Allen Bradley PLC 1794-IB10XOB6 / 1794IB10XOB6

China Allen Bradley PLC 1794-IB10XOB6 / 1794IB10XOB6 supplier
Allen Bradley PLC 1794-IB10XOB6 / 1794IB10XOB6 supplier Allen Bradley PLC 1794-IB10XOB6 / 1794IB10XOB6 supplier Allen Bradley PLC 1794-IB10XOB6 / 1794IB10XOB6 supplier Allen Bradley PLC 1794-IB10XOB6 / 1794IB10XOB6 supplier Allen Bradley PLC 1794-IB10XOB6 / 1794IB10XOB6 supplier

Large Image :  Allen Bradley PLC 1794-IB10XOB6 / 1794IB10XOB6

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1794-IB10XOB6 / 1794IB10XOB6

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $143.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1794-IB10XOB6 technical data PDF download FLEX I/O 1794-IB10XOB6 / 1794IB10XOB6 10 In / 6 Out 24V DC Module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC I/O

The 1794-IB10XOB6 combines ten 24V DC sinking inputs and six 24V DC sourcing outputs in one FLEX I/O slot, on a 1794-TB3 family terminal base or a 1794-TB2.

It is the module for a small island that needs a few inputs and a few relay-driving outputs at once — a valve cluster, a conveyor section, a remote starter group — where two separate modules would waste a slot and a base.

1794-IB8 8-point 24V DC sinking input module IN STOCK
1794-IB16 16-point 24V DC sinking input module IN STOCK
1794-IB32 32-point 24V DC sinking input module IN STOCK
1794-IB10XOB6 10 inputs / 6 sourcing outputs, 24V DC combo module IN STOCK
1794-IB16XOB16P 16 inputs / 16 protected sourcing outputs combo module IN STOCK
1794-IB16D 16-point diagnostic sinking input module IN STOCK
1794-IB16XT 16-point 24V DC sinking input, extended temperature IN STOCK
1794-IB10XOB6XT 10 inputs / 6 sourcing outputs, extended temperature IN STOCK
1794-IA8 8-point 120V AC input module IN STOCK
1794-IA16 16-point 120V AC input module IN STOCK
1794-IC16 16-point 48V DC sinking input module IN STOCK
1794-IG16 16-point 5V DC TTL input module IN STOCK
1794-IH16 16-point 125V DC sinking input module IN STOCK
1794-IM8 8-point 240V AC input module IN STOCK
1794-IM16 16-point 240V AC input module IN STOCK
1794-IV16 16-point 24V DC sourcing input module IN STOCK
1794-IV32 32-point 24V DC sourcing input module IN STOCK

Product Specifications 1794-IB10XOB6 (PDF)
 Application
 FLEX I/O combi digital module
 Cat Num
 1794-IB10XOB6
 Brand Name
 Rockwell
 Inputs
 10, current, sinking
 Outputs
 6, current, sourcing
 Input on-state
 10V DC min, 24V DC nom, 31.2V DC max; 2.0 to 12.1 mA
 Output on-state
 10V DC min, 24V DC nom, 31.2V DC max
 Output current
 2 A per channel, 10 A per module max
 Surge current
 4 A for 50 ms, repeatable every 2 s
 Isolation
 50V continuous basic; tested 2121V DC for 1 s
 Flexbus current
 50 mA at 5V DC
 Power dissipation
 6.0 W max at 31.2V DC (20.3 BTU/hr)
 Terminal base
 1794-TB2, -TB3, -TB3S, -TB3K, -TB3SK, -TBKD, -TB37DS
 Weight
 85 g (3.00 oz)

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1794-DU001 (module specifications) and 1794-SG002 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1794-IB10XOB6 original product photograph, wide view 1794-IB10XOB6 original product photograph, wide view 1794-IB10XOB6 original product photograph, wide view

Input side

Ten sinking inputs, 10...31.2V DC on-state, 2.0 mA minimum and 8.8 mA nominal at 24V DC with a 12.1 mA maximum, off-state 5V DC and 1.5 mA.

