The 1734-IE8C packs eight 4...20 mA inputs into one 12 mm POINT I/O slice - eight channels where the 1734-IE2C gives two - at the same 16-bit resolution over 0...21 mA and the same 60 ohm input impedance.
The density costs speed: the eight channels share one converter, so the module update is 400 ms at the default 60 Hz notch and 480 ms at 50 Hz, against 100 ms for a two-channel module. That single number decides whether IE8C belongs on a tank farm or on a fast pressure loop.
| 1734-IE2C | 2 analog current inputs, 4...20 mA, 16 bits over 0...21 mA, 60 ohm | IN STOCK |
| 1734-IE2V | 2 analog voltage inputs, 0...10V or +/-10V, 15 bits plus sign, 100 kOhm | IN STOCK |
| 1734-IE4S | 4 analog inputs, 0...20 mA / 0...10V, 16 bits, isolated | IN STOCK |
| 1734-IE8C | 8 analog current inputs, 4...20 mA, 16 bits | IN STOCK |
Number of inputs |
8 single-ended, non-isolated, current |
Resolution |
16 bits over 0...21 mA, 0.32 uA/count |
Input current range |
4...20 mA or 0...20 mA |
Input impedance |
60 ohm |
Absolute accuracy |
0.1% full scale @ 25 °C, including offset, gain, non-linearity and repeatability |
Accuracy drift with temperature |
30 ppm/deg C |
Input update rate, per module |
480 ms @ 50 Hz, 400 ms @ 60 Hz (default), 240 ms @ 100 Hz, 200 ms @ 120 Hz, 120 ms @ 200 Hz, 100 ms @ 240 Hz, 80 ms @ 300 Hz, 60 ms @ 400 Hz, 50 ms @ 480 Hz |
Step response, per channel |
60 ms @ 50 Hz, 50 ms @ 60 Hz, 30 ms @ 100 Hz, 25 ms @ 120 Hz, 15 ms @ 200 Hz, 12.5 ms @ 240 Hz, 10 ms @ 300 Hz, 7.5 ms @ 400 Hz, 6.25 ms @ 480 Hz |
Normal mode rejection |
60 dB with 15.7 Hz notch at 60 Hz setting |
Maximum overload |
Fault protected to 28.8V DC |
Isolation voltage |
50V, tested 1500V AC for 60 s, inputs and field power to system; no isolation between inputs or inputs to field power |
POINTBus current, max |
75 mA |
Power dissipation, max |
0.6 W @ 28.8V DC |
Thermal dissipation, max |
2.0 BTU/hr @ 28.8V DC |
Field power input |
10...28.8V DC, 30 mA, Class 2 |
Terminal base |
1734-TB, 1734-TBS, 1734-TOP or 1734-TOPS |
Wire size |
0.25...2.5 mm2 (22...14 AWG) shielded copper rated 100 °C or greater, 1.2 mm insulation max |
Wiring category |
2 - on signal ports, 1 - on power ports |
Dimensions, HxWxD |
56.0 x 12.0 x 75.5 mm |
Weight, approx |
36 g |
Operating temperature |
-20...55 °C |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1734-SG001 (module specifications) and 1734-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
All eight inputs are single-ended and non-isolated and share one common, and the update rate is per module, not per channel: 400 ms at 60 Hz means every channel is refreshed every 400 ms. Two 1734-IE2C modules give four channels at 100 ms each for similar cost, so choose density only when the process is genuinely slow.
The 60 Hz default rejects 15.7 Hz normal-mode with a 50 ms step response. Raising the notch to 480 Hz cuts the update to 50 ms per module with a 6.25 ms step response - a 8x speed improvement, at the cost of accepting more mains-borne noise. The notch and the update rate are one decision, not two.
Field to system is 50V continuous, tested at 1500V AC for 60 s - an AC test voltage, unlike the 2550V DC figure on 1734-IE2C. There is no isolation between the eight inputs or between inputs and field power, so a grounded transmitter on channel 3 and a floating one on channel 5 cannot coexist without an external isolator.
Inputs are fault protected to 28.8V DC, so a mis-wired 24V supply on a current input will not destroy the channel. Field power is 10...28.8V DC at 30 mA Class 2 for the transmitters, and conductors must be shielded copper rated 100 °C - higher than the 75 °C of the two-channel modules.
36 g and 12 mm wide for eight loops is roughly a quarter of the panel space of four two-channel modules, and the 0.6 W dissipation is the same as a two-channel slice. The trade is that a single module failure takes eight loops offline, which is worth stating in a redundancy review.
What is the update rate of 1734-IE8C?
400 ms per module at the default 60 Hz notch and 480 ms at 50 Hz. The rate is per module, not per channel, because eight channels share one converter - 50 ms only at the 480 Hz notch.
How many inputs and what resolution?
Eight single-ended non-isolated current inputs, 16 bits over 0...21 mA, 0.32 uA per count, 4...20 mA or 0...20 mA, with 60 ohm input impedance.
Are the channels isolated from each other?
No. Field to system isolation is 50V continuous, tested at 1500V AC for 60 s, and there is no isolation between inputs or between inputs and field power.
Can 1734-IE8C replace two 1734-IE2C modules?
Only if 400 ms per module is fast enough. Eight channels at 400 ms are slower than four channels at 100 ms, and one module failure removes eight loops at once instead of two.
What wire and base are required?
1734-TB, 1734-TBS, 1734-TOP or 1734-TOPS, with shielded 0.25...2.5 mm2 (22...14 AWG) copper rated 100 deg C or greater and 1.2 mm maximum insulation.
