20AC022A3AYNAEC0 is a PowerFlex 70 in the 400 V class at the 22 A rating: 11 kW, 15 Hp, frame D.
Its build differs from the plain 20AC022A0AYNANC0 in EtherNet/IP. The power stage is the same across the family, so the differences are in the option slots only.
Quick answer. 20AC022A3AYNAEC0 is a Rockwell Automation PowerFlex 70 drive, 400 V AC class, 22 A normal duty (11 kW / 15 Hp), frame D, A - Panel mount, IP 20, NEMA/UL Type 1.
| 20AC022F3NYNANC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022F0AYNANC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022C0AYNANC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022A3AYYADG1 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022A3AYNANC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022A3AYNADC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022A0AYNANC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022C3AYYANC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022C3AYNANC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022C3AYNAEC1 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022C0NYNANC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022A3AYYANC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022A3AYNANG0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022A3AYNAEG0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022A3AYNAEC0 | 22 A / 11 kW, frame D | IN STOCK |
| 20AC022A0AYYANC0 | 22 A / 11 kW, frame D | IN STOCK |
Catalog number |
20AC022A3AYNAEC0 |
Voltage class |
400 V AC, 3-phase, 6-pulse |
Normal duty output current |
22 A |
Normal duty motor rating |
11 kW / 15 Hp |
Frame size |
D |
Enclosure (d) |
A - Panel mount, IP 20, NEMA/UL Type 1 |
HIM (e) |
3 - Full numeric LCD |
Documentation (f) |
A - Manual included |
Brake IGBT (g) |
Y - Brake IGBT fitted |
Internal brake resistor (h) |
N - No internal brake resistor |
Emission class (i) |
A - Filtered |
Comm slot (j) |
E - EtherNet/IP |
Control and I/O (k) |
C - Enhanced control, no safe-off |
Feedback (l) |
0 - No feedback, enhanced control |
Source |
20A-UM001 p.10 catalog explanation |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 20A-UM001 (Feb 2018) (module specifications) and 20A-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
The string is 20A (drive), C (400 V AC 3-phase), 022 (rating), then nine option positions d to l.
Here: d=A, e=3, f=A, g=Y, h=N, i=A, j=E, k=C, l=0.
Rockwell prints each position as its own table on page 10 of 20A-UM001; decoding by eye is where most used-drive listings go wrong.
Enclosure (d) decides the mounting: Panel mount, IP 20, NEMA/UL Type 1.
HIM (e): Full numeric LCD. The LCD keypad is removable, so a used drive can arrive with a blank cover.
Brake IGBT (g): Brake IGBT fitted; internal brake resistor (h): No internal brake resistor. Both are needed before a holding brake can be wired straight to the drive.
Comm slot (j): EtherNet/IP. Control and I/O (k): Enhanced control, no safe-off. Feedback (l): No feedback, enhanced control.
Normal duty 22 A, 11 kW / 15 Hp on frame D.
Frame sets the heatsink, fan and terminal spacing, so a frame change is also a panel-space change.
Heavy duty figures are lower than the normal duty row and are listed separately in 20A-UM001.
Nameplate catalog number, full 16 characters, against this page - one letter changes the enclosure or the network option.
Safe-off builds (k=G) carry a second terminal pair; a standard-control drive does not.
Encoder interface (l=1) is a separate board; it is not CE EMC certified when fitted.
Every code above is transcribed from the Catalog Number Explanation, page 10 of Rockwell publication 20A-UM001 (February 2018).
No field on this page is inferred from a distributor listing; positions Rockwell leaves blank are not published and are not shown as data.
What is 20AC022A3AYNAEC0?
PowerFlex 70, 400 V, 22 A / 11 kW, frame D, panel mount.
What is the output current of 20AC022A3AYNAEC0?
22 A normal duty at 400 V.
Which frame is 20AC022A3AYNAEC0?
Frame D, 11 kW / 15 Hp normal duty.
Does 20AC022A3AYNAEC0 have a network slot?
EtherNet/IP.
What enclosure is 20AC022A3AYNAEC0?
Panel mount, IP 20, NEMA/UL Type 1.
