Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB

China Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier
Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB supplier

Large Image :  Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley Micro850 2080-LC50-48AWB / 2080LC5048AWB

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $478.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: T/T, Paypal and Western Union.
Supply Ability: 5 PCS
Detailed Product Description

2080-LC50-48AWB technical data PDF download 2080-LC50-48AWB Rockwell Micro850 48 Point Ethernet Controller

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: Micro800 2080 plug-in modules

The 2080-LC50-48AWB is the 48-point Micro850 with 120 V AC inputs and twenty relay outputs.

At 238 mm wide it takes five plug-in slots and still accepts four expansion modules, so the point count can go well past the embedded 48.

2080-LC10-12AWA Micro810, 8 AC in / 4 relay out IN STOCK
2080-LC10-12QWB Micro810, 8 DC/AC in / 4 relay out IN STOCK
2080-LC10-12QBB Micro810, 8 DC/AC in / 4 DC source out IN STOCK
2080-LC10-12DWD Micro810, 8 12V DC in / 4 relay out IN STOCK
2080-LC20-20AWB Micro820, 12 AC in / 8 relay out IN STOCK
2080-LC20-20QWB Micro820, 12 DC in / 8 relay out IN STOCK
2080-LC20-20QBB Micro820, 12 DC in / 8 DC source out IN STOCK
2080-LC20-20AWBR Micro820 with removable terminal blocks IN STOCK
2080-LC20-20QWBR Micro820 with removable terminal blocks IN STOCK
2080-LC20-20QBBR Micro820 with removable terminal blocks IN STOCK
2080-LC30-10QWB Micro830, 6 DC/AC in / 4 relay out IN STOCK
2080-LC30-10QVB Micro830, 6 DC/AC in / 4 DC sink out IN STOCK
2080-LC30-16AWB Micro830, 10 AC in / 6 relay out IN STOCK
2080-LC30-16QWB Micro830, 10 DC/AC in / 6 relay out IN STOCK
2080-LC30-16QVB Micro830, 10 DC/AC in / 6 DC sink out IN STOCK
2080-LC30-24QWB Micro830, 14 DC/AC in / 10 relay out IN STOCK
2080-LC30-24QVB Micro830, 14 DC/AC in / 10 DC sink out IN STOCK
2080-LC30-24QBB Micro830, 14 DC/AC in / 10 DC source out IN STOCK
2080-LC30-48AWB Micro830, 28 AC in / 20 relay out IN STOCK
2080-LC30-48QWB Micro830, 28 DC/AC in / 20 relay out IN STOCK
2080-LC30-48QVB Micro830, 28 DC/AC in / 20 DC sink out IN STOCK
2080-LC50-24AWB Micro850, 14 AC in / 10 relay out IN STOCK
2080-LC50-24QVB Micro850, 14 DC/AC in / 10 DC sink out IN STOCK
2080-LC50-24QBB Micro850, 14 DC/AC in / 10 DC source out IN STOCK
2080-LC50-48AWB Micro850, 28 AC in / 20 relay out IN STOCK
2080-LC50-48QWB Micro850, 28 DC/AC in / 20 relay out IN STOCK
2080-LC50-48QVB Micro850, 28 DC/AC in / 20 DC sink out IN STOCK
2080-LC50-48QBB Micro850, 28 DC/AC in / 20 DC source out IN STOCK

Product Specifications 2080-LC50-48AWB (PDF)
 Catalog number
 2080-LC50-48AWB
 Family
 Micro850 expandable Ethernet controller
 I/O points
 48 (28 inputs, 20 relay outputs)
 Inputs
 28 inputs, 120 V AC
 Outputs
 20 relay outputs, 2 A at 240 V AC and 1 A at 24 V DC
 Supply
 24 V DC Class 2, 21.4 to 26.4 V DC
 Communication
 USB 2.0 Type B, 10/100 Base-T Ethernet RJ45, RS-232/RS-485 non-isolated combo serial
 Plug-in modules
 3 slots (24-point) or 5 slots (48-point), plus up to four expansion I/O modules
 Dimensions, H x W x D
 90 x 238 x 80 mm
 Shipping weight
 0.725 kg
 Temperature rating
 -20 to 65 C (-4 to 149 F)
 Power consumption, max
 11 W without plug-ins and expansion, 33 W with
 Lifecycle
 Rockwell literature 2080-TD001 lists the 2080-L50E successor for this point count; the LC50 catalog number itself does not appear in the current revision
 Output terminals
 Relay
 Ethernet nodes
 8
 Expansion I/O
 Up to four 2085 modules
 Remote LCD
 2080-REMLCD supported from firmware 23.011

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 2080-TD001 (module specifications) and 2080-UM002 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

2080-LC50-48AWB 2080-LC50-48AWB 2080-LC50-48AWB 2080-LC50-48AWB 2080-LC50-48AWB 2080-LC50-48AWB 2080-LC50-48AWB

What this controller covers

The 2080-LC50-48AWB is the 48-point Micro850 with 120 V AC inputs and twenty relay outputs.

At 238 mm wide it takes five plug-in slots and still accepts four expansion modules, so the point count can go well past the embedded 48.

It is the model for a large AC panel that also has to appear on Ethernet.

Inputs, outputs and field wiring

Twenty relays switch contactors and valves directly; rating is 2 A at 240 V AC and 1 A at 24 V DC.

Inputs are 120 V AC at 16 mA.

Wire range is 0.2 to 2.5 square mm, 24 to 14 AWG.

Communication, plug-ins and programming

Communication and capacity. USB 2.0 Type B, 10/100 Base-T Ethernet RJ45, RS-232/RS-485 non-isolated combo serial

3 slots (24-point) or 5 slots (48-point), plus up to four expansion I/O modules plug-in modules can be fitted, each drawing about 1.44 W of the controller's internal budget.

Connected Components Workbench is the programming environment for the whole family, so a project built for one Micro800 controller converts to another with the I/O reassigned.

Dimensions, ratings and lifecycle

Mounting is DIN rail or panel, 90 x 238 x 80 mm, shipping 0.725 kg.

Rated ambient -20 to 65 C (-4 to 149 F), maximum consumption 11 W without plug-ins and expansion, 33 W with.

Lifecycle. Rockwell literature 2080-TD001 lists the 2080-L50E successor for this point count; the LC50 catalog number itself does not appear in the current revision

Buying a used Micro800 controller

Five plug-in slots, four expansion modules, eight Ethernet nodes and REMLCD support.

Rockwell's technical data lists the 2080-L50E-48AWB successor for this point count.

Supply is 24 V DC Class 2, 21.4 to 26.4 V DC.

FAQ — 2080-LC50-48AWB

How many I/O points does 2080-LC50-48AWB have?

Micro850 expandable Ethernet controller: 48 (28 inputs, 20 relay outputs).

What is the input type on 2080-LC50-48AWB?

28 inputs, 120 V AC.

What does 2080-LC50-48AWB use for communication?

USB 2.0 Type B, 10/100 Base-T Ethernet RJ45, RS-232/RS-485 non-isolated combo serial.

What are the dimensions of 2080-LC50-48AWB?

90 x 238 x 80 mm, 0.725 kg.

What is the lifecycle status of 2080-LC50-48AWB?

Rockwell literature 2080-TD001 lists the 2080-L50E successor for this point count; the LC50 catalog number itself does not appear in the current revision.


Data sources. Controller I/O counts, supply ranges, dimensions and weights come from the Micro800 technical data 2080-TD001 and the controller manual 2080-UM002. Application text is written from those tables; nothing here is estimated. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
