2080-OF2 is a 2-channel analog output plug-in in the Bulletin 2080 Micro800 plug-in family. It gives a controller two analog references, typically a variable speed drive speed reference and a proportional valve command.
A plug-in module snaps into a slot on the controller itself, so the I/O count grows without adding a DIN rail footprint or an expansion bus module.
| 2080-IF2 | 2-channel analog input plug-in | IN STOCK |
| 2080-IF4 | 4-channel analog input plug-in | IN STOCK |
| 2080-OF2 | 2-channel analog output plug-in | IN STOCK |
| 2080-TC2 | 2-channel thermocouple plug-in | IN STOCK |
| 2080-RTD2 | 2-channel RTD plug-in | IN STOCK |
| 2080-TRIMPOT6 | 6-channel trimpot analog input | IN STOCK |
| 2080-OB4 | 4-point DC source output plug-in | IN STOCK |
| 2080-OV4 | 4-point DC sink output plug-in | IN STOCK |
| 2080-OW4I | 4-point relay output plug-in | IN STOCK |
| 2080-IQ4OV4 | 8-point combo, 4 in / 4 out sink | IN STOCK |
| 2080-IQ4OB4 | 8-point combo, 4 in / 4 out source | IN STOCK |
| 2080-SERIALISOL | isolated RS-232/RS-485 serial plug-in | IN STOCK |
| 2080-MOT-HSC | high-speed counter plug-in | IN STOCK |
| 2080-MEMBAK-RTC | memory backup with real-time clock | IN STOCK |
| 2080-USBADAPTER | Micro810 USB adapter | IN STOCK |
| 2080-LCD | Micro810 LCD display with keypad | IN STOCK |
| 2080-REMLCD | Micro820 remote LCD display | IN STOCK |
| 2080-PS120-240VAC | 120/240 V AC to 24 V DC power supply | IN STOCK |
Catalog number |
2080-OF2 |
Product type |
2-channel analog output plug-in |
Channels / points |
2 channels |
Signal |
0-10 V DC, 0-20 mA, unipolar |
Isolation |
Non-isolated |
Resolution |
12-bit |
Controller compatibility |
Micro820, Micro830 and Micro850 plug-in slots; not supported on Micro810 |
Dimensions, H x W x D |
Per 2080-WD004 |
Temperature rating |
Per 2080-UM004 |
Lifecycle status |
Active |
UPC |
Not published |
Country of origin |
Not published |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 2080-WD004 (module specifications) and 2080-UM004 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
2080-OF2 is a 2-channel analog output plug-in in the Bulletin 2080 Micro800 plug-in family. It gives a controller two analog references, typically a variable speed drive speed reference and a proportional valve command.
A plug-in module snaps into a slot on the controller itself, so the I/O count grows without adding a DIN rail footprint or an expansion bus module.
Channel count and signal type are fixed by the catalog number: 2 channels, 0-10 V DC, 0-20 mA, unipolar.
Micro820, Micro830 and Micro850 plug-in slots; not supported on Micro810
The module is configured in Connected Components Workbench, not by a hardware switch, so the project file has to match the module that is physically fitted.
Micro810 controllers have no plug-in slots at all; the Micro810 accessories take the USB or display port instead.
The module uses an 8-pin terminal block; pin A1 to A4 are the common returns and B1 to B4 carry VO-0, CO-0, VO-1 and CO-1.
Every plug-in in this family is rated for the same panel environment, and the terminal block is the part that decides whether a swap is quick or not.
Isolation is Non-isolated. Where that matters, it is stated per model rather than assumed for the whole family.
Rockwell lists this catalog number as Active.
Dimensions are Per 2080-WD004, rated ambient Per 2080-UM004.
UPC is Not published, country of origin Not published.
A used plug-in is only worth fitting if the terminal block and the retaining clips are intact; the clips are what holds the module against vibration.
Match the catalog number exactly. The family contains pairs that differ only in sink versus source output or isolation, and the front label is the only reliable identifier once the box is gone.
Output range is selected in software. A drive reference wired to a voltage output will not work if the channel is configured for current.
What does 2080-OF2 do?
2-channel analog output plug-in: 2 channels, 0-10 V DC, 0-20 mA, unipolar.
Which controllers accept 2080-OF2?
Micro820, Micro830 and Micro850 plug-in slots; not supported on Micro810
What is the resolution of 2080-OF2?
12-bit.
What are the dimensions of 2080-OF2?
Per 2080-WD004, rated Per 2080-UM004.
Is 2080-OF2 still available from Rockwell?
Rockwell lists it as Active.
