Allen Bradley PLC 1794-OB16P / 1794-OB16P

China Allen Bradley PLC 1794-OB16P / 1794-OB16P supplier
Allen Bradley PLC 1794-OB16P / 1794-OB16P supplier Allen Bradley PLC 1794-OB16P / 1794-OB16P supplier Allen Bradley PLC 1794-OB16P / 1794-OB16P supplier Allen Bradley PLC 1794-OB16P / 1794-OB16P supplier Allen Bradley PLC 1794-OB16P / 1794-OB16P supplier

Large Image :  Allen Bradley PLC 1794-OB16P / 1794-OB16P

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1794-OB16P / 1794-OB16P

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $175.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1794-OB16P technical data PDF download FLEX I/O 1794-OB16P 16-Point 24V DC Protected Sourcing Output

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC I/O

The 1794-OB16P is the self-protected sixteen-point sourcing output module: short circuit, overload and over-temperature shut the affected channel down, and it returns automatically when the fault is removed.

The protection is local to the module rather than at a fuse, so a chafed cable or a failed solenoid does not take a card out of the panel — but the fault is not reported to the processor, which is the trade-off against the diagnostic version.

1794-OB8 8-point 24V DC sourcing output module IN STOCK
1794-OB8EP 8-point 2 A electronically fused sourcing output module IN STOCK
1794-OB16 16-point 24V DC sourcing output module IN STOCK
1794-OB16P 16-point protected sourcing output module IN STOCK
1794-OB16D 16-point diagnostic 24V DC output module IN STOCK
1794-OB32P 32-point protected sourcing output module IN STOCK
1794-OB16PXT 16-point protected sourcing output, extended temperature IN STOCK
1794-OB8EPXT 8-point 2 A electronically fused output, extended temperature IN STOCK
1794-OV16 16-point sinking output module IN STOCK
1794-OV16P 16-point protected sinking output module IN STOCK
1794-OV32 32-point sinking output module IN STOCK
1794-OC16 16-point 48V DC sourcing output module IN STOCK
1794-OG16 16-point 5V DC sourcing output module IN STOCK
1794-OW8 8-point isolated relay output module IN STOCK

Product Specifications 1794-OB16P (PDF)
 Application
 FLEX I/O protected digital output
 Cat Num
 1794-OB16P
 Brand Name
 Rockwell
 Outputs
 16, current, sourcing, electronically protected
 On-state voltage
 10V DC min, 24V DC nom, 31.2V DC max
 Output current
 500 mA per channel, 8 A per module
 On-state voltage drop
 0.5V DC max
 Off-state leakage
 0.5 mA max
 Surge current
 1.5 A for 50 ms, repeatable every 2 s
 Output delay
 0.5 ms off to on, 1.0 ms on to off
 External supply current
 25...75 mA
 Isolation
 50V continuous; tested 2121V DC for 60 s
 Power dissipation
 5.0 W max at 31.2V DC (17.0 BTU/hr)
 Terminal base
 1794-TB2, -TB3, -TB3S, -TB3K, -TB3SK

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1794-DU001 (module specifications) and 1794-SG002 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1794-OB16P original product photograph, wide view 1794-OB16P original product photograph, wide view 1794-OB16P original product photograph, wide view

Protection behaviour

Electronic protection acts on the output itself — short circuit, overload or over-temperature — and recovery is automatic once the fault clears.

<No fault status reaches the processor. The indication is the channel LED and the symptom; diagnosis relies on the program or a meter.

1.5 A surge for 50 ms every 2 s is lower than the unprotected 1794-OB16 because the protection circuit sets the ceiling.

Protection trips on temperature as well as current, so a blocked enclosure fan can shut outputs down before the current limit is ever reached.

Because no fault bit is reported, the program cannot tell a protection trip from a command never issued; a timer on the feedback is the usual workaround.

The 2121V DC figure is a type test on the module, not a routine panel dielectric test, and must not be applied across field terminals in service.

A fused base can still be fitted where the panel standard demands one, even though the module protects itself electronically.

Where the load is a valve with a built-in flyback diode, the protection sees a clean inductive kick; without the diode it belongs in the panel.

Ratings

500 mA per channel, 8 A per module over 10...31.2V DC, 1.0 mA minimum load, 0.5 mA maximum off-state leakage.

0.5V DC maximum drop and 0.5 ms / 1.0 ms delays are identical to the unprotected module, so a substitution does not change timing.

25...75 mA from the external supply is higher than the unprotected card because the protection circuitry has its own quiescent draw.

Isolation and thermal

2121V DC for 60 s type tested, at 50V continuous basic insulation, field side to system — a higher test level than the unprotected module's 850V DC.

5.0 W maximum dissipation (17.0 BTU/hr) at 31.2V DC, marginally less than the 5.3 W of the unprotected version.

-20...55 °C operating. The XT variant, 1794-OB16PXT, extends this to -20...70 °C with conformal coating.

Bases and wiring

TB2 or the TB3 family carries the module; the base decides the terminal style, not the electrical behaviour.

Field supply on row C, outputs on row B. With sixteen channels the return current is shared, so a single return terminal is normal.

No external fuse is needed for protection, though a fused base can still be used where the panel standard requires it.

When the P version is the right buy

Inductive field loads. Brake and valve coils are the usual cause of a failed output channel; self-protection keeps the card in service.

Maintenance without spares analysis. The channel comes back when the fault clears, so a field repair does not always need a new module.

Not when the fault must be logged. If the process needs to know a channel tripped, the 1794-OB16D reports it.

FAQ — 1794-OB16P

What protection does the 1794-OB16P provide?

Electronic protection against short circuit, overload and over-temperature, with automatic recovery when the fault is removed.

Does it report the fault to the processor?

No. Fault indication is the channel LED only; the 1794-OB16D is the diagnostic module that reports.

Can each output carry 500 mA?

Yes, with 8 A per module maximum, over 10...31.2V DC.

Is an external fuse still needed?

Not for protection; external fusing is a panel standard decision, not a module requirement.

What is its isolation test level?

Type tested at 2121V DC for 60 s between field side and system, at 50V continuous basic insulation.

Does it come in an extended temperature version?

Yes, the 1794-OB16PXT, rated -20...70 °C with conformal coating.


Data sources. Technical values on this page come from Rockwell publication 1794-SG002 (digital DC protected output comparison, Table 14) and 1794-DU001. Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
