20AB6P8A0AYNANC0 is a PowerFlex 70 in the 240 V class at the 6.8 A rating: 1.5 kW, 2.0 Hp, frame B.
This is the plain build of the 20AB6P8 rating: panel mount, filtered, no network slot. The power stage is the same across the family, so the differences are in the option slots only.
Quick answer. 20AB6P8A0AYNANC0 is a Rockwell Automation PowerFlex 70 drive, 240 V AC, 3-phase, 6-pulse, 6.8 A normal duty (1.5 kW / 2.0 Hp), frame B, A - Panel mount, IP 20, NEMA/UL Type 1.
| 20AB9P6C3AYNANC0 | 9.6 A / 2.2 kW, frame B | IN STOCK |
| 20AB9P6A0AYNNNC0 | 9.6 A / 2.2 kW, frame B | IN STOCK |
| 20AB9P6A0AYNANG0 | 9.6 A / 2.2 kW, frame B | IN STOCK |
| 20AB6P8A0AYNNNC0 | 6.8 A / 1.5 kW, frame B | IN STOCK |
| 20AB6P8A0AYNANC0 | 6.8 A / 1.5 kW, frame B | IN STOCK |
| 20AB4P2A3NYNNEG1 | 4.2 A / 0.75 kW, frame A | IN STOCK |
| 20AB4P2A3NYNNDG1 | 4.2 A / 0.75 kW, frame A | IN STOCK |
| 20AB4P2A3AYNNNC0 | 4.2 A / 0.75 kW, frame A | IN STOCK |
| 20AB4P2A0AYNNNG0 | 4.2 A / 0.75 kW, frame A | IN STOCK |
| 20AB4P2A0AYNNNC0 | 4.2 A / 0.75 kW, frame A | IN STOCK |
| 20AB4P2A0AYNANC0 | 4.2 A / 0.75 kW, frame A | IN STOCK |
| 20AB2P2A0AYNNNC0 | 2.2 A / 0.37 kW, frame A | IN STOCK |
| 20AB070A0AYNANC0 | 70 A / 18.5 kW, frame E | IN STOCK |
| 20AB054C0NYNANC0 | 54 A / 15 kW, frame E | IN STOCK |
| 20AB054A3AYNANC0 | 54 A / 15 kW, frame E | IN STOCK |
| 20AB054A0AYNANC0 | 54 A / 15 kW, frame E | IN STOCK |
| 20AB042A3AYNANC0 | 42 A / 11 kW, frame D | IN STOCK |
| 20AB042A0AYNANC0 | 42 A / 11 kW, frame D | IN STOCK |
| 20AB028C0AYNANC0 | 28 A / 7.5 kW, frame D | IN STOCK |
| 20AB028A3AYNANC0 | 28 A / 7.5 kW, frame D | IN STOCK |
| 20AB022C3AYNANC0 | 22 A / 5.5 kW, frame C | IN STOCK |
| 20AB022A3AYNANC0 | 22 A / 5.5 kW, frame C | IN STOCK |
| 20AB022A0AYNANC0 | 22 A / 5.5 kW, frame C | IN STOCK |
| 20AB9P6A3AYNACG0 | 9.6 A / 2.2 kW, frame B | IN STOCK |
| 20AB9P6A0AYNANC0 | 9.6 A / 2.2 kW, frame B | IN STOCK |
| 20AB6P8C3AYNANC0 | 6.8 A / 1.5 kW, frame B | IN STOCK |
| 20AB6P8A0AYNNEC0 | 6.8 A / 1.5 kW, frame B | IN STOCK |
| 20AB2P2A3AYNNNC0 | 2.2 A / 0.37 kW, frame A | IN STOCK |
| 20AB2P2A0AYNANC0 | 2.2 A / 0.37 kW, frame A | IN STOCK |
| 20AB054A3NYNANC0 | 54 A / 15 kW, frame E | IN STOCK |
| 20AB042C0AYNANC0 | 42 A / 11 kW, frame D | IN STOCK |
| 20AB028A0AYNANC0 | 28 A / 7.5 kW, frame D | IN STOCK |
Catalog number |
20AB6P8A0AYNANC0 |
Voltage class |
240 V AC, 3-phase, 6-pulse |
Normal duty output current |
6.8 A |
Normal duty motor rating |
1.5 kW / 2.0 Hp |
Frame size |
B |
Enclosure (d) |
A - Panel mount, IP 20, NEMA/UL Type 1 |
HIM (e) |
0 - Blank cover |
Documentation (f) |
A - Manual included |
Brake IGBT (g) |
Y - Brake IGBT fitted |
Internal brake resistor (h) |
N - No internal brake resistor |
Emission class (i) |
A - Filtered |
Comm slot (j) |
N - None |
Control and I/O (k) |
C - Enhanced control, no safe-off |
Feedback (l) |
0 - No feedback, enhanced control |
Source |
20A-UM001 p.10 catalog explanation |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 20A-UM001 (Feb 2018) (module specifications) and 20A-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
The string is 20A (drive), B (240 V AC 3-phase), 6P8 (rating), then nine option positions d to l.
Here: d=A, e=0, f=A, g=Y, h=N, i=A, j=N, k=C, l=0.
Rockwell prints each position as its own table on page 10 of 20A-UM001; decoding by eye is where most used-drive listings go wrong.
Enclosure (d) decides the mounting: Panel mount, IP 20, NEMA/UL Type 1.
HIM (e): Blank cover. The LCD keypad is removable, so a used drive can arrive with a blank cover.
Brake IGBT (g): Brake IGBT fitted; internal brake resistor (h): No internal brake resistor. Both are needed before a holding brake can be wired straight to the drive.
Comm slot (j): None. Control and I/O (k): Enhanced control, no safe-off. Feedback (l): No feedback, enhanced control.
Normal duty 6.8 A, 1.5 kW / 2.0 Hp on frame B.
Frame sets the heatsink, fan and terminal spacing, so a frame change is also a panel-space change.
Heavy duty figures are lower than the normal duty row and are listed separately in 20A-UM001.
Nameplate catalog number, full 16 characters, against this page - one letter changes the enclosure or the network option.
Safe-off builds (k=G) carry a second terminal pair; a standard-control drive does not.
Encoder interface (l=1) is a separate board; it is not CE EMC certified when fitted.
Every code above is transcribed from the Catalog Number Explanation, page 10 of Rockwell publication 20A-UM001 (February 2018).
No field on this page is inferred from a distributor listing; positions Rockwell leaves blank are not published and are not shown as data.
What is 20AB6P8A0AYNANC0?
PowerFlex 70, 240 V, 6.8 A / 1.5 kW, frame B, panel mount.
What is the output current of 20AB6P8A0AYNANC0?
6.8 A normal duty at 240 V.
Which frame is 20AB6P8A0AYNANC0?
Frame B, 1.5 kW / 2.0 Hp normal duty.
Does 20AB6P8A0AYNANC0 have a network slot?
None.
What enclosure is 20AB6P8A0AYNANC0?
Panel mount, IP 20, NEMA/UL Type 1.
