Allen Bradley PLC 1794-OB32P / 1794-OB32P

China Allen Bradley PLC 1794-OB32P / 1794-OB32P supplier
Allen Bradley PLC 1794-OB32P / 1794-OB32P supplier Allen Bradley PLC 1794-OB32P / 1794-OB32P supplier Allen Bradley PLC 1794-OB32P / 1794-OB32P supplier Allen Bradley PLC 1794-OB32P / 1794-OB32P supplier Allen Bradley PLC 1794-OB32P / 1794-OB32P supplier Allen Bradley PLC 1794-OB32P / 1794-OB32P supplier

Large Image :  Allen Bradley PLC 1794-OB32P / 1794-OB32P

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1794-OB32P / 1794-OB32P

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $245.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1794-OB32P technical data PDF download FLEX I/O 1794-OB32P 32-Point Protected 24V DC Output Module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC I/O

The 1794-OB32P puts thirty-two self-protected sourcing outputs on one FLEX I/O slot, split into two groups of sixteen with separate supply terminals so each group can run from its own 24V DC source.

It is the density answer for a valve bank or a starter group: one slot, one TB32 base, and half the rail of two sixteen-point modules.

1794-OB8 8-point 24V DC sourcing output module IN STOCK
1794-OB8EP 8-point 2 A electronically fused sourcing output module IN STOCK
1794-OB16 16-point 24V DC sourcing output module IN STOCK
1794-OB16P 16-point protected sourcing output module IN STOCK
1794-OB16D 16-point diagnostic 24V DC output module IN STOCK
1794-OB32P 32-point protected sourcing output module IN STOCK
1794-OB16PXT 16-point protected sourcing output, extended temperature IN STOCK
1794-OB8EPXT 8-point 2 A electronically fused output, extended temperature IN STOCK
1794-OV16 16-point sinking output module IN STOCK
1794-OV16P 16-point protected sinking output module IN STOCK
1794-OV32 32-point sinking output module IN STOCK
1794-OC16 16-point 48V DC sourcing output module IN STOCK
1794-OG16 16-point 5V DC sourcing output module IN STOCK
1794-OW8 8-point isolated relay output module IN STOCK

Product Specifications 1794-OB32P (PDF)
 Application
 FLEX I/O high-density protected output
 Cat Num
 1794-OB32P
 Brand Name
 Rockwell
 Outputs
 32, sourcing, protected, two groups of 16
 On-state voltage
 10V DC min, 24V DC nom, 31.2V DC max
 Output current
 500 mA per channel
 Module current
 6.0 A on channels 0...15, 8.0 A on channels 16...31
 On-state voltage drop
 0.5V DC max
 Surge current
 2 A for 50 ms, repeatable every 2 s
 Output delay
 0.5 ms off to on, 1.0 ms on to off
 External supply current
 103...273 mA
 Isolation
 50V continuous; tested 850V DC for 60 s
 Power dissipation
 5.3 W max at 31.2V DC (18.1 BTU/hr)
 Terminal base
 1794-TB32, 1794-TB32S
 Operating temperature
 0...55 °C (32...131 °F)

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1794-DU001 (module specifications) and 1794-SG002 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1794-OB32P original product photograph, wide view 1794-OB32P original product photograph, wide view 1794-OB32P original product photograph, wide view

Two groups, two supplies

Channels 0...15 and 16...31 are independent groups with their own +V and common terminals on the 34...51 row of the TB32 base.

Group current limits differ: 6.0 A total on the first sixteen channels and 8.0 A on the second, against a 14 A module figure.

Separate supplies let one group stay energised while the other is isolated for maintenance — the practical reason the base has four supply terminals.

Fourteen amps for the module against six and eight per group means the group limits, not the channel rating, constrain a dense valve bank.

The two group supplies can come from separate 24V feeds, which is how a machine keeps a safety branch apart from a general-purpose one.

Fault recovery is automatic, so an intermittently chafed cable produces a repeating off-on pattern instead of a latched fault.

At 0...55 °C the module excludes cold-start duty, unlike the 16-point protected card rated from -20 °C.

One TB32 base holds forty-eight terminals, which is why wire numbers are planned before the card is ordered.

A group running from its own supply can be isolated while the other stays energised; the module keeps the groups separate but they share the base.

The 2 A surge figure is per channel, so simultaneous inrush across several channels is bounded by the 14 A module limit, not by the sum of surges.

Protected output stage

500 mA per channel with electronic protection against short and overload, recovery on fault removal, and no fault bit to the processor.

0.5V DC maximum drop and 0.5 ms / 1.0 ms delays, matching the 16-point protected module.

2 A surge for 50 ms every 2 s is enough for a solenoid, not for a contactor coil above the rating.

Supply and thermal

103...273 mA from the external supply is the module's own draw, and it is the highest in the digital output range because thirty-two protected channels are monitored continuously.

<5.3 W maximum dissipation (18.1 BTU/hr) at 31.2V DC and 0...55 °C operation — the density costs low-temperature range compared with the 16-point cards.

50V continuous basic insulation, tested 850V DC for 60 s, field side to system, with no channel-to-channel isolation.

Base and wiring

<1794-TB32 or 1794-TB32S only. The TB3 family does not carry 32 points; terminals 16, 33, 34 and 51 are not connections on this base.

<Outputs land on rows A and B, with +V1/COM1 and +V2/COM2 on row C, and jumpers carry the supplies to the next base.

Keyswitch position 2 must be set on the base before the module is pressed in.

When 32 protected outputs pay

Concentrated valve banks. Thirty-two coils on one slot remove a base and a rail length from the panel.

Separate group supplies. Two feeds on one module suit a machine with two 24V branches.

Not for mixed output types. The whole card is sourcing, so a panel that also needs relay outputs still needs a 1794-OW8.

FAQ — 1794-OB32P

How many outputs has the 1794-OB32P?

Thirty-two sourcing outputs in two groups of sixteen, each with its own supply and common terminals.

What are the group current limits?

6.0 A total on channels 0...15 and 8.0 A on channels 16...31, against 14 A for the module.

Which base is required?

1794-TB32 or 1794-TB32S; the TB3 family does not support 32 points.

Are the outputs protected?

Yes, electronically protected against short circuit and overload, with automatic recovery.

What supply current does it draw?

103...273 mA from the external 10...31.2V DC supply.

What is the operating temperature?

0...55 °C, with 5.3 W maximum dissipation at 31.2V DC.


Data sources. Technical values on this page come from Rockwell publication 1794-SG002 (digital DC protected output comparison, Table 14) and 1794-DU001. Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
