Allen Bradley PLC 1794-IB32 / 1794IB32

China Allen Bradley PLC 1794-IB32 / 1794IB32 supplier
Allen Bradley PLC 1794-IB32 / 1794IB32 supplier Allen Bradley PLC 1794-IB32 / 1794IB32 supplier Allen Bradley PLC 1794-IB32 / 1794IB32 supplier Allen Bradley PLC 1794-IB32 / 1794IB32 supplier Allen Bradley PLC 1794-IB32 / 1794IB32 supplier Allen Bradley PLC 1794-IB32 / 1794IB32 supplier

Large Image :  Allen Bradley PLC 1794-IB32 / 1794IB32

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1794-IB32 / 1794IB32

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $219.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 25 PCS
Detailed Product Description

1794-IB32 technical data PDF download FLEX I/O 1794-IB32 / 1794IB32 32-Point 24V DC Sinking Input Module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC I/O

The 1794-IB32 puts thirty-two 24V DC sinking inputs on one FLEX I/O slot, in two groups of sixteen with separate supply and common terminals, on a 1794-TB32 or 1794-TB32S terminal base.

It trades field-side robustness for density: the input impedance is 22.2 kΩ rather than 4.6 kΩ, the operating range starts at 19.2V DC, and the module is certified for 0...55 °C rather than the -20...55 °C of the sixteen-point cards.

1794-IB8 8-point 24V DC sinking input module IN STOCK
1794-IB16 16-point 24V DC sinking input module IN STOCK
1794-IB32 32-point 24V DC sinking input module IN STOCK
1794-IB10XOB6 10 inputs / 6 sourcing outputs, 24V DC combo module IN STOCK
1794-IB16XOB16P 16 inputs / 16 protected sourcing outputs combo module IN STOCK
1794-IB16D 16-point diagnostic sinking input module IN STOCK
1794-IB16XT 16-point 24V DC sinking input, extended temperature IN STOCK
1794-IB10XOB6XT 10 inputs / 6 sourcing outputs, extended temperature IN STOCK
1794-IA8 8-point 120V AC input module IN STOCK
1794-IA16 16-point 120V AC input module IN STOCK
1794-IC16 16-point 48V DC sinking input module IN STOCK
1794-IG16 16-point 5V DC TTL input module IN STOCK
1794-IH16 16-point 125V DC sinking input module IN STOCK
1794-IM8 8-point 240V AC input module IN STOCK
1794-IM16 16-point 240V AC input module IN STOCK
1794-IV16 16-point 24V DC sourcing input module IN STOCK
1794-IV32 32-point 24V DC sourcing input module IN STOCK

Product Specifications 1794-IB32 (PDF)
 Application
 FLEX I/O high-density digital input
 Cat Num
 1794-IB32
 Brand Name
 Rockwell
 Inputs
 32, current, sinking (two groups of 16)
 On-state voltage
 19.2V DC min, 24V DC nom, 31.2V DC max
 On-state current
 2.0 mA min, 4.1 mA nom, 6.0 mA max
 Off-state voltage
 5.0V DC max
 Input impedance
 22.2 kΩ nominal
 Isolation
 50V continuous basic; type tested 212V DC for 2 s
 Flexbus current
 25 mA at 5V DC
 Power dissipation
 6.0 W max at 31.2V DC (20.47 BTU/hr)
 Terminal base
 1794-TB32, 1794-TB32S
 Operating temperature
 0...55 °C (32...131 °F)
 Weight
 79 g (2.79 oz)

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1794-DU001 (module specifications) and 1794-SG002 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1794-IB32 original product photograph, wide view 1794-IB32 original product photograph, wide view 1794-IB32 original product photograph, wide view

Two groups, two supplies

Inputs 0...15 and 16...31 are separate groups. Each has its own +V and common terminals on the 34...51 row, so two different sensor supplies can feed one module without a common bus.

Row A carries the first sixteen signals, row B the second sixteen. Terminals 16 and 33 on row B and 34 and 51 on row C are not connections on the TB32 base — a wiring mistake that shows up as a dead second group.

