Allen Bradley PowerFlex 20AB9P6A0AYNANC0

China Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier
Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier Allen Bradley PowerFlex 20AB9P6A0AYNANC0 supplier

Large Image :  Allen Bradley PowerFlex 20AB9P6A0AYNANC0

Product Details:

Place of Origin: Made in MEXICO
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PowerFlex 20AB9P6A0AYNANC0

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $625.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: T/T, Western Union and Paypal.
Supply Ability: 2 PCS
Detailed Product Description

20AB9P6A0AYNANC0 technical data PDF download 20AB9P6A0AYNANC0 PowerFlex 70 Drive, 9.6 A / 2.2 kW

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PowerFlex 70 drives

20AB9P6A0AYNANC0 is a PowerFlex 70 in the 240 V class at the 9.6 A rating: 2.2 kW, 3.0 Hp, frame B.

This is the plain build of the 20AB9P6 rating: panel mount, filtered, no network slot. The power stage is the same across the family, so the differences are in the option slots only.

Quick answer. 20AB9P6A0AYNANC0 is a Rockwell Automation PowerFlex 70 drive, 240 V AC, 3-phase, 6-pulse, 9.6 A normal duty (2.2 kW / 3.0 Hp), frame B, A - Panel mount, IP 20, NEMA/UL Type 1.

  • Normal duty output current: 9.6 A
  • Motor rating: 2.2 kW / 3.0 Hp
  • Frame: B
  • Enclosure: A - Panel mount, IP 20, NEMA/UL Type 1
  • Communication slot: N - None
  • Control and I/O: C - Enhanced control, no safe-off
20AB9P6C3AYNANC0 9.6 A / 2.2 kW, frame B IN STOCK
20AB9P6A0AYNNNC0 9.6 A / 2.2 kW, frame B IN STOCK
20AB9P6A0AYNANG0 9.6 A / 2.2 kW, frame B IN STOCK
20AB6P8A0AYNNNC0 6.8 A / 1.5 kW, frame B IN STOCK
20AB6P8A0AYNANC0 6.8 A / 1.5 kW, frame B IN STOCK
20AB4P2A3NYNNEG1 4.2 A / 0.75 kW, frame A IN STOCK
20AB4P2A3NYNNDG1 4.2 A / 0.75 kW, frame A IN STOCK
20AB4P2A3AYNNNC0 4.2 A / 0.75 kW, frame A IN STOCK
20AB4P2A0AYNNNG0 4.2 A / 0.75 kW, frame A IN STOCK
20AB4P2A0AYNNNC0 4.2 A / 0.75 kW, frame A IN STOCK
20AB4P2A0AYNANC0 4.2 A / 0.75 kW, frame A IN STOCK
20AB2P2A0AYNNNC0 2.2 A / 0.37 kW, frame A IN STOCK
20AB070A0AYNANC0 70 A / 18.5 kW, frame E IN STOCK
20AB054C0NYNANC0 54 A / 15 kW, frame E IN STOCK
20AB054A3AYNANC0 54 A / 15 kW, frame E IN STOCK
20AB054A0AYNANC0 54 A / 15 kW, frame E IN STOCK
20AB042A3AYNANC0 42 A / 11 kW, frame D IN STOCK
20AB042A0AYNANC0 42 A / 11 kW, frame D IN STOCK
20AB028C0AYNANC0 28 A / 7.5 kW, frame D IN STOCK
20AB028A3AYNANC0 28 A / 7.5 kW, frame D IN STOCK
20AB022C3AYNANC0 22 A / 5.5 kW, frame C IN STOCK
20AB022A3AYNANC0 22 A / 5.5 kW, frame C IN STOCK
20AB022A0AYNANC0 22 A / 5.5 kW, frame C IN STOCK
20AB9P6A3AYNACG0 9.6 A / 2.2 kW, frame B IN STOCK
20AB9P6A0AYNANC0 9.6 A / 2.2 kW, frame B IN STOCK
20AB6P8C3AYNANC0 6.8 A / 1.5 kW, frame B IN STOCK
20AB6P8A0AYNNEC0 6.8 A / 1.5 kW, frame B IN STOCK
20AB2P2A3AYNNNC0 2.2 A / 0.37 kW, frame A IN STOCK
20AB2P2A0AYNANC0 2.2 A / 0.37 kW, frame A IN STOCK
20AB054A3NYNANC0 54 A / 15 kW, frame E IN STOCK
20AB042C0AYNANC0 42 A / 11 kW, frame D IN STOCK
20AB028A0AYNANC0 28 A / 7.5 kW, frame D IN STOCK

