Allen Bradley PLC 1764-28BXB1 / 176428BXB1

China Allen Bradley PLC 1764-28BXB1 / 176428BXB1 supplier
Allen Bradley PLC 1764-28BXB1 / 176428BXB1 supplier Allen Bradley PLC 1764-28BXB1 / 176428BXB1 supplier Allen Bradley PLC 1764-28BXB1 / 176428BXB1 supplier Allen Bradley PLC 1764-28BXB1 / 176428BXB1 supplier Allen Bradley PLC 1764-28BXB1 / 176428BXB1 supplier Allen Bradley PLC 1764-28BXB1 / 176428BXB1 supplier

Large Image :  Allen Bradley PLC 1764-28BXB1 / 176428BXB1

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1764-28BXB1 / 176428BXB1

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $351.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 10 PCS
Detailed Product Description

1764-28BXB1 technical data PDF download 1764-28BXB1 Rockwell MicroLogix 1500 28 Point Base Unit

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: MicroLogix 1100 / 1763

1764-28BXB1 is a MicroLogix 1500 base unit: the I/O and power half of a controller that only becomes a PLC when a 1764-LSP processor is fitted on top.

That two-piece construction is the reason the base keeps turning up in spares lists years after the line was retired — a base with a dead processor can be brought back with a processor alone, and vice versa.

1764-24AWA Base, 12 ac inputs, 12 relay outputs, ac power IN STOCK
1764-28BXB1 Base, 28 point, 24V dc, relay + FET IN STOCK
1764-LSP Standard processor, 7.6 KB IN STOCK
1764-DAT Data access tool IN STOCK
1764-MM1 Memory module, 8K IN STOCK
1764-MM2 Memory module, 16K IN STOCK
1764-MM3 Memory module, 16K plus recipe data IN STOCK
1764-MM1RTC 8K memory with real-time clock IN STOCK
1764-MM2RTC 16K memory with real-time clock IN STOCK
1764-MM3RTC 16K memory with real-time clock and recipe data IN STOCK
1764-RTC Real-time clock IN STOCK
1764-RPLTB1 Replacement part IN STOCK
1764-RPLTB2 Replacement part IN STOCK
1764-RPLCDR1 Replacement part IN STOCK

Product Specifications 1764-28BXB1 (PDF)
 Catalog number
 1764-28BXB1
 Description
 MicroLogix 1500 base, 28 point, 24V dc
 Line power
 24V dc
 Inputs
 8 standard 24V dc inputs plus 8 fast 24V dc inputs
 Outputs
 6 relay outputs (2 isolated), 4 standard 24V dc FET, 2 fast 24V dc FET
 High-speed I/O
 8 inputs at 20 kHz, 2 outputs at 20 kHz
 Dimensions
 118 mm high (138 mm with DIN latch open), 168 mm wide, 87 mm deep
 Relay contact rating
 240V ac 7.5 A make / 0.75 A break, 120V ac 15 A make / 1.5 A break
 Continuous relay current
 8 A per common; 18 A at 150V and at 240V per controller
 Heat dissipation
 18 W + (0.3 x system loading)
 Mounting
 Horizontal, Compact I/O expansion to the right, 50 mm free space all round
 Lifecycle status
 Discontinued June 30, 2017
 Replacement category
 Functional Replacement
 UPC
 781180892929
 Publication
 1764-UM001

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1764-UM001 (module specifications) and 1764-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1764-28BXB1 1764-28BXB1 1764-28BXB1 1764-28BXB1

I/O complement

8 standard 24V dc inputs plus 8 fast 24V dc inputs on the 24V dc line power.

6 relay outputs (2 isolated), 4 standard 24V dc FET, 2 fast 24V dc FET

Two relays on the base are isolated from the rest, which lets one contact switch a different circuit potential without a separate interposing relay.

Ratings

Relay contacts are rated 7.5 A make and 0.75 A break at 240V ac, 15 A make and 1.5 A break at 120V ac, 2.5 A continuous. The total load controlled by the base is limited to 1440 VA break.

Continuous relay current is 8 A per common; 18 A at 150V and at 240V per controller, and per-common grouping therefore matters when several outputs feed the same machine section.

Heat and enclosure

18 W + (0.3 x system loading). A fully loaded base in a sealed enclosure is a real heat source — the 50 mm of free space on all sides is the minimum, not a target.

118 mm high with the DIN latch closed, 138 mm open, 168 mm wide, 87 mm deep.

Processor pairing

The base is useless without a processor: 1764-LSP (7.6 KB, standard) or 1764-LRP (enhanced, RS-232 port). Only the LRP supports programs above 8K, which is why MM2/MM3 modules are specified with it.

Compact I/O expansion modules mount to the right of the base and draw from its backplane supply.

Lifecycle

Discontinued June 30, 2017, replacement category Functional Replacement — Rockwell pointed customers at a successor family rather than a like-for-like part.

For a running line the practical path is a tested spare base, or a migration project. Mixing a used base with a used processor of unknown history is how a panel ends up with two faults instead of one.

FAQ — 1764-28BXB1

What I/O does 1764-28BXB1 have?

8 standard 24V dc inputs plus 8 fast 24V dc inputs; 6 relay outputs (2 isolated), 4 standard 24V dc FET, 2 fast 24V dc FET.

What line power does 1764-28BXB1 take?

24V dc.

Is 1764-28BXB1 still available from Rockwell?

No. Discontinued June 30, 2017; replacement category Functional Replacement.

Does 1764-28BXB1 work without a processor?

No. It needs a 1764-LSP or 1764-LRP processor.

What is the relay rating on 1764-28BXB1?

240V ac 7.5 A make / 0.75 A break, 2.5 A continuous, 1440 VA total load break.


Data sources. I/O counts, relay contact ratings, continuous current limits, dimensions and the heat dissipation equation come from the 1764-UM001 base unit tables; discontinued date, replacement category and UPC come from the Rockwell product page. Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
