Allen Bradley PLC 1794-AENTR / 1794AENTR

China Allen Bradley PLC 1794-AENTR / 1794AENTR supplier
Allen Bradley PLC 1794-AENTR / 1794AENTR supplier Allen Bradley PLC 1794-AENTR / 1794AENTR supplier Allen Bradley PLC 1794-AENTR / 1794AENTR supplier Allen Bradley PLC 1794-AENTR / 1794AENTR supplier Allen Bradley PLC 1794-AENTR / 1794AENTR supplier

Large Image :  Allen Bradley PLC 1794-AENTR / 1794AENTR

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1794-AENTR / 1794AENTR

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $345.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1794-AENTR technical data PDF download FLEX I/O 1794-AENTR / 1794AENTR Dual-Port EtherNet/IP Adapter

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC I/O

The 1794-AENTR adds a second RJ45 port to the FLEX I/O EtherNet/IP adapter, so the island can sit on a redundant media ring instead of a single star link.

Both ports are Category 5 RJ45 on the underside of the module, and the redundancy is in the network design — the adapter presents one node to the controller either way.

1794-AENT EtherNet/IP adapter, single RJ45, 8 modules IN STOCK
1794-AENTR dual-port EtherNet/IP adapter, redundancy capable IN STOCK
1794-AENTRXT dual-port EtherNet/IP adapter, extended temperature IN STOCK
1794-ACN15 ControlNet adapter, 15 Mbps, 8 modules IN STOCK
1794-ACN15K ControlNet adapter, 15 Mbps, conformal coated IN STOCK
1794-ACNR ControlNet adapter with redundant media IN STOCK
1794-ACNR15XT ControlNet adapter, redundant media, extended temperature IN STOCK
1794-ACN ControlNet adapter module, 8 modules IN STOCK
1794-ADN DeviceNet adapter, 8 modules IN STOCK
1794-ADNK DeviceNet adapter, conformal coated IN STOCK
1794-APB Profibus DP adapter, 8 modules IN STOCK
1794-APBDPV1 Profibus DP-V1 adapter, 8 modules IN STOCK
1794-ASB Remote I/O adapter, 8 modules IN STOCK
1794-ASB2 Remote I/O adapter, extended functionality IN STOCK
1794-ASBLT Remote I/O adapter with built-in termination IN STOCK

Product Specifications 1794-AENTR (PDF)
 Application
 FLEX I/O dual-port EtherNet/IP adapter
 Cat Num
 1794-AENTR
 Brand Name
 Rockwell
 I/O module capacity
 8 modules
 Ethernet connectors
 2 x RJ45 Category 5
 Communication rate
 10/100 Mbps
 Input voltage
 24V DC nom, 19.2...31.2V DC range
 Inrush current
 18 A for 2 ms
 Flexbus output
 640 mA at 5V DC
 Power consumption, max
 500 mA at 24V DC
 Operating temperature
 0...55 deg C

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1794-DU001 (module specifications) and 1794-SG002 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1794-AENTR original product photograph, wide view 1794-AENTR original product photograph, wide view 1794-AENTR original product photograph, wide view

Two ports, one node

2 Ethernet RJ45 Category 5 connectors, labelled link 1 and link 2 with yellow/green indicators.

The second cable is described as the redundant Ethernet network cable, connecting to the second RJ45.

One adapter, one IP address, with 8 modules of I/O behind it.

Media redundancy is a network-level property, not a second controller connection.

Power

18 A inrush for 2 ms, which is why the 24V supply has to tolerate a capacitive load.

500 mA at 24V DC maximum consumption, against 440 mA on the single-port adapter.

<640 mA of 5V Flexbus output for the modules behind it.

19.2...31.2V DC input range including 5 percent ripple.

Isolation and thermal

50V continuous isolation, tested at 1000V AC for 60 s between power, Flexbus and EtherNet/IP.

7.1 W dissipation at 19.2V DC and 24.2 BTU/hr, the figures for enclosure sizing.

T5 temperature code for 1794-AENTR, with Ex ec IIC T5 Gc protection in Zone 2.

87 x 94 x 92 mm, 227 g, larger than the single-port part because of the second connector.

Application

Redundant media rings where a single cable failure must not drop the island.

<<Process areas with critical I/O and a documented network redundancy requirement.

Not the extended range; the 1794-AENTRXT runs -25...70 deg C.

Not a controller platform; the adapter is an I/O node only.

Where it fits

Dual-port islands on EtherNet/IP with device-level ring topologies.

Panels standardised on the FLEX I/O adapter family.

Not for 16 modules; the capacity is 8 per adapter.

Not for ControlNet media.

FAQ — 1794-AENTR

How many ports has the 1794-AENTR?

Two RJ45 Category 5 Ethernet ports.

What is the inrush current?

18 A for 2 ms.

How many modules can it carry?

8 FLEX I/O modules.

What is the power consumption?

500 mA at 24V DC maximum.

What is the isolation rating?

50V continuous, tested at 1000V AC for 60 s.

What is the operating temperature?

0...55 deg C, T5 temperature code.


Data sources. Technical values on this page come from Rockwell publication 1794-IN131 (FLEX I/O Dual Port EtherNet/IP Adapter Modules). Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
