1760-L12DWD is a Pico controller: a compact logic relay programmed with function blocks rather than a ladder PLC.
for 12 V DC systems Inputs are 8, 12 V DC and outputs are 4, relay.
| 1760-L12BBB | 12 I/O, 24 V DC, 8 DC in / 4 MOSFET out | IN STOCK |
| 1760-L12BWB | 12 I/O, 24 V DC, 8 DC in / 4 relay out | IN STOCK |
| 1760-L12BWB-NC | same as L12BWB without real-time clock | IN STOCK |
| 1760-L12BWB-ND | same as L12BWB without display | IN STOCK |
| 1760-L12DWD | 12 I/O, 12 V DC, 8 DC in / 4 relay out | IN STOCK |
| 1760-L18AWA-EX | 18 I/O, 120/240 V AC, expansion capable | IN STOCK |
| 1760-L18BWB-EX | 18 I/O, 24 V DC, expansion capable | IN STOCK |
| 1760-L20BBB-EX | 20 I/O, 24 V DC, 8 MOSFET out, expansion | IN STOCK |
| 1760-L20BBB-EXND | same as L20BBB-EX without display | IN STOCK |
| 1760-IA12XOW6I | expansion, 12 AC in / 6 relay out | IN STOCK |
| 1760-IB12XOW6I | expansion, 12 DC in / 6 relay out | IN STOCK |
| 1760-IB12XOB8 | expansion, 12 DC in / 8 transistor out | IN STOCK |
| 1760-IB12XOW4IF | GFX I/O, 12 DC in / 4 relay out, analog in | IN STOCK |
| 1760-IB12XOW4IOF | GFX I/O, 12 DC in / 4 relay out, analog in and out | IN STOCK |
| 1760-OW2 | expansion, 2 relay out | IN STOCK |
| 1760-CBL-INT01 | 0.3 m interface cable | IN STOCK |
| 1760-CBL-PC02 | PicoGFX programming cable | IN STOCK |
| 1760-CBL-PM02 | Pico programming cable | IN STOCK |
| 1760-DUB | PicoGFX display unit with keypad | IN STOCK |
| 1760-LDFC | PicoGFX GFX-70 processor, 24 V DC | IN STOCK |
| 1760-MM1 | memory module | IN STOCK |
| 1760-MM2B | memory module, larger | IN STOCK |
| 1760-NDC | protective cover | IN STOCK |
| 1760-PICOSOFT | PicoSoft programming software | IN STOCK |
| 1760-PICOSOFTPRO | PicoSoft Pro programming software | IN STOCK |
| 1760-SIM | I/O simulator | IN STOCK |
| 1760-TERM1 | Pico-Link termination resistors | IN STOCK |
| 1760-USB-PICO | Pico USB programming cable | IN STOCK |
Catalog number |
1760-L12DWD |
Inputs |
8, 12 V DC |
Outputs |
4, relay |
Line power |
12 V DC |
Real-time clock |
Yes |
Display and keypad |
Yes |
Analog inputs |
Not published |
Expansion modules |
Not expansion capable (no EX suffix) |
Lifecycle |
Discontinued 31 March 2017 |
Documentation |
1760-UM001 |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1760-UM001 (module specifications) and 1760-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
1760-L12DWD is a Pico controller: a compact logic relay programmed with function blocks rather than a ladder PLC.
for 12 V DC systems Inputs are 8, 12 V DC and outputs are 4, relay.
The controller is powered from 12 V DC and carries its own display and keypad unless the ND suffix says otherwise.
Pico controllers are wired on screw terminals with the inputs on the top row and the outputs on the bottom.
For AC input models the inputs must be connected to the same phase as the power feed L1, as the manual requires; otherwise the input threshold may not be reached.
Expansion: Not expansion capable (no EX suffix).
A memory module in the interface slot holds the circuit diagram and the parameters, so a replacement controller can be loaded without a PC.
Programming is done with PicoSoft through the 1760-CBL-PM02 cable, or from the keypad on models that have a display.
Rockwell lists this catalog number as Discontinued, with a discontinuation date of 31 March 2017.
Every value in the table above comes from Rockwell publication 1760-UM001 or 1760-UM002, or from the Rockwell product page for this catalog number.
Where a value is not printed in those documents it is marked as not published rather than estimated.
Rockwell discontinued the Bulletin 1760 Pico and PicoGFX range on 31 March 2017; the product pages now carry a discontinuation notice and no replacement catalogue is offered for the accessories.
These parts have been out of production since 2017, so the supply is used or surplus stock rather than new distribution.
For a controller, confirm that the memory module and the programming cable are included: without the cable the unit cannot be reprogrammed, and a memory module carries the only copy of the circuit diagram on many machines.
Ask for the label photograph: the ND and NC suffixes change the display and the clock, and the catalog number on the label is the only reliable identifier.
What is 1760-L12DWD?
A Pico controller with 8, 12 V DC and 4, relay.
What supply does 1760-L12DWD need?
12 V DC.
Does 1760-L12DWD have a real-time clock?
Yes.
Can 1760-L12DWD take expansion modules?
Not expansion capable (no EX suffix).
Is 1760-L12DWD still sold by Rockwell?
No. It was discontinued on 31 March 2017.