<Daisy-chaining follows group boundaries. C-41 to the next base for +V1, C-42 for COM1, C-49 for +V2 and C-50 for COM2.

The two groups are independent, so one module can serve a 24V DC sensor bank and a separately supplied dry-contact bank, as long as both stay inside 19.2...31.2V DC.

The 0...55 °C rating excludes cold-start duty; a panel that drops below freezing needs enclosure heating or a different module.

Adapter firmware levels are printed per family, so a 32-point retrofit bill of materials has to name the adapter series and revision, not just the module.

At 22.2 kΩ the input draws roughly a quarter of the current of the 16-point card, so an indicator lamp in series may no longer pull the input on.

The TB32 base brings forty-eight screw terminals to a single slot, which is why wire numbers are planned before the card is ordered.

Field thresholds and the density compromise

19.2...31.2V DC on-state with 2.0 mA minimum, 4.1 mA nominal and 6.0 mA maximum, so a sensor that worked on a 4.6 kΩ module draws roughly a quarter of the current here.

22.2 kΩ nominal impedance means leakage current matters more: a wet contact or a long cable with induced voltage can hold an input on where a 16-point module would read it off.

0...55 °C operating range against -20...55 °C for the 16-point modules — the density costs low-temperature headroom, which matters on outdoor or cold-store panels.

Adapter compatibility is explicit

Remote I/O: 1794-ASB series E or later, 1794-ASB2 series D or later.

ControlNet: 1794-ACN15 series C firmware 4.1 or later, 1794-ACNR15 series C firmware 4.1 or later.

DeviceNet: 1794-ADN series B firmware 2.4 or later; EtherNet/IP: 1794-AENT series A firmware 2.4 or later; PROFIBUS: 1794-APBDPV1 with series B GSD file; Logix: Studio 5000 Logix Designer version 20 or later.

Electrical position

25 mA flexbus, 6.0 W maximum dissipation (20.47 BTU/hr) at 31.2V DC, 79 g, 94 x 94 x 69 mm with the base.

Isolation is 212V DC type tested for 2 s at 50V continuous basic — a lower test level than the 16-point module, and the reason the datasheet should be read before assuming interchangeability.

UL file E322657 and E334470 cover the module; the temperature code is T3C with no IECEx or ATEX Zone 2 approval, unlike the eight- and sixteen-point modules.

Where 32 points on one slot pays

Concentrated switch banks. A machine section with 30 limit switches on one adapter saves a slot and a terminal base.

Panel space. Three 1794-IB32 replace six 16-point modules, which is half the rail and half the bases.

Not for mixed-voltage islands. Because both groups are 24V DC sinking, a 32-point card does not help where the island mixes AC and DC inputs.

FAQ — 1794-IB32

How many inputs has the 1794-IB32?

Thirty-two, current sinking, arranged as two groups of sixteen with independent supply and common terminals.

Which terminal base does it need?

1794-TB32 or 1794-TB32S; the TB3 family does not carry 32 points.

What is the input impedance?

22.2 kΩ nominal, compared with 4.6 kΩ on the 1794-IB8 and 1794-IB16.

What does it draw from the backplane?

25 mA at 5V DC over the flexbus.

Which adapter firmware is required?

ASB series E, ASB2 series D, ACN15/ACNR15 series C firmware 4.1, ADN series B firmware 2.4, AENT series A firmware 2.4, APBDPV1 GSD revision B, or Studio 5000 version 20 or later.

Is the 1794-IB32 rated for Zone 2?

No. The ATEX/IECEx Zone 2 approvals listed by Rockwell cover the 1794-IB8 and 1794-IB16, not the 32-point module.


Data sources. Technical values on this page come from Rockwell publication 1794-IN093 (FLEX I/O Digital Input Modules, 1794-IB8, -IB16, -IB32), 1794-IN083 (1794-IB10XOB6 and 1794-IB16XOB16P) and 1794-DU001 (protection method and electrical ratings). Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
