Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB

Customer Reviews
Welcome to PLC-VIP , Your online shop for Allen Bradley & Siemens PLC parts.

—— PLC-VIP.SHOP

We also wish to be able to continue doing good business with you and your company in the years to come. We are very thankful for that.

—— Rodrigo

I'm Online Chat Now

Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB

China Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier
Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB supplier

Large Image :  Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley Micro850 2080-LC50-48QWB / 2080LC5048QWB

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $478.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: T/T, Paypal and Western Union.
Supply Ability: 5 PCS
Detailed Product Description

2080-LC50-48QWB technical data PDF download 2080-LC50-48QWB Rockwell Micro850 48 Point Controller

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: Micro800 2080 plug-in modules

The 2080-LC50-48QWB is the DC-input 48-point Micro850 with twenty relay outputs and six embedded high-speed counters.

Relays keep the AC load list inside the controller while the inputs stay on 24 V sensors.

2080-LC10-12AWA Micro810, 8 AC in / 4 relay out IN STOCK
2080-LC10-12QWB Micro810, 8 DC/AC in / 4 relay out IN STOCK
2080-LC10-12QBB Micro810, 8 DC/AC in / 4 DC source out IN STOCK
2080-LC10-12DWD Micro810, 8 12V DC in / 4 relay out IN STOCK
2080-LC20-20AWB Micro820, 12 AC in / 8 relay out IN STOCK
2080-LC20-20QWB Micro820, 12 DC in / 8 relay out IN STOCK
2080-LC20-20QBB Micro820, 12 DC in / 8 DC source out IN STOCK
2080-LC20-20AWBR Micro820 with removable terminal blocks IN STOCK
2080-LC20-20QWBR Micro820 with removable terminal blocks IN STOCK
2080-LC20-20QBBR Micro820 with removable terminal blocks IN STOCK
2080-LC30-10QWB Micro830, 6 DC/AC in / 4 relay out IN STOCK
2080-LC30-10QVB Micro830, 6 DC/AC in / 4 DC sink out IN STOCK
2080-LC30-16AWB Micro830, 10 AC in / 6 relay out IN STOCK
2080-LC30-16QWB Micro830, 10 DC/AC in / 6 relay out IN STOCK
2080-LC30-16QVB Micro830, 10 DC/AC in / 6 DC sink out IN STOCK
2080-LC30-24QWB Micro830, 14 DC/AC in / 10 relay out IN STOCK
2080-LC30-24QVB Micro830, 14 DC/AC in / 10 DC sink out IN STOCK
2080-LC30-24QBB Micro830, 14 DC/AC in / 10 DC source out IN STOCK
2080-LC30-48AWB Micro830, 28 AC in / 20 relay out IN STOCK
2080-LC30-48QWB Micro830, 28 DC/AC in / 20 relay out IN STOCK
2080-LC30-48QVB Micro830, 28 DC/AC in / 20 DC sink out IN STOCK
2080-LC50-24AWB Micro850, 14 AC in / 10 relay out IN STOCK
2080-LC50-24QVB Micro850, 14 DC/AC in / 10 DC sink out IN STOCK
2080-LC50-24QBB Micro850, 14 DC/AC in / 10 DC source out IN STOCK
2080-LC50-48AWB Micro850, 28 AC in / 20 relay out IN STOCK
2080-LC50-48QWB Micro850, 28 DC/AC in / 20 relay out IN STOCK
2080-LC50-48QVB Micro850, 28 DC/AC in / 20 DC sink out IN STOCK
2080-LC50-48QBB Micro850, 28 DC/AC in / 20 DC source out IN STOCK

