Allen Bradley PLC 1734-EP24DC / 1734EP24DC

China Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier
Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier Allen Bradley PLC 1734-EP24DC / 1734EP24DC supplier

Large Image :  Allen Bradley PLC 1734-EP24DC / 1734EP24DC

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: Manufacturer Warranty on all factory pre-ordered products
Model Number: Allen Bradley AB 1734-EP24DC 24V DC Power/Bus Extension Module

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $75.00-$81.00 (USD/PCS)
Packaging Details: All goods we supply are 100% original factory sealed with 1 year warranty!
Delivery Time: Ships within 24 Hours
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 25 PCS 1-2 Business Days
Detailed Product Description

1734-EP24DC technical data PDF download POINT I/O 1734-EP24DC / 1734EP24DC 24V DC Power Supply

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: POINT I/O expansion power supply

The 1734-EP24DC is the 24V DC expansion supply: it takes 24V DC in, generates the 5V POINTBus for 4 to 17 modules to its right, and starts a new field power segment for them at the same time.

The reason it exists is a hard ceiling. A single 1734 adapter or 1734-PDN supplies 1.3 A of POINTBus current and 63 modules total; past that, the rack needs another supply, and the EP24DC is what the 24V DC side uses to get there.

1734-AENT EtherNet/IP adapter, 10/100 Mbit, 63 modules, 1.0 A POINTBus IN STOCK
1734-ADN DeviceNet adapter, 125/250/500 kbit, 63 modules IN STOCK
1734-ADNX DeviceNet adapter with Subnet scanner, node 0 on the subnet IN STOCK
1734-ACNR ControlNet adapter, redundant coax A/B, node 01...99 IN STOCK
1734-APB PROFIBUS DP adapter, 63 modules on one DP node IN STOCK
1734-PDN DeviceNet communication interface, 24V DC 400 mA, 1.3 A POINTBus IN STOCK
1734-EP24DC 24V DC expansion power supply, 1.3 A POINTBus at 19.2...28.8V input IN STOCK
1734-EPAC 120/240V AC expansion power supply, 1.3 A POINTBus, 3250V DC isolation IN STOCK
1734-FPD Field potential distributor, breaks the field power bus, no current draw IN STOCK
1734-ARM Address reserve module, 75 mA POINTBus, keeps a slot addressed IN STOCK

Product Specifications 1734-EP24DC (PDF)
 Input voltage rating
 24V DC nominal, 10...28.8V DC range
 POINTBus output, horizontal mounting
 1 A @ 10...19.2V input; 1.3 A @ 19.2...28.8V input
 POINTBus output, vertical mounting
 1 A @ 10...28.8V input
 I/O module capacity
 4...17 modules, depending on the current rating of each module
 Field side power requirement
 24V DC @ 400 mA max (28.8V DC maximum)
 Inrush current, max
 6 A for 10 ms
 Power consumption, max
 9.8 W @ 28.8V DC
 Power dissipation, max
 3.0 W @ 28.8V DC
 Thermal dissipation, max
 10.0 BTU/hr @ 28.8V DC
 Isolation voltage
 50V continuous, tested at 2600V DC for 60 s
 Field power bus
 10 A max, 10...28.8V DC
 Module location
 Between I/O modules, breaks the field power bus
 Dimensions, HxWxD
 76.2 x 25.4 x 133.4 mm
 Weight, approx
 120 g
 Wire size
 0.324...2.08 mm2 (22...14 AWG), 75 deg C or greater
 Terminal base screw torque
 0.6 Nm (7 lb-in)

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1734-IN058 (module specifications) and 1734-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1734-EP24DC original product photograph 1734-EP24DC original product photograph, second view 1734-EP24DC original product photograph, third view

The derating that catches people out

1.3 A only above 19.2V input, and only on horizontal DIN rail. At 10...19.2V input, or vertically mounted at any voltage, the output is 1 A. On a 24V rail that sits at 20V or dips during a brownout, the module count drops from 17 to 13 at 75 mA per slice.

Two partitions in one module

Field power to the left is separated from field power to the right, so inputs and outputs, or analog and digital, can run from different supplies. The field side draws 400 mA maximum at 28.8V DC - that is the supply's own field-side requirement, not the load current of the field devices.

Wiring is 6/7, 4/5, 2/3

+V DC on terminals 6 and 7, -V DC on 4 and 5, chassis ground on 2 and 3 - each pair repeated for daisy-chaining the supply to the next segment. Never connect 120/240V AC to this module; that is the 1734-EPAC's job.

3.0 W inside the cabinet

9.8 W consumption and 3.0 W dissipation at 28.8V DC, 10 BTU/hr. In a sealed enclosure that is the number to add when summing the thermal load; the AC version dissipates more than twice as much.

FAQ — 1734-EP24DC

How much POINTBus current does 1734-EP24DC provide?

1.3 A at 19.2...28.8V input and 1 A at 10...19.2V input, horizontal mounting; 1 A at 10...28.8V input when mounted vertically.

How many I/O modules can it support?

4 to 17, depending on each module's POINTBus current - 17 only with 75 mA slices at 19.2V or above.

Can 120/240V AC be connected to it?

No. The EP24DC takes 24V DC only; use the 1734-EPAC for AC field power.

What current does the field side draw?

400 mA maximum at 28.8V DC, with 6 A inrush for 10 ms.

What isolation and dissipation does it have?

50V continuous isolation tested at 2600V DC for 60 s, with 3.0 W dissipation and 10 BTU/hr at 28.8V DC.


Data sources. Technical values on this page come from Rockwell publication 1734-IN058 (POINT I/O 24V DC Expansion Power Supply) and 1734-UM001. Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
