Allen Bradley PLC 1734-IB4 / 1734IB4

China Allen Bradley PLC 1734-IB4 / 1734IB4 supplier
Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier Allen Bradley PLC 1734-IB4 / 1734IB4 supplier

Large Image :  Allen Bradley PLC 1734-IB4 / 1734IB4

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1734-IB4 / 1734IB4

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $30.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 5 PCS
Detailed Product Description

1734-IB4 technical data PDF download POINT I/O 1734-IB4 / 1734IB4 4-Point 24V DC Sink Input Module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: POINT I/O Digital Input

The 1734-IB4 is the four-channel POINT I/O Series C sink input module. All four points sit in one common group on a single 12 mm slice, which is the usual choice for a station that needs a small cluster of sensors: four proximity switches on a transfer, four limit switches on a fixture, or the feedback set of a two-position valve.

It produces one byte of input data, consumes nothing, and shares the same electrical window as the other Series C sink inputs: 10...28.8V DC on-state, 5V DC maximum off-state, 4 mA typical on current.

1734-IB2 2 sinking 24V DC inputs, one group of 2, 30.9 g IN STOCK
1734-IB4 4 sinking 24V DC inputs, one group of 4, 31.8 g IN STOCK
1734-IB8 8 sinking 24V DC inputs, one group of 8, 32.3 g IN STOCK

Product Specifications 1734-IB4 (PDF)
 On-state voltage, min
 10V DC
 On-state voltage, nominal
 24V DC
 On-state voltage, max
 28.8V DC
 On-state current, min
 2 mA
 On-state current, nominal
 4 mA @ 24V DC
 On-state current, max
 5 mA
 Off-state voltage, max
 5V DC
 Off-state current, min
 1.5 mA
 Input impedance, nominal
 3.6 kΩ
 Input impedance, max
 4.7 kΩ
 Input filter time
 0.5 ms hardware plus 0...63 ms, user-selectable, both directions
 POINTBus current, max
 75 mA @ 5V DC
 Isolation voltage
 50V (continuous), Reinforced Insulation, tested 2500V DC for 60 s, field side to system
 Field power supply, nominal
 24V DC
 Field power voltage range
 10...28.8V DC
 Dimensions, HxWxD
 56 x 12 x 75.5 mm
 Terminal base screw torque
 0.8 Nm (7 lb-in)
 Mounting base
 1734-TB or 1734-TBS wiring base assembly
 Keyswitch position
 1
 Temperature code
 T4A (North American), T4 (IEC)
 Operating temperature
 -20...55 °C
 Enclosure
 None (open style)
 Inputs per module
 4 (1 group of 4), sinking
 Power dissipation, max @ 28.8V DC
 1.0 W @ 28.8V DC
 Thermal dissipation, max @ 28.8V DC
 3.4 BTU/hr @ 28.8V DC
 Input status indicators
 4, yellow, logic side
 Weight, approx
 31.8 g

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1734-IN051H-EN-E (module specifications) and 1734-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1734-IB4 original product photograph, wide view 1734-IB4 original product photograph, label view 1734-IB4 original product photograph, second unit

Density and heat

A 1734-IB4 draws 75 mA at 5V DC from POINTBus and dissipates 1.0 W at 28.8V DC, or 3.4 BTU/hr. That is a third of the thermal load of an eight-point slice, so a cabinet that is already tight on adapter power budget can add two four-point modules for close to the heat of one eight-point module while keeping the point count the same.

Terminal assignment

Terminals 0 to 3 are inputs 0 to 3, terminal 4 and 5 are common, and terminals 6 and 7 are user supply. A 2-wire sinking sensor returns to the common terminal and a 3-wire sensor takes its supply from 6 or 7. Because the four points share one common group, keep the field devices on a common reference - a mixed-source cluster will defeat the shared common.

Filter and timestamp behaviour

Both directions use 0.5 ms hardware filtering, and a per-module 0...63 ms software filter can be added. Sequence-of-events work benefits from leaving the software filter at zero and letting the controller timestamp the byte, while mechanical contacts benefit from 4 to 10 ms of software filtering to suppress bounce.

What the LEDs tell you

Four yellow indicators show each point, one module status LED and one network status LED report the slice. Flashing green means the module is online but not yet configured, solid green means the connection is established. Per-point diagnostics are not available on this module.

Choosing between IB2, IB4 and IB8

The three modules differ only in point count, POINTBus current is the same 75 mA, and the dissipation scales with the count. Choose the smallest module that covers the station so spare points do not consume adapter power and cabinet heat without being used.

FAQ — 1734-IB4

Does the 1734-IB4 consume output data from the scanner?

No. The module produces one byte of input data (scanner Rx) and consumes no I/O data (scanner Tx), so the adapter's output image is not used by this module.

What is the input filter time and can it be changed?

0.5 ms of hardware filtering applies in both directions, plus a user-selectable 0...63 ms software filter. The default configuration uses the hardware filter only, so set the software value in the module's configuration when contact bounce or noise is present.

Which terminal base does the 1734-IB4 need?

It mounts on a 1734-TB or 1734-TBS wiring base assembly with a removable terminal block. Terminal base screw torque is 0.8 Nm (7 lb-in).

Can I use 2-wire and 3-wire proximity switches?

Yes. Sink inputs accept 2-wire and 3-wire sinking devices; on 3-wire switches connect the common to terminal 4 (1734-IB2/IB4) and take 12/24V DC from the internal power bus or from terminals 6/7.

What field voltage range can the inputs tolerate?

Field power is 24V DC nominal and the published range is 10...28.8V DC. On-state voltage is 10V DC minimum, 24V DC nominal and 28.8V DC maximum; off-state voltage must stay at or below 5V DC.

How much current does a 1734-IB4 draw from the adapter?

75 mA at 5V DC maximum on POINTBus. Dissipation is 1.0 W and 3.4 BTU/hr at 28.8V DC.


Data sources. Technical values on this page come from Rockwell publication 1734-IN051H-EN-E (POINT I/O Input Modules, catalog numbers 1734-IB2, 1734-IB4, 1734-IB8, Series C) and 1734-UM001 (POINT I/O Digital and Analog Modules User Manual). Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
