Allen Bradley PowerFlex 20AC015A0AYNANC0

China Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier
Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier Allen Bradley PowerFlex 20AC015A0AYNANC0 supplier

Large Image :  Allen Bradley PowerFlex 20AC015A0AYNANC0

Product Details:

Place of Origin: Made in MEXICO
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PowerFlex 20AC015A0AYNANC0

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $863.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: T/T, Western Union and Paypal.
Supply Ability: 2 PCS
Detailed Product Description

20AC015A0AYNANC0 technical data PDF download 20AC015A0AYNANC0 PowerFlex 70 Drive, 15.4 A / 7.5 kW

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PowerFlex 70 drives

20AC015A0AYNANC0 is a PowerFlex 70 in the 400 V class at the 15.4 A rating: 7.5 kW, 10 Hp, frame C.

This is the plain build of the 20AC015 rating: panel mount, filtered, no network slot. The power stage is the same across the family, so the differences are in the option slots only.

Quick answer. 20AC015A0AYNANC0 is a Rockwell Automation PowerFlex 70 drive, 400 V AC class, 15.4 A normal duty (7.5 kW / 10 Hp), frame C, A - Panel mount, IP 20, NEMA/UL Type 1.

  • Normal duty output current: 15.4 A
  • Motor rating: 7.5 kW / 10 Hp
  • Frame: C
  • Enclosure: A - Panel mount, IP 20, NEMA/UL Type 1
  • Communication slot: N - None
  • Control and I/O: C - Enhanced control, no safe-off
20AC015C0AYNANC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYYANC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYYAEC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYNANC1 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYNANC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYNAEG0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYNAEC1 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYNAEC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYNADG1 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A0AYYANC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A0AYNANC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A0AYNAEC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A0AYNADG0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015F0AYNANC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015C3AYYANC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015C3AYNANC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYNADC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A3AYNACC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A0AYNANC1 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A0AYNADC0 15.4 A / 7.5 kW, frame C IN STOCK
20AC015A0AYNACC0 15.4 A / 7.5 kW, frame C IN STOCK

Product Specifications 20AC015A0AYNANC0 (PDF)
 Catalog number
 20AC015A0AYNANC0
 Voltage class
 400 V AC, 3-phase, 6-pulse
 Normal duty output current
 15.4 A
 Normal duty motor rating
 7.5 kW / 10 Hp
 Frame size
 C
 Enclosure (d)
 A - Panel mount, IP 20, NEMA/UL Type 1
 HIM (e)
 0 - Blank cover
 Documentation (f)
 A - Manual included
 Brake IGBT (g)
 Y - Brake IGBT fitted
 Internal brake resistor (h)
 N - No internal brake resistor
 Emission class (i)
 A - Filtered
 Comm slot (j)
 N - None
 Control and I/O (k)
 C - Enhanced control, no safe-off
 Feedback (l)
 0 - No feedback, enhanced control
 Source
 20A-UM001 p.10 catalog explanation

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 20A-UM001 (Feb 2018) (module specifications) and 20A-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

20AC015A0AYNANC0 20AC015A0AYNANC0 20AC015A0AYNANC0 20AC015A0AYNANC0 20AC015A0AYNANC0 20AC015A0AYNANC0 20AC015A0AYNANC0

How to read this catalog number

The string is 20A (drive), C (400 V AC 3-phase), 015 (rating), then nine option positions d to l.

Here: d=A, e=0, f=A, g=Y, h=N, i=A, j=N, k=C, l=0.

Rockwell prints each position as its own table on page 10 of 20A-UM001; decoding by eye is where most used-drive listings go wrong.

What each position controls

Enclosure (d) decides the mounting: Panel mount, IP 20, NEMA/UL Type 1.

HIM (e): Blank cover. The LCD keypad is removable, so a used drive can arrive with a blank cover.

Brake IGBT (g): Brake IGBT fitted; internal brake resistor (h): No internal brake resistor. Both are needed before a holding brake can be wired straight to the drive.

Comm slot (j): None. Control and I/O (k): Enhanced control, no safe-off. Feedback (l): No feedback, enhanced control.

Rating and frame

Normal duty 15.4 A, 7.5 kW / 10 Hp on frame C.

Frame sets the heatsink, fan and terminal spacing, so a frame change is also a panel-space change.

Heavy duty figures are lower than the normal duty row and are listed separately in 20A-UM001.

What to verify before buying used

Nameplate catalog number, full 16 characters, against this page - one letter changes the enclosure or the network option.

Safe-off builds (k=G) carry a second terminal pair; a standard-control drive does not.

Encoder interface (l=1) is a separate board; it is not CE EMC certified when fitted.

Documented source

Every code above is transcribed from the Catalog Number Explanation, page 10 of Rockwell publication 20A-UM001 (February 2018).

No field on this page is inferred from a distributor listing; positions Rockwell leaves blank are not published and are not shown as data.

FAQ — 20AC015A0AYNANC0

What is 20AC015A0AYNANC0?

PowerFlex 70, 400 V, 15.4 A / 7.5 kW, frame C, panel mount.

What is the output current of 20AC015A0AYNANC0?

15.4 A normal duty at 400 V.

Which frame is 20AC015A0AYNANC0?

Frame C, 7.5 kW / 10 Hp normal duty.

Does 20AC015A0AYNANC0 have a network slot?

None.

What enclosure is 20AC015A0AYNANC0?

Panel mount, IP 20, NEMA/UL Type 1.

Related catalog numbers in the same rating code. Same 15.4 A A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.

20AC015C0AYNANC0 (15.4 A / 7.5 kW, frame C) · 20AC015A3AYYANC0 (15.4 A / 7.5 kW, frame C) · 20AC015A3AYYAEC0 (15.4 A / 7.5 kW, frame C) · 20AC015A3AYNANC1 (15.4 A / 7.5 kW, frame C) · 20AC015A3AYNANC0 (15.4 A / 7.5 kW, frame C) · 20AC015A3AYNAEG0 (15.4 A / 7.5 kW, frame C) · 20AC015A3AYNAEC1 (15.4 A / 7.5 kW, frame C) · 20AC015A3AYNAEC0 (15.4 A / 7.5 kW, frame C) · 20AC015A3AYNADG1 (15.4 A / 7.5 kW, frame C) · 20AC015A0AYYANC0 (15.4 A / 7.5 kW, frame C)


Data sources. Decoded from Rockwell 20A-UM001 p.10 Catalog Number Explanation; ratings from the 400 V 50 Hz table on the same page Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