Product Specifications 20AB9P6A0AYNANC0 (PDF)
 Catalog number
 20AB9P6A0AYNANC0
 Voltage class
 240 V AC, 3-phase, 6-pulse
 Normal duty output current
 9.6 A
 Normal duty motor rating
 2.2 kW / 3.0 Hp
 Frame size
 B
 Enclosure (d)
 A - Panel mount, IP 20, NEMA/UL Type 1
 HIM (e)
 0 - Blank cover
 Documentation (f)
 A - Manual included
 Brake IGBT (g)
 Y - Brake IGBT fitted
 Internal brake resistor (h)
 N - No internal brake resistor
 Emission class (i)
 A - Filtered
 Comm slot (j)
 N - None
 Control and I/O (k)
 C - Enhanced control, no safe-off
 Feedback (l)
 0 - No feedback, enhanced control
 Source
 20A-UM001 p.10 catalog explanation

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 20A-UM001 (Feb 2018) (module specifications) and 20A-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

20AB9P6A0AYNANC0 20AB9P6A0AYNANC0 20AB9P6A0AYNANC0 20AB9P6A0AYNANC0 20AB9P6A0AYNANC0 20AB9P6A0AYNANC0 20AB9P6A0AYNANC0

How to read this catalog number

The string is 20A (drive), B (240 V AC 3-phase), 9P6 (rating), then nine option positions d to l.

Here: d=A, e=0, f=A, g=Y, h=N, i=A, j=N, k=C, l=0.

Rockwell prints each position as its own table on page 10 of 20A-UM001; decoding by eye is where most used-drive listings go wrong.

What each position controls

Enclosure (d) decides the mounting: Panel mount, IP 20, NEMA/UL Type 1.

HIM (e): Blank cover. The LCD keypad is removable, so a used drive can arrive with a blank cover.

Brake IGBT (g): Brake IGBT fitted; internal brake resistor (h): No internal brake resistor. Both are needed before a holding brake can be wired straight to the drive.

Comm slot (j): None. Control and I/O (k): Enhanced control, no safe-off. Feedback (l): No feedback, enhanced control.

Rating and frame

Normal duty 9.6 A, 2.2 kW / 3.0 Hp on frame B.

Frame sets the heatsink, fan and terminal spacing, so a frame change is also a panel-space change.

Heavy duty figures are lower than the normal duty row and are listed separately in 20A-UM001.

What to verify before buying used

Nameplate catalog number, full 16 characters, against this page - one letter changes the enclosure or the network option.

Safe-off builds (k=G) carry a second terminal pair; a standard-control drive does not.

Encoder interface (l=1) is a separate board; it is not CE EMC certified when fitted.

Documented source

Every code above is transcribed from the Catalog Number Explanation, page 10 of Rockwell publication 20A-UM001 (February 2018).

No field on this page is inferred from a distributor listing; positions Rockwell leaves blank are not published and are not shown as data.

FAQ — 20AB9P6A0AYNANC0

What is 20AB9P6A0AYNANC0?

PowerFlex 70, 240 V, 9.6 A / 2.2 kW, frame B, panel mount.

What is the output current of 20AB9P6A0AYNANC0?

9.6 A normal duty at 240 V.

Which frame is 20AB9P6A0AYNANC0?

Frame B, 2.2 kW / 3.0 Hp normal duty.

Does 20AB9P6A0AYNANC0 have a network slot?

None.

What enclosure is 20AB9P6A0AYNANC0?

Panel mount, IP 20, NEMA/UL Type 1.

Related catalog numbers in the same rating code. Same 9.6 A A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.

20AB9P6C3AYNANC0 (9.6 A / 2.2 kW, frame B) · 20AB9P6A0AYNNNC0 (9.6 A / 2.2 kW, frame B) · 20AB9P6A0AYNANG0 (9.6 A / 2.2 kW, frame B) · 20AB6P8A0AYNNNC0 (6.8 A / 1.5 kW, frame B) · 20AB6P8A0AYNANC0 (6.8 A / 1.5 kW, frame B) · 20AB4P2A3NYNNEG1 (4.2 A / 0.75 kW, frame A) · 20AB4P2A3NYNNDG1 (4.2 A / 0.75 kW, frame A) · 20AB4P2A3AYNNNC0 (4.2 A / 0.75 kW, frame A) · 20AB4P2A0AYNNNG0 (4.2 A / 0.75 kW, frame A) · 20AB4P2A0AYNNNC0 (4.2 A / 0.75 kW, frame A)


Data sources. Decoded from Rockwell 20A-UM001 p.10 Catalog Number Explanation; ratings from the 240 V 60 Hz table on the same page Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
