Allen Bradley PowerFlex 20AC011F3NYNANC0

China Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier
Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier Allen Bradley PowerFlex 20AC011F3NYNANC0 supplier

Large Image :  Allen Bradley PowerFlex 20AC011F3NYNANC0

Product Details:

Place of Origin: Made in MEXICO
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PowerFlex 20AC011F3NYNANC0

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $880.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: T/T, Western Union and Paypal.
Supply Ability: 2 PCS
Detailed Product Description

20AC011F3NYNANC0 technical data PDF download 20AC011F3NYNANC0 PowerFlex 70 Drive, 11.5 A / 5.5 kW

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PowerFlex 70 drives

20AC011F3NYNANC0 is a PowerFlex 70 in the 400 V class at the 11.5 A rating: 5.5 kW, 7.5 Hp, frame C.

Its build differs from the plain 20AC011A0AYNANC0 in flange mount. The power stage is the same across the family, so the differences are in the option slots only.

Quick answer. 20AC011F3NYNANC0 is a Rockwell Automation PowerFlex 70 drive, 400 V AC class, 11.5 A normal duty (5.5 kW / 7.5 Hp), frame C, F - Flange mount, front IP 20, rear heatsink IP 66.

  • Normal duty output current: 11.5 A
  • Motor rating: 5.5 kW / 7.5 Hp
  • Frame: C
  • Enclosure: F - Flange mount, front IP 20, rear heatsink IP 66
  • Communication slot: N - None
  • Control and I/O: C - Enhanced control, no safe-off
20AC011F3NYNANC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011F0AYNANC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A3AYYANC1 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A3AYYAEC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A3AYNANC1 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A3AYNAEC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A0AYYANC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A0AYNANC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A0AYNADC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A0AYNADG0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011C3AYNANC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011C0AYNANC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A3AYYAEC1 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A3AYNANC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A3AYNAEG0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A3AYNADC0 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A0AYNANC1 11.5 A / 5.5 kW, frame C IN STOCK
20AC011A0AYNAEG0 11.5 A / 5.5 kW, frame C IN STOCK

Product Specifications 20AC011F3NYNANC0 (PDF)
 Catalog number
 20AC011F3NYNANC0
 Voltage class
 400 V AC, 3-phase, 6-pulse
 Normal duty output current
 11.5 A
 Normal duty motor rating
 5.5 kW / 7.5 Hp
 Frame size
 C
 Enclosure (d)
 F - Flange mount, front IP 20, rear heatsink IP 66
 HIM (e)
 3 - Full numeric LCD
 Documentation (f)
 N - No manual
 Brake IGBT (g)
 Y - Brake IGBT fitted
 Internal brake resistor (h)
 N - No internal brake resistor
 Emission class (i)
 A - Filtered
 Comm slot (j)
 N - None
 Control and I/O (k)
 C - Enhanced control, no safe-off
 Feedback (l)
 0 - No feedback, enhanced control
 Source
 20A-UM001 p.10 catalog explanation

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 20A-UM001 (Feb 2018) (module specifications) and 20A-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

20AC011F3NYNANC0 20AC011F3NYNANC0 20AC011F3NYNANC0 20AC011F3NYNANC0 20AC011F3NYNANC0 20AC011F3NYNANC0 20AC011F3NYNANC0

How to read this catalog number

The string is 20A (drive), C (400 V AC 3-phase), 011 (rating), then nine option positions d to l.

Here: d=F, e=3, f=N, g=Y, h=N, i=A, j=N, k=C, l=0.

Rockwell prints each position as its own table on page 10 of 20A-UM001; decoding by eye is where most used-drive listings go wrong.

What each position controls

Enclosure (d) decides the mounting: Flange mount, front IP 20, rear heatsink IP 66.

HIM (e): Full numeric LCD. The LCD keypad is removable, so a used drive can arrive with a blank cover.

Brake IGBT (g): Brake IGBT fitted; internal brake resistor (h): No internal brake resistor. Both are needed before a holding brake can be wired straight to the drive.

Comm slot (j): None. Control and I/O (k): Enhanced control, no safe-off. Feedback (l): No feedback, enhanced control.

Rating and frame

Normal duty 11.5 A, 5.5 kW / 7.5 Hp on frame C.

Frame sets the heatsink, fan and terminal spacing, so a frame change is also a panel-space change.

Heavy duty figures are lower than the normal duty row and are listed separately in 20A-UM001.

What to verify before buying used

Nameplate catalog number, full 16 characters, against this page - one letter changes the enclosure or the network option.

Safe-off builds (k=G) carry a second terminal pair; a standard-control drive does not.

Encoder interface (l=1) is a separate board; it is not CE EMC certified when fitted.

Documented source

Every code above is transcribed from the Catalog Number Explanation, page 10 of Rockwell publication 20A-UM001 (February 2018).

No field on this page is inferred from a distributor listing; positions Rockwell leaves blank are not published and are not shown as data.

FAQ — 20AC011F3NYNANC0

What is 20AC011F3NYNANC0?

PowerFlex 70, 400 V, 11.5 A / 5.5 kW, frame C, flange mount.

What is the output current of 20AC011F3NYNANC0?

11.5 A normal duty at 400 V.

Which frame is 20AC011F3NYNANC0?

Frame C, 5.5 kW / 7.5 Hp normal duty.

Does 20AC011F3NYNANC0 have a network slot?

None.

What enclosure is 20AC011F3NYNANC0?

Flange mount, front IP 20, rear heatsink IP 66.

Related catalog numbers in the same rating code. Same 11.5 A A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.

20AC011F0AYNANC0 (11.5 A / 5.5 kW, frame C) · 20AC011A3AYYANC1 (11.5 A / 5.5 kW, frame C) · 20AC011A3AYYAEC0 (11.5 A / 5.5 kW, frame C) · 20AC011A3AYNANC1 (11.5 A / 5.5 kW, frame C) · 20AC011A3AYNAEC0 (11.5 A / 5.5 kW, frame C) · 20AC011A0AYYANC0 (11.5 A / 5.5 kW, frame C) · 20AC011A0AYNANC0 (11.5 A / 5.5 kW, frame C) · 20AC011A0AYNADC0 (11.5 A / 5.5 kW, frame C) · 20AC011A0AYNADG0 (11.5 A / 5.5 kW, frame C)


Data sources. Decoded from Rockwell 20A-UM001 p.10 Catalog Number Explanation; ratings from the 400 V 50 Hz table on the same page Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
