20AC011A0AYYANC0 is a PowerFlex 70 in the 400 V class at the 11.5 A rating: 5.5 kW, 7.5 Hp, frame C.
This is the plain build of the 20AC011 rating: panel mount, filtered, no network slot. The power stage is the same across the family, so the differences are in the option slots only.
Quick answer. 20AC011A0AYYANC0 is a Rockwell Automation PowerFlex 70 drive, 400 V AC class, 11.5 A normal duty (5.5 kW / 7.5 Hp), frame C, A - Panel mount, IP 20, NEMA/UL Type 1.
| 20AC011F3NYNANC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011F0AYNANC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A3AYYANC1 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A3AYYAEC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A3AYNANC1 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A3AYNAEC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A0AYYANC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A0AYNANC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A0AYNADC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A0AYNADG0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011C3AYNANC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011C0AYNANC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A3AYYAEC1 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A3AYNANC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A3AYNAEG0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A3AYNADC0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A0AYNANC1 | 11.5 A / 5.5 kW, frame C | IN STOCK |
| 20AC011A0AYNAEG0 | 11.5 A / 5.5 kW, frame C | IN STOCK |
Catalog number |
20AC011A0AYYANC0 |
Voltage class |
400 V AC, 3-phase, 6-pulse |
Normal duty output current |
11.5 A |
Normal duty motor rating |
5.5 kW / 7.5 Hp |
Frame size |
C |
Enclosure (d) |
A - Panel mount, IP 20, NEMA/UL Type 1 |
HIM (e) |
0 - Blank cover |
Documentation (f) |
A - Manual included |
Brake IGBT (g) |
Y - Brake IGBT fitted |
Internal brake resistor (h) |
Y - Internal brake resistor fitted |
Emission class (i) |
A - Filtered |
Comm slot (j) |
N - None |
Control and I/O (k) |
C - Enhanced control, no safe-off |
Feedback (l) |
0 - No feedback, enhanced control |
Source |
20A-UM001 p.10 catalog explanation |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 20A-UM001 (Feb 2018) (module specifications) and 20A-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
The string is 20A (drive), C (400 V AC 3-phase), 011 (rating), then nine option positions d to l.
Here: d=A, e=0, f=A, g=Y, h=Y, i=A, j=N, k=C, l=0.
Rockwell prints each position as its own table on page 10 of 20A-UM001; decoding by eye is where most used-drive listings go wrong.
Enclosure (d) decides the mounting: Panel mount, IP 20, NEMA/UL Type 1.
HIM (e): Blank cover. The LCD keypad is removable, so a used drive can arrive with a blank cover.
Brake IGBT (g): Brake IGBT fitted; internal brake resistor (h): Internal brake resistor fitted. Both are needed before a holding brake can be wired straight to the drive.
Comm slot (j): None. Control and I/O (k): Enhanced control, no safe-off. Feedback (l): No feedback, enhanced control.
Normal duty 11.5 A, 5.5 kW / 7.5 Hp on frame C.
Frame sets the heatsink, fan and terminal spacing, so a frame change is also a panel-space change.
Heavy duty figures are lower than the normal duty row and are listed separately in 20A-UM001.
Nameplate catalog number, full 16 characters, against this page - one letter changes the enclosure or the network option.
Safe-off builds (k=G) carry a second terminal pair; a standard-control drive does not.
Encoder interface (l=1) is a separate board; it is not CE EMC certified when fitted.
Every code above is transcribed from the Catalog Number Explanation, page 10 of Rockwell publication 20A-UM001 (February 2018).
No field on this page is inferred from a distributor listing; positions Rockwell leaves blank are not published and are not shown as data.
What is 20AC011A0AYYANC0?
PowerFlex 70, 400 V, 11.5 A / 5.5 kW, frame C, panel mount.
What is the output current of 20AC011A0AYYANC0?
11.5 A normal duty at 400 V.
Which frame is 20AC011A0AYYANC0?
Frame C, 5.5 kW / 7.5 Hp normal duty.
Does 20AC011A0AYYANC0 have a network slot?
None.
What enclosure is 20AC011A0AYYANC0?
Panel mount, IP 20, NEMA/UL Type 1.
Related catalog numbers in the same rating code. Same 11.5 A A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.