Product Specifications 2080-LC50-48QWB (PDF)
 Catalog number
 2080-LC50-48QWB
 Family
 Micro850 expandable Ethernet controller
 I/O points
 48 (28 inputs, 20 relay outputs)
 Inputs
 28 inputs, 24 V DC sink/source (standard and high-speed)
 Outputs
 20 relay outputs, 2 A at 240 V AC and 1 A at 24 V DC
 Supply
 24 V DC Class 2, 21.4 to 26.4 V DC
 Communication
 USB 2.0 Type B, 10/100 Base-T Ethernet RJ45, RS-232/RS-485 non-isolated combo serial
 Plug-in modules
 3 slots (24-point) or 5 slots (48-point), plus up to four expansion I/O modules
 Dimensions, H x W x D
 90 x 238 x 80 mm
 Shipping weight
 0.725 kg
 Temperature rating
 -20 to 65 C (-4 to 149 F)
 Power consumption, max
 11 W without plug-ins and expansion, 33 W with
 Lifecycle
 Rockwell literature 2080-TD001 lists the 2080-L50E successor for this point count; the LC50 catalog number itself does not appear in the current revision
 Output terminals
 Relay
 Ethernet nodes
 8
 Expansion I/O
 Up to four 2085 modules
 Remote LCD
 2080-REMLCD supported from firmware 23.011

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 2080-TD001 (module specifications) and 2080-UM002 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

2080-LC50-48QWB 2080-LC50-48QWB 2080-LC50-48QWB 2080-LC50-48QWB 2080-LC50-48QWB 2080-LC50-48QWB 2080-LC50-48QWB

What this controller covers

The 2080-LC50-48QWB is the DC-input 48-point Micro850 with twenty relay outputs and six embedded high-speed counters.

Relays keep the AC load list inside the controller while the inputs stay on 24 V sensors.

Five plug-in slots and four expansion modules make it the largest general-purpose configuration in the family.

Inputs, outputs and field wiring

Relay output rating is 2 A at 240 V AC and 1 A at 24 V DC per point.

Inputs are 24 V DC sink/source, standard and high-speed.

Six embedded high-speed counters are listed for the 48-point chassis.

Communication, plug-ins and programming

Communication and capacity. USB 2.0 Type B, 10/100 Base-T Ethernet RJ45, RS-232/RS-485 non-isolated combo serial

3 slots (24-point) or 5 slots (48-point), plus up to four expansion I/O modules plug-in modules can be fitted, each drawing about 1.44 W of the controller's internal budget.

Connected Components Workbench is the programming environment for the whole family, so a project built for one Micro800 controller converts to another with the I/O reassigned.

Dimensions, ratings and lifecycle

Mounting is DIN rail or panel, 90 x 238 x 80 mm, shipping 0.725 kg.

Rated ambient -20 to 65 C (-4 to 149 F), maximum consumption 11 W without plug-ins and expansion, 33 W with.

Lifecycle. Rockwell literature 2080-TD001 lists the 2080-L50E successor for this point count; the LC50 catalog number itself does not appear in the current revision

Buying a used Micro800 controller

Five plug-in slots, four expansion modules, eight Ethernet nodes.

Rockwell's technical data lists the 2080-L50E-480WB successor for this point count.

Supply is 24 V DC Class 2, 21.4 to 26.4 V DC.

FAQ — 2080-LC50-48QWB

How many I/O points does 2080-LC50-48QWB have?

Micro850 expandable Ethernet controller: 48 (28 inputs, 20 relay outputs).

What is the input type on 2080-LC50-48QWB?

28 inputs, 24 V DC sink/source (standard and high-speed).

What does 2080-LC50-48QWB use for communication?

USB 2.0 Type B, 10/100 Base-T Ethernet RJ45, RS-232/RS-485 non-isolated combo serial.

What are the dimensions of 2080-LC50-48QWB?

90 x 238 x 80 mm, 0.725 kg.

What is the lifecycle status of 2080-LC50-48QWB?

Rockwell literature 2080-TD001 lists the 2080-L50E successor for this point count; the LC50 catalog number itself does not appear in the current revision.


Data sources. Controller I/O counts, supply ranges, dimensions and weights come from the Micro800 technical data 2080-TD001 and the controller manual 2080-UM002. Application text is written from those tables; nothing here is estimated. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
