Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND

China Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier
Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND supplier

Large Image :  Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley 1760-L12BWB-ND / 1760L12BWB-ND

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $104.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1760-L12BWB-ND technical data PDF download 1760-L12BWB-ND Rockwell Pico 12 Point Controller, No Display

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: Pico and PicoGFX 1760 controllers

1760-L12BWB-ND is a Pico controller: a compact logic relay programmed with function blocks rather than a ladder PLC.

without a display Inputs are 8, 24 V DC and outputs are 4, relay.

1760-L12BBB 12 I/O, 24 V DC, 8 DC in / 4 MOSFET out IN STOCK
1760-L12BWB 12 I/O, 24 V DC, 8 DC in / 4 relay out IN STOCK
1760-L12BWB-NC same as L12BWB without real-time clock IN STOCK
1760-L12BWB-ND same as L12BWB without display IN STOCK
1760-L12DWD 12 I/O, 12 V DC, 8 DC in / 4 relay out IN STOCK
1760-L18AWA-EX 18 I/O, 120/240 V AC, expansion capable IN STOCK
1760-L18BWB-EX 18 I/O, 24 V DC, expansion capable IN STOCK
1760-L20BBB-EX 20 I/O, 24 V DC, 8 MOSFET out, expansion IN STOCK
1760-L20BBB-EXND same as L20BBB-EX without display IN STOCK
1760-IA12XOW6I expansion, 12 AC in / 6 relay out IN STOCK
1760-IB12XOW6I expansion, 12 DC in / 6 relay out IN STOCK
1760-IB12XOB8 expansion, 12 DC in / 8 transistor out IN STOCK
1760-IB12XOW4IF GFX I/O, 12 DC in / 4 relay out, analog in IN STOCK
1760-IB12XOW4IOF GFX I/O, 12 DC in / 4 relay out, analog in and out IN STOCK
1760-OW2 expansion, 2 relay out IN STOCK
1760-CBL-INT01 0.3 m interface cable IN STOCK
1760-CBL-PC02 PicoGFX programming cable IN STOCK
1760-CBL-PM02 Pico programming cable IN STOCK
1760-DUB PicoGFX display unit with keypad IN STOCK
1760-LDFC PicoGFX GFX-70 processor, 24 V DC IN STOCK
1760-MM1 memory module IN STOCK
1760-MM2B memory module, larger IN STOCK
1760-NDC protective cover IN STOCK
1760-PICOSOFT PicoSoft programming software IN STOCK
1760-PICOSOFTPRO PicoSoft Pro programming software IN STOCK
1760-SIM I/O simulator IN STOCK
1760-TERM1 Pico-Link termination resistors IN STOCK
1760-USB-PICO Pico USB programming cable IN STOCK

Product Specifications 1760-L12BWB-ND (PDF)
 Catalog number
 1760-L12BWB-ND
 Inputs
 8, 24 V DC
 Outputs
 4, relay
 Line power
 24 V DC
 Real-time clock
 Yes
 Display and keypad
 No
 Analog inputs
 2 (0 to 10 V DC)
 Expansion modules
 Not expansion capable (no EX suffix)
 Lifecycle
 Discontinued 31 March 2017
 Documentation
 1760-UM001

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1760-UM001 (module specifications) and 1760-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1760-L12BWB-ND 1760-L12BWB-ND 1760-L12BWB-ND 1760-L12BWB-ND 1760-L12BWB-ND 1760-L12BWB-ND 1760-L12BWB-ND

What this catalog number is

1760-L12BWB-ND is a Pico controller: a compact logic relay programmed with function blocks rather than a ladder PLC.

without a display Inputs are 8, 24 V DC and outputs are 4, relay.

The controller is powered from 24 V DC and carries its own display and keypad unless the ND suffix says otherwise.

I/O, wiring and compatibility

Pico controllers are wired on screw terminals with the inputs on the top row and the outputs on the bottom.

For AC input models the inputs must be connected to the same phase as the power feed L1, as the manual requires; otherwise the input threshold may not be reached.

Expansion: Not expansion capable (no EX suffix).

Programming, spares and lifecycle

A memory module in the interface slot holds the circuit diagram and the parameters, so a replacement controller can be loaded without a PC.

Programming is done with PicoSoft through the 1760-CBL-PM02 cable, or from the keypad on models that have a display.

Rockwell lists this catalog number as Discontinued, with a discontinuation date of 31 March 2017.

Documented data

Every value in the table above comes from Rockwell publication 1760-UM001 or 1760-UM002, or from the Rockwell product page for this catalog number.

Where a value is not printed in those documents it is marked as not published rather than estimated.

Rockwell discontinued the Bulletin 1760 Pico and PicoGFX range on 31 March 2017; the product pages now carry a discontinuation notice and no replacement catalogue is offered for the accessories.

Buying a used unit

These parts have been out of production since 2017, so the supply is used or surplus stock rather than new distribution.

For a controller, confirm that the memory module and the programming cable are included: without the cable the unit cannot be reprogrammed, and a memory module carries the only copy of the circuit diagram on many machines.

Ask for the label photograph: the ND and NC suffixes change the display and the clock, and the catalog number on the label is the only reliable identifier.

FAQ — 1760-L12BWB-ND

What is 1760-L12BWB-ND?

A Pico controller with 8, 24 V DC and 4, relay.

What supply does 1760-L12BWB-ND need?

24 V DC.

Does 1760-L12BWB-ND have a real-time clock?

Yes.

Can 1760-L12BWB-ND take expansion modules?

Not expansion capable (no EX suffix).

Is 1760-L12BWB-ND still sold by Rockwell?

No. It was discontinued on 31 March 2017.


Data sources. Pico and PicoGFX data is taken from Rockwell 1760-UM001 and 1760-UM002; accessories from the Rockwell product pages. Discontinuation date 31 March 2017 per Rockwell notice. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
