20BC011A0AYNADC1 is a PowerFlex 700 drive, catalog code b=C: 400 V AC, 3-phase, 50/60 Hz.
The three digits after the voltage letter are the output current in amps - here 11.5 A. Published ratings: 5.5 kW, frame 0.
Quick answer. 20BC011A0AYNADC1 is a Rockwell Automation PowerFlex 70 drive, 400 V AC, normal duty (), frame 0, A - IP 20, NEMA/UL Type 1, with conformal coating.
| 20BC011A0NYNANC1 | 11.5 A | IN STOCK |
| 20BC011A0NYNANC0 | 11.5 A | IN STOCK |
| 20BC011A0AYYANC0 | 11.5 A | IN STOCK |
| 20BC011A0AYYACD1 | 11.5 A | IN STOCK |
| 20BC011A0AYNAND0 | 11.5 A | IN STOCK |
| 20BC011A0AYNANC1 | 11.5 A | IN STOCK |
| 20BC011A0AYNANC0 | 11.5 A | IN STOCK |
| 20BC011A0AYNANA0 | 11.5 A | IN STOCK |
| 20BC011A0AYNAEC1 | 11.5 A | IN STOCK |
| 20BC011A0AYNADC1 | 11.5 A | IN STOCK |
| 20BC011A0AYNACC0 | 11.5 A | IN STOCK |
Catalog number |
20BC011A0AYNADC1 |
Voltage rating (b) |
C - 400 V AC, 3-phase, 50/60 Hz |
Output current rating (c) |
11.5 A |
Normal duty rating |
5.5 kW |
Frame size |
0 |
Enclosure (d) |
A - IP 20, NEMA/UL Type 1, with conformal coating |
HIM (e) |
0 - Blank cover |
Documentation (f) |
A - Manual included |
Brake IGBT (g) |
Y - Brake IGBT fitted |
Internal braking resistor (h) |
N - No internal braking resistor |
Emission class (i) |
A - CE filter fitted, CM choke fitted |
Comm slot (j) |
D - DeviceNet |
Control and I/O (k) |
C - Vector control, 24 V DC I/O |
Feedback (l) |
1 - Encoder, 12 V/5 V |
Rating code |
011 - read as the output current in amps |
Source |
20B-TD001 p.6-7 catalog explanation; rating and frame from the Rockwell rating tables |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 20B-TD001 (Sept 2023) (module specifications) and 20B-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
The string is 20B (drive), C (voltage), 011 (output current in amps), then nine option positions d to l.
Here: d=A, e=0, f=A, g=Y, h=N, i=A, j=D, k=C, l=1.
Two more positions m and n exist for future use and special firmware; they are omitted on most orders.
Enclosure (d): IP 20, NEMA/UL Type 1, with conformal coating.
HIM (e): Blank cover. Remote HIM codes J and K mount on a panel door and need the stand-alone IP 54 enclosure.
Brake IGBT (g): Brake IGBT fitted. Internal braking resistor (h): No internal braking resistor; Rockwell does not offer the internal resistor on frame 3 and larger.
Emission (i): CE filter fitted, CM choke fitted. Comm slot (j): DeviceNet. Control and I/O (k): Vector control, 24 V DC I/O. Feedback (l): Encoder, 12 V/5 V.
A 20BD drive is the 480 V AC three-phase member of the PowerFlex 700 family: three-phase input, three-phase output, 0 to rated motor voltage on the output.
The current code is the drive output current in amps, so the same code reappears across the 400 V and 480 V families with different kW values - the kW figure here is the 480 V one.
Sensorless vector control with full tuning is standard; the k position decides whether the I/O is 24 V DC/AC or 115 V AC.
Nameplate catalog number, all 16 characters, against this page.
Whether the frame 5 or 6 enclosure is present; open/flange (d=F) and stand-alone (d=G) drives are the same chassis in different packaging.
Encoder board presence (l=1) and the brake IGBT (g=Y), because both are separate hardware, not parameters.
Positions, voltage classes and option codes are transcribed from 20B-TD001 (September 2023), Catalog Number Explanation, pages 6 and 7, and cross-checked against 20B-UM001 page P-5.
Current, power and frame figures are taken from the Rockwell Automation product page for this catalog number; where that page carries no power rating, none is shown here.
What is 20BC011A0AYNADC1?
PowerFlex 700 drive, 400 V AC, 3-phase, 50/60 Hz, 11.5 A output.
What is the output current of 20BC011A0AYNADC1?
11.5 A.
What does the C code mean?
400 V AC, 3-phase, 50/60 Hz.
Does 20BC011A0AYNADC1 have a communication option?
DeviceNet.
What enclosure is 20BC011A0AYNADC1?
IP 20, NEMA/UL Type 1, with conformal coating.
