product photograph 1756-A10 chassis view 2 product photograph 1756-A10 chassis view 3 product photograph

Where the module sits in a typical system

Ten slots covers a full process unit — controller, three network modules, six I/O modules — without splitting I/O across racks and without a second chassis-to-chassis link to design.

It is also the size that keeps a redundant design simple: the pair, adapter and two 0.91 m cables sit beside a single rack rather than being distributed across two.

Because the enclosure height stays 50.8 cm across the family, a 10-slot rack shares the panel's vertical layout with a 7-slot one; only the width grows from 60.9 to 76.2 cm.

Commissioning in five steps

  1. Confirm the chassis series against the supply: a /B chassis takes the AC redundant pair, a /C chassis takes the DC pair, and a standard chassis takes one non-redundant supply. The compatibility table in 1756-IN620 is the authority for this.
  2. Mount the chassis on the panel using the bracket the chassis ships with, and leave the convection path open — the published minimum enclosure size is a volume requirement, not a clearance allowance.
  3. Install the power supply, then verify the backplane voltages at the supply terminals before any module is inserted. A wiring error found with an empty chassis costs a fuse; found with a loaded chassis it costs modules.
  4. Insert modules with the chassis de-energised, then check that every module seats flush. A module that stops half way leaves its backplane connector open.
  5. Record the slot assignment on the drawing. ControlLogix allows the controller and communication modules to be placed in the slots the design needs, so the drawing rather than convention is what a later technician will follow.

Diagnostics: status indicators

Three bi-colour indicators plus the alphanumeric display cover almost every commissioning fault, so most problems are resolved at the panel without a laptop.

 Indicator State Meaning and first action
 Check 2 Panel width first 76.2 cm minimum enclosure width. Check the panel drawing before ordering the rack, because this is the size where a standard enclosure starts to constrain the layout.
 Check 3 Supply sizing Total module backplane current must be checked against the supply selected. The supply, not the rack, is the limit.
 Check 4 Series suffix /B with the AC redundant pair, /C with the DC pair. Confirm from the label and the IN620 table.
 Check 5 Wiring volume A 10-slot rack brings roughly twice the field wiring of a 4-slot one into the same height. Terminal space is the constraint, not the chassis envelope.

Slot and supply compatibility per Rockwell publication 1756-IN620 (ControlLogix Redundant Power Supply installation instructions) and 1756-IN005 (chassis installation instructions) and 1756-IN050.

Sizing the rack and upgrading the slot count

Below it is 1756-A7 (7 slots, 50.8 x 60.9 cm); above it are 1756-A13 (13 slots, 60.9 x 76.2 cm) and 1756-A17 (17 slots, 76.2 x 91.4 cm).

A rack replacement means a new panel cut-out and a new slot drawing, so the decision is a project-stage decision, not a maintenance one.

Supplies, adapter and cables are family-wide parts — a rack change does not obsolete them.

Which ControlLogix EtherNet/IP module to specify

  • 1756-A4 — 4 slots, minimum enclosure 50.8 x 50.8 x 20.3 cm; the smallest enclosure footprint of the family.
  • 1756-A7 — 7 slots, minimum enclosure 50.8 x 60.9 x 20.3 cm; the size most machine-level panels are built around.
  • 1756-A10 — 10 slots, minimum enclosure 50.8 x 76.2 x 20.3 cm.
  • 1756-A13 — 13 slots, minimum enclosure 60.9 x 76.2 x 20.3 cm, 0...60 °C published.
  • 1756-A17 — 17 slots, minimum enclosure 76.2 x 91.4 x 20.3 cm, 0...60 °C published.
  • Series suffix matters — /B chassis take the AC redundant pair (1756-PA75R x2 + 1756-PSCA2 + 1756-CPR2 x2); /C chassis take the DC redundant pair (1756-PB75R x2 + the same adapter and cables).
  • 1756-PA75 / 1756-PB75 — the single supplies used when redundancy is not required; ordered separately from the chassis.

FAQ — 1756-A10 ControlLogix 10 Slot Chassis | Rockwell

What is the 1756-A10?

A 10-slot ControlLogix chassis, convection cooled, published minimum enclosure 50.8 x 76.2 x 20.3 cm.

Does the chassis include a supply?

No. The supply is a separate catalogue number — single 1756-PA75 or 1756-PB75, or a redundant pair with 1756-PSCA2.

How many I/O modules can I fit?

Nine module positions after the controller, if a single controller is used and the supply occupies the leftmost position.

What is the minimum enclosure?

50.8 x 76.2 x 20.3 cm (20 x 30 x 8 in.), with the convection path kept open.

Which series takes a redundant supply?

/B takes the AC pair and /C the DC pair; 1756-IN620 lists the combinations.

Is it fan cooled?

No — convection cooling, so no filter to service and no fan failure to diagnose.

What is the UPC?

612598129270.

Are drawings available?

Yes: 2-D PDF, DXF and 3-D STEP, plus 1756-SG001 for selection.


Data sources. Technical values on this page come from Rockwell publications 1756-TD003 (ControlLogix Communication Modules Specifications), 1756-IN050 (1756 EtherNet/IP Communication Modules, installation instructions), 1756-UM004 (ControlLogix EtherNet/IP Network Devices User Manual) and the manufacturer's product page for 1756-A10. Values re-checked 15 November 2026.
