Allen Bradley PLC 1769-PB2 / 1769PB2

China Allen Bradley PLC 1769-PB2 / 1769PB2 supplier
Allen Bradley PLC 1769-PB2 / 1769PB2 supplier Allen Bradley PLC 1769-PB2 / 1769PB2 supplier Allen Bradley PLC 1769-PB2 / 1769PB2 supplier Allen Bradley PLC 1769-PB2 / 1769PB2 supplier Allen Bradley PLC 1769-PB2 / 1769PB2 supplier

Large Image :  Allen Bradley PLC 1769-PB2 / 1769PB2

Product Details:

Place of Origin: Made in MALAYSIA
Brand Name: Rockwell
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1769-PB2 / 1769PB2

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $157.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1769-PB2 technical data PDF download 1769-PB2 / 1769PB2 Compact I/O 24V DC Power Supply

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PLC Power Supply

The 1769-PB2 is the 2 A DC power supply for a 1769 Compact I/O bank: 19.2...31.2V DC input, 2.0 A at 5V and 0.7 A at 24V out, 50VA drawn at 24V DC, 7.5 W dissipated at 60 °C.

It is the supply for panels that already run on 24V DC — no mains inside the enclosure — and it is one of the two 1769 supplies carrying ATEX and IECEx Zone 2 approval, which is the reason a hazardous-area bank specifies PB rather than PA.

1769-IA16 Compact 16-point 120V AC input module IN STOCK
1769-IQ16 Compact 16-point 24V DC sink/source input module IN STOCK
1769-IQ32 Compact 32-point 24V DC sink/source input module IN STOCK
1769-OA16 Compact 16-point 120/240V AC output module IN STOCK
1769-OB16 Compact 16-point 24V DC output module IN STOCK
1769-OB32 Compact 32-point 24V DC output module IN STOCK
1769-OW16 Compact 16-point relay output module IN STOCK
1769-IF4 Compact 4-channel analog input module IN STOCK
1769-IF8 Compact 8-channel analog input module IN STOCK
1769-IF16C Compact 16-channel current input module IN STOCK
1769-OF4 Compact 4-channel analog output module IN STOCK
1769-OF8V Compact 8-channel voltage output module IN STOCK
1769-OF8C Compact 8-channel current output module IN STOCK
1769-ARM Compact address reserve module IN STOCK

Product Specifications 1769-PB2 (PDF)
 Application
 Compact I/O bank power supply
 Cat Num
 1769-PB2
 Brand Name
 Rockwell
 Input voltage range
 19.2...31.2V DC
 Input voltage, nom
 24V DC
 Power consumption
 50VA @ 24V DC
 Current capacity @ 5V
 2.0 A
 Current capacity @ 24V
 0.7 A
 Power dissipation
 7.5 W @ 60 °C (140 °F)
 Inrush current, max
 30 A @ 31.2V DC
 Isolation voltage
 75V continuous, reinforced insulation
 Weight, approx
 525 g (1.16 lb)
 Dimensions (H * W * D), approx
 118 * 70 * 87 mm

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1769-TD006 (module specifications) and 1769-SG001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1769-PB2 Compact I/O 24V DC power supply, factory packaging 1769-PB2 power supply front view with status indicators 1769-PB2 label detail showing catalog number and ratings

What the DC input buys

No mains in the panel. 19.2...31.2V DC input means the bank can sit on the same 24V source as the sensors and the controller, with no 120/230V wiring to the I/O enclosure. 50VA at 24V DC. The input power the upstream 24V supply has to reserve for this bank, at 2 A of inrush for the first milliseconds. 75V reinforced isolation. Lower than the AC supplies' 265V because the input is already a safe voltage; routine tested at 1697V DC for 1 s.

Zone 2 and the K suffix

ATEX and IECEx. The PB2 is approved as II 3 G Ex ec IIC T4 Gc to EN 60079-0 and EN 60079-7, certificate DEMKO 12 ATEX 1116807X and IECEx UL 21.0112X, for Zone 2 areas. The K variant. A catalog number ending in K denotes conformal coating; the Zone 2 approvals are published against both the plain and the K part. CCC for the DC supplies. The explosion-proof CCC rule CNCA-C23-01 is listed for the PB parts and not for the PA parts.

Output and heat

2.0 A at 5V, 0.7 A at 24V. The lowest 24V output in the family — lower than the PA2's 0.8 A — because the input is already 24V and the supply does less conversion. 7.5 W at 60 °C. Slightly under the PA2's 8 W, so the PB2 is the cooler of the two 2 A supplies. 525 g, 118 * 70 * 87 mm. Identical footprint and weight to the PA2; the two are interchangeable on the rail as far as space goes.

Bank planning with a PB2

Eight modules per side. The physical limit is the same as every other 1769 supply. Distance rating from this supply. Each module's rating counts from the bank's own supply, not from the controller down the cable. One supply per bank. A 1769-L3x controller plus two expansion cables gives three banks and therefore three supplies.

Commissioning checks

Confirm the 24V source can deliver the 50VA plus inrush without dipping below 19.2V at the supply terminals. Check the 5V and 24V module totals against 2.0 A and 0.7 A before populating the bank fully. In a Zone 2 area, quote the exact part — plain or K — that matches the certificate on the panel drawing. Keep the supply's 7.5 W in the enclosure thermal budget; the DC input removes the mains heat but not the conversion loss.

FAQ — 1769-PB2

What is the output of the 1769-PB2?

2.0 A at 5V and 0.7 A at 24V, from a 19.2...31.2V DC input drawing 50VA at 24V DC.

Is the 1769-PB2 approved for Zone 2?

Yes, as II 3 G Ex ec IIC T4 Gc to EN 60079-0 and EN 60079-7, certificates DEMKO 12 ATEX 1116807X and IECEx UL 21.0112X.

How much power does the 1769-PB2 dissipate?

7.5 W at 60 °C ambient, slightly less than the 1769-PA2's 8 W.

What is the difference between 1769-PB2 and 1769-PB4?

Output current: 2.0 A/0.7 A at 7.5 W for the PB2 against 4.0 A/1.7 A at 14.5 W for the PB4, both from 19.2...31.2V DC.

What does the K suffix mean on 1769-PB2K?

Conformal coating. The Zone 2 approvals are published for both the plain and the K catalog numbers.

Can a 1769-PB2 replace a 1769-PA2?

Only if the panel has a 24V DC source instead of mains; the footprint is identical but the input and the isolation rating differ.


Data sources. Technical values on this page come from Rockwell publication 1769-TD008 (CompactLogix Power Supplies Specifications) and 1769-IN028 (Compact I/O Expansion Power Supplies), current Rockwell Automation documents. Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
