The 2080-LC30-48AWB is the largest Micro830: twenty-eight 110 V AC inputs and twenty relay outputs.
The 48-point chassis is 230 mm wide and carries five plug-in modules, so analog, serial and a counter card can all be added without an expansion bus.
| 2080-LC10-12AWA | Micro810, 8 AC in / 4 relay out | IN STOCK |
| 2080-LC10-12QWB | Micro810, 8 DC/AC in / 4 relay out | IN STOCK |
| 2080-LC10-12QBB | Micro810, 8 DC/AC in / 4 DC source out | IN STOCK |
| 2080-LC10-12DWD | Micro810, 8 12V DC in / 4 relay out | IN STOCK |
| 2080-LC20-20AWB | Micro820, 12 AC in / 8 relay out | IN STOCK |
| 2080-LC20-20QWB | Micro820, 12 DC in / 8 relay out | IN STOCK |
| 2080-LC20-20QBB | Micro820, 12 DC in / 8 DC source out | IN STOCK |
| 2080-LC20-20AWBR | Micro820 with removable terminal blocks | IN STOCK |
| 2080-LC20-20QWBR | Micro820 with removable terminal blocks | IN STOCK |
| 2080-LC20-20QBBR | Micro820 with removable terminal blocks | IN STOCK |
| 2080-LC30-10QWB | Micro830, 6 DC/AC in / 4 relay out | IN STOCK |
| 2080-LC30-10QVB | Micro830, 6 DC/AC in / 4 DC sink out | IN STOCK |
| 2080-LC30-16AWB | Micro830, 10 AC in / 6 relay out | IN STOCK |
| 2080-LC30-16QWB | Micro830, 10 DC/AC in / 6 relay out | IN STOCK |
| 2080-LC30-16QVB | Micro830, 10 DC/AC in / 6 DC sink out | IN STOCK |
| 2080-LC30-24QWB | Micro830, 14 DC/AC in / 10 relay out | IN STOCK |
| 2080-LC30-24QVB | Micro830, 14 DC/AC in / 10 DC sink out | IN STOCK |
| 2080-LC30-24QBB | Micro830, 14 DC/AC in / 10 DC source out | IN STOCK |
| 2080-LC30-48AWB | Micro830, 28 AC in / 20 relay out | IN STOCK |
| 2080-LC30-48QWB | Micro830, 28 DC/AC in / 20 relay out | IN STOCK |
| 2080-LC30-48QVB | Micro830, 28 DC/AC in / 20 DC sink out | IN STOCK |
| 2080-LC50-24AWB | Micro850, 14 AC in / 10 relay out | IN STOCK |
| 2080-LC50-24QVB | Micro850, 14 DC/AC in / 10 DC sink out | IN STOCK |
| 2080-LC50-24QBB | Micro850, 14 DC/AC in / 10 DC source out | IN STOCK |
| 2080-LC50-48AWB | Micro850, 28 AC in / 20 relay out | IN STOCK |
| 2080-LC50-48QWB | Micro850, 28 DC/AC in / 20 relay out | IN STOCK |
| 2080-LC50-48QVB | Micro850, 28 DC/AC in / 20 DC sink out | IN STOCK |
| 2080-LC50-48QBB | Micro850, 28 DC/AC in / 20 DC source out | IN STOCK |
Catalog number |
2080-LC30-48AWB |
Family |
Micro830 brick controller |
I/O points |
48 (28 inputs, 20 relay outputs) |
Inputs |
28 inputs, 110 V AC |
Outputs |
20 relay outputs |
Supply |
24 V DC Class 2 through the optional power supply slot |
Communication |
USB 2.0 Type B programming port and RS-232/RS-485 non-isolated combo serial port |
Plug-in modules |
5 plug-in slots |
Dimensions, H x W x D |
90 x 230 x 80 mm |
Shipping weight |
See 2080-UM002 table |
Temperature rating |
-20 to 65 C (-4 to 149 F) |
Power consumption, max |
11 W |
Lifecycle |
Listed in the current Micro830 catalog table of 2080-UM002 |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 2080-UM002 (module specifications) and 2080-UM002 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
The 2080-LC30-48AWB is the largest Micro830: twenty-eight 110 V AC inputs and twenty relay outputs.
The 48-point chassis is 230 mm wide and carries five plug-in modules, so analog, serial and a counter card can all be added without an expansion bus.
It is the model for a panel that is mostly AC field devices and has no room for interposing relays.
Twenty relay outputs will run a row of contactors and solenoid valves directly.
Inputs are 110 V AC, which suits pushbuttons, floats and limit switches in a legacy AC panel.
Five plug-in slots are fitted; each module draws about 1.44 W of the internal budget.
Communication and capacity. USB 2.0 Type B programming port and RS-232/RS-485 non-isolated combo serial port
5 plug-in slots plug-in modules can be fitted, each drawing about 1.44 W of the controller's internal budget.
Connected Components Workbench is the programming environment for the whole family, so a project built for one Micro800 controller converts to another with the I/O reassigned.
Mounting is DIN rail or panel, 90 x 230 x 80 mm, shipping See 2080-UM002 table.
Rated ambient -20 to 65 C (-4 to 149 F), maximum consumption 11 W.
Lifecycle. Listed in the current Micro830 catalog table of 2080-UM002
Five plug-in slots, 11 W base consumption, 90 x 230 x 80 mm.
2080-UM002 lists this catalog with 28 inputs and 20 relay outputs.
Rockwell's Micro830 catalog table still lists this catalog number.
How many I/O points does 2080-LC30-48AWB have?
Micro830 brick controller: 48 (28 inputs, 20 relay outputs).
What is the input type on 2080-LC30-48AWB?
28 inputs, 110 V AC.
What does 2080-LC30-48AWB use for communication?
USB 2.0 Type B programming port and RS-232/RS-485 non-isolated combo serial port.
What are the dimensions of 2080-LC30-48AWB?
90 x 230 x 80 mm, See 2080-UM002 table.
What is the lifecycle status of 2080-LC30-48AWB?
Listed in the current Micro830 catalog table of 2080-UM002.