4.8 kΩ nominal impedance and a selectable filter time of 0.25 to 32 ms set through bits 08, 09 and 10 of the configuration word.

Inputs 0...9 land on row A with the supply and common on rows C and B respectively, the same wiring grammar as the pure input modules.

The 1794-TB2 alternative suits a panel where only part of the module's points are wired and a shorter terminal base saves rail space.

With no internal fusing, a shorted load is cleared by the external fuse and the module reports the channel off rather than damaged.

Input-to-output isolation is what lets a sensor supply and a separate output supply share one base without a common return.

The T3 temperature code comes from the output stage, so the module is not a drop-in substitute for a T4 input card in a Zone 2 assessment.

Ten inputs and six outputs match a valve manifold plus its position feedback, which is why that ratio exists in the range.

Output side

Six sourcing outputs rated 2 A each and 10 A per module across 10...31.2V DC, with a 4 A surge for 50 ms repeatable every 2 s.

<1V DC maximum on-state drop at 2 A, 0.5 mA maximum off-state leakage, and output delays of 0.5 ms off-to-on and 1.0 ms on-to-off.

Outputs are not fused internally. Rockwell recommends external fusing with a SAN-O MQ4-3A or Littelfuse 235-003 fuse; a shorted solenoid without that fuse is a module replacement.

Isolation that separates the two halves

2121V DC for 1 s, system to I/O and inputs to outputs, at 50V continuous basic insulation — this module does separate its input and output sides, unlike the pure input cards.

Still no channel-to-channel isolation. Two outputs feeding two solenoids share a return path, which matters when one device is replaced live.

Six outputs mean six fuses in a real panel; that is the cost of a combi module against a separate 1794-OB8.

Certification and functional safety

TÜV certified up to SIL 2 for the 1794-IB10XOB6, and UL listed under E65584 and E194810 for Class I Division 2.

Zone 2 approval is Ex ec IIC T3 Gc under DEMKO 14 ATEX 1342501X and IECEx UL 14.0066X, which is one temperature class lower than the 1794-IB16 because of the output stage.

EFT immunity ±3 kV on power ports and ±2 kV on signal ports — a higher power-port level than the input-only modules, reflecting the switched load.

Selection notes

Six outputs is a deliberate number. It matches a valve manifold, a starter group or a small annunciator, and leaves two spare points on a 8-output card budget.

85 g, 94 x 94 x 69 mm with the base, 6.0 W (20.3 BTU/hr) — the same envelope as an input module, so panel space is not the reason to split functions.

Where isolation matters, split. If the inputs and outputs must be in separate circuits with separate supplies and separate returns, two modules do that better than one combi.

FAQ — 1794-IB10XOB6

How many points has the 1794-IB10XOB6?

Ten sinking inputs and six sourcing outputs in one slot.

What is the output current rating?

2 A per channel and 10 A per module maximum, with a 4 A surge for 50 ms repeatable every 2 s.

Are the outputs fused?

No. Rockwell specifies external fusing, for example a SAN-O MQ4-3A or Littelfuse 235-003 fuse.

Which terminal bases are allowed?

1794-TB2, 1794-TB3, 1794-TB3S, 1794-TB3K, 1794-TB3SK, 1794-TBKD or 1794-TB37DS.

Is it certified for functional safety?

Yes, TÜV certified up to and including SIL 2.

Does it isolate inputs from outputs?

Yes, 2121V DC for 1 s between system and I/O and between inputs and outputs, at 50V continuous basic insulation.


Data sources. Technical values on this page come from Rockwell publication 1794-IN093 (FLEX I/O Digital Input Modules, 1794-IB8, -IB16, -IB32), 1794-IN083 (1794-IB10XOB6 and 1794-IB16XOB16P) and 1794-DU001 (protection method and electrical ratings). Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
