Product Details:
Payment & Shipping Terms:
|
1760-IA12XOW6I is an expansion module for the Pico range: 12, 100 to 240 V AC and 6, relay.
It adds I/O to a Pico -EX controller or to the GFX-70 processor through the Pico-Link connection.
| 1760-L12BBB | 12 I/O, 24 V DC, 8 DC in / 4 MOSFET out | IN STOCK |
| 1760-L12BWB | 12 I/O, 24 V DC, 8 DC in / 4 relay out | IN STOCK |
| 1760-L12BWB-NC | same as L12BWB without real-time clock | IN STOCK |
| 1760-L12BWB-ND | same as L12BWB without display | IN STOCK |
| 1760-L12DWD | 12 I/O, 12 V DC, 8 DC in / 4 relay out | IN STOCK |
| 1760-L18AWA-EX | 18 I/O, 120/240 V AC, expansion capable | IN STOCK |
| 1760-L18BWB-EX | 18 I/O, 24 V DC, expansion capable | IN STOCK |
| 1760-L20BBB-EX | 20 I/O, 24 V DC, 8 MOSFET out, expansion | IN STOCK |
| 1760-L20BBB-EXND | same as L20BBB-EX without display | IN STOCK |
| 1760-IA12XOW6I | expansion, 12 AC in / 6 relay out | IN STOCK |
| 1760-IB12XOW6I | expansion, 12 DC in / 6 relay out | IN STOCK |
| 1760-IB12XOB8 | expansion, 12 DC in / 8 transistor out | IN STOCK |
| 1760-IB12XOW4IF | GFX I/O, 12 DC in / 4 relay out, analog in | IN STOCK |
| 1760-IB12XOW4IOF | GFX I/O, 12 DC in / 4 relay out, analog in and out | IN STOCK |
| 1760-OW2 | expansion, 2 relay out | IN STOCK |
| 1760-CBL-INT01 | 0.3 m interface cable | IN STOCK |
| 1760-CBL-PC02 | PicoGFX programming cable | IN STOCK |
| 1760-CBL-PM02 | Pico programming cable | IN STOCK |
| 1760-DUB | PicoGFX display unit with keypad | IN STOCK |
| 1760-LDFC | PicoGFX GFX-70 processor, 24 V DC | IN STOCK |
| 1760-MM1 | memory module | IN STOCK |
| 1760-MM2B | memory module, larger | IN STOCK |
| 1760-NDC | protective cover | IN STOCK |
| 1760-PICOSOFT | PicoSoft programming software | IN STOCK |
| 1760-PICOSOFTPRO | PicoSoft Pro programming software | IN STOCK |
| 1760-SIM | I/O simulator | IN STOCK |
| 1760-TERM1 | Pico-Link termination resistors | IN STOCK |
| 1760-USB-PICO | Pico USB programming cable | IN STOCK |
Catalog number |
1760-IA12XOW6I |
Inputs |
12, 100 to 240 V AC |
Outputs |
6, relay |
Line power |
100 to 240 V AC |
Analog capability |
None |
Used with |
Pico -EX controllers and the PicoGFX GFX-70 processor |
Lifecycle |
Discontinued, 2017 |
Documentation |
1760-UM001 / 1760-UM002 |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1760-UM001 (module specifications) and 1760-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
1760-IA12XOW6I is an expansion module for the Pico range: 12, 100 to 240 V AC and 6, relay.
It adds I/O to a Pico -EX controller or to the GFX-70 processor through the Pico-Link connection.
It is the AC expansion for a Pico -EX controller, adding twelve 100 to 240 V AC inputs and six relays.
Expansion inputs are addressed R1 to R12 and outputs S1 to S8 in the circuit diagram.
Input and output data is transferred serially, so the reaction time of an expansion input is 30 ms plus one cycle, and an expansion output 15 ms plus one cycle.
Analog capability: None.
The module is supplied with its connector; 1760-RPLCONN is the replacement connector catalog number.
No programming change is needed beyond using the R and S contacts: the controller detects an expansion module by their presence.
Rockwell lists this catalog number as discontinued in the 2017 Pico withdrawal.
Every value in the table above comes from Rockwell publication 1760-UM001 or 1760-UM002, or from the Rockwell product page for this catalog number.
Where a value is not printed in those documents it is marked as not published rather than estimated.
Rockwell discontinued the Bulletin 1760 Pico and PicoGFX range on 31 March 2017; the product pages now carry a discontinuation notice and no replacement catalogue is offered for the accessories.
These parts have been out of production since 2017, so the supply is used or surplus stock rather than new distribution.
For a controller, confirm that the memory module and the programming cable are included: without the cable the unit cannot be reprogrammed, and a memory module carries the only copy of the circuit diagram on many machines.
Ask for the label photograph: the ND and NC suffixes change the display and the clock, and the catalog number on the label is the only reliable identifier.
What does 1760-IA12XOW6I add?
12, 100 to 240 V AC and 6, relay.
Which controllers accept 1760-IA12XOW6I?
Pico -EX models and the PicoGFX GFX-70 processor.
How are the inputs addressed?
R1 to R12, with outputs S1 to S8.
What is the input reaction time?
30 ms plus one cycle time.
Is 1760-IA12XOW6I still available?
No, it was discontinued in 2017.
