Allen Bradley PLC 1794-OG16 / 1794-OG16

China Allen Bradley PLC 1794-OG16 / 1794-OG16 supplier
Allen Bradley PLC 1794-OG16 / 1794-OG16 supplier Allen Bradley PLC 1794-OG16 / 1794-OG16 supplier Allen Bradley PLC 1794-OG16 / 1794-OG16 supplier Allen Bradley PLC 1794-OG16 / 1794-OG16 supplier Allen Bradley PLC 1794-OG16 / 1794-OG16 supplier

Large Image :  Allen Bradley PLC 1794-OG16 / 1794-OG16

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1794-OG16 / 1794-OG16

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $165.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1794-OG16 technical data PDF download FLEX I/O 1794-OG16 / 1794OG16 16-Point 5V DC TTL Output Module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC I/O

The 1794-OG16 gives 16 TTL outputs at 24 mA per channel, for driving logic-level inputs, solid-state relays and instrument gates.

Like the input card of the same family, the logic is inverted: On is 0...0.4V DC, Off is 4.5...5.5V DC.

1794-OB8 8-point 24V DC sourcing output module IN STOCK
1794-OB8EP 8-point 2 A electronically fused sourcing output module IN STOCK
1794-OB16 16-point 24V DC sourcing output module IN STOCK
1794-OB16P 16-point protected sourcing output module IN STOCK
1794-OB16D 16-point diagnostic 24V DC output module IN STOCK
1794-OB32P 32-point protected sourcing output module IN STOCK
1794-OB16PXT 16-point protected sourcing output, extended temperature IN STOCK
1794-OB8EPXT 8-point 2 A electronically fused output, extended temperature IN STOCK
1794-OV16 16-point sinking output module IN STOCK
1794-OV16P 16-point protected sinking output module IN STOCK
1794-OV32 32-point sinking output module IN STOCK
1794-OC16 16-point 48V DC sourcing output module IN STOCK
1794-OG16 16-point 5V DC sourcing output module IN STOCK
1794-OW8 8-point isolated relay output module IN STOCK

Product Specifications 1794-OG16 (PDF)
 Application
 FLEX I/O TTL digital output
 Cat Num
 1794-OG16
 Brand Name
 Rockwell
 Number of outputs
 16, TTL
 Output voltage
 0V DC min, 0V DC nom, 0.4V DC max
 Output current
 0.15 mA min, 24 mA max per channel
 Off-state leakage
 1 mA max
 Isolation
 50V continuous, type tested 707V DC for 60 s
 Signal delay
 0.5 ms Off-to-On, 1.0 ms On-to-Off
 Flexbus current
 80 mA at 5V DC
 External supply
 4.5...5.5V DC, 100 mA at 5V DC
 Terminal base
 1794-TB3, 1794-TB3S, 1794-TB3K, 1794-TB3SK

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1794-DU001 (module specifications) and 1794-SG002 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1794-OG16 original product photograph, wide view 1794-OG16 original product photograph, wide view 1794-OG16 original product photograph, wide view

Logic polarity

On = 1 = logic low = 0...0.4V DC; Off = 0 = logic high = 4.5...5.5V DC, as printed in the publication.

A NOT instruction restores conventional polarity in the ladder program.

24 mA per channel maximum, 0.15 mA minimum, which is enough for a TTL input or an SSR gate.

1 mA off-state leakage will hold a sensitive input low, so check the driven device.

Timing and supply

0.5 ms Off-to-On and 1.0 ms On-to-Off, the values the datasheet gives rather than a range.

4.5...5.5V DC external supply, 100 mA at 5V, supplied from the same rail as the driven logic.

80 mA from the Flexbus, higher than the input card because each channel is driven.

0.8 W dissipation and 3.41 BTU/hr, negligible in a panel thermal budget.

Application

Driving TTL inputs, SSRs and small interface boards.

Test rigs that emulate logic-level signals.

Not for 24V devices; the 1794-OB16 is the 24V sourcing card.

Not for long cable runs; the 10 m cable limit applies to this family.

Installation

Capacitors of 0.01 uF, 2000V minimum, across the output wiring per the publication drawing.

I/O cable under 10 m, shielded per the wiring recommendation.

<Keyswitch position 4A, set on the terminal base before the module is seated.

16 yellow status indicators show each output state.

Where it fits

TTL-level interface islands.

Machine panels passing signals to a vision or measurement system.

Not for inductive 24V loads.

Not for AC.

FAQ — 1794-OG16

How many outputs has the 1794-OG16?

16 TTL outputs.

What is the maximum output current?

24 mA per channel.

Is the logic inverted?

Yes; On is 0...0.4V DC and Off is 4.5...5.5V DC.

What is the output delay?

0.5 ms Off-to-On and 1.0 ms On-to-Off.

What supply does it need?

4.5...5.5V DC, drawing 100 mA at 5V.

Which terminal bases are used?

1794-TB3, 1794-TB3S, 1794-TB3K and 1794-TB3SK.


Data sources. Technical values on this page come from Rockwell publication 1794-IN119 (FLEX I/O 5V DC TTL Digital Input and Output Modules). Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
