20BP205A0AYNANC0 is a PowerFlex 700 drive, catalog code b=P: 540 V DC input (Y), pre-charge.
The three digits after the voltage letter are the output current in amps - here 205 A. Published ratings: 110 HP normal duty, 90 HP heavy duty, frame 6.
Quick answer. 20BP205A0AYNANC0 is a Rockwell Automation PowerFlex 70 drive, 400 V AC, normal duty (), frame 6, A - IP 20, NEMA/UL Type 1, with conformal coating.
Catalog number |
20BP205A0AYNANC0 |
Voltage rating (b) |
P - 540 V DC input (Y), pre-charge |
Output current rating (c) |
205 A |
Normal duty rating |
110 HP |
Heavy duty rating |
90 HP |
Frame size |
6 |
Enclosure (d) |
A - IP 20, NEMA/UL Type 1, with conformal coating |
HIM (e) |
0 - Blank cover |
Documentation (f) |
A - Manual included |
Brake IGBT (g) |
Y - Brake IGBT fitted |
Internal braking resistor (h) |
N - No internal braking resistor |
Emission class (i) |
A - CE filter fitted, CM choke fitted |
Comm slot (j) |
N - None |
Control and I/O (k) |
C - Vector control, 24 V DC I/O |
Feedback (l) |
0 - No feedback |
Rating code |
205 - read as the output current in amps |
Source |
20B-TD001 p.6-7 catalog explanation; rating and frame from the Rockwell product page |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 20B-TD001 (Sept 2023) (module specifications) and 20B-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
The string is 20B (drive), P (voltage), 205 (output current in amps), then nine option positions d to l.
Here: d=A, e=0, f=A, g=Y, h=N, i=A, j=N, k=C, l=0.
Two more positions m and n exist for future use and special firmware; they are omitted on most orders.
Enclosure (d): IP 20, NEMA/UL Type 1, with conformal coating.
HIM (e): Blank cover. Remote HIM codes J and K mount on a panel door and need the stand-alone IP 54 enclosure.
Brake IGBT (g): Brake IGBT fitted. Internal braking resistor (h): No internal braking resistor; Rockwell does not offer the internal resistor on frame 3 and larger.
Emission (i): CE filter fitted, CM choke fitted. Comm slot (j): None. Control and I/O (k): Vector control, 24 V DC I/O. Feedback (l): No feedback.
A 540 V DC input PowerFlex 700 takes its power from a common DC bus instead of a three-phase rectifier.
Pre-charge is in the catalog code (the Y in position b), so the drive expects the DC bus to be brought up by the line-side pre-charge circuit rather than by the drive itself.
This is the difference an engineer checks first: a 20BP is not a drop-in replacement for a 20BD fed from 480 V AC.
Nameplate catalog number, all 16 characters, against this page.
Whether the frame 5 or 6 enclosure is present; open/flange (d=F) and stand-alone (d=G) drives are the same chassis in different packaging.
Encoder board presence (l=1) and the brake IGBT (g=Y), because both are separate hardware, not parameters.
Positions, voltage classes and option codes are transcribed from 20B-TD001 (September 2023), Catalog Number Explanation, pages 6 and 7, and cross-checked against 20B-UM001 page P-5.
Current, power and frame figures are taken from the Rockwell Automation product page for this catalog number; where that page carries no power rating, none is shown here.
