2711-NL6 is Replacement backlight from the PanelView Standard accessory range: Replacement Backlight for PanelView 1000 Color Terminals (Series B).
It is ordered by this catalog number and matched to the terminal series printed on the nameplate.
| 2711-NL7 | Replacement Backlight for PanelView 1000 Color Terminals (Series C) | IN STOCK |
| 2711-NL6 | Replacement Backlight for PanelView 1000 Color Terminals (Series B) | IN STOCK |
| 2711-NL5 | Replacement Backlight, Series C, PanelView 600 Keypad or Keypad and Touch Screen Terminal | IN STOCK |
| 2711-NL1 | Replacement Backlight for PanelView 550 Series A to G | IN STOCK |
Application |
2711 PanelView Standard Terminal Accessories, Replacement Backlight for PanelView 1000 Color Terminals (Series B) |
Cat Num |
2711-NL6 |
Brand Name |
Rockwell |
Product Type |
Replacement backlight |
Fits |
PanelView 1000 Color, Series B |
Light Type |
Replacement backlight |
Lifecycle |
Discontinued April 30, 2021 |
Replacement |
Engineering Replacement |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 2711-UM014 (module specifications) and 2711-TD007 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
Official Rockwell description: 2711 PanelView Standard Terminal Accessories, Replacement Backlight for PanelView 1000 Color Terminals (Series B).
The backlight is a lamp assembly inside the PanelView Standard display; it is the part that is replaced when the screen has gone dim, pink or dark while the terminal still runs the application.
Fits: PanelView 1000 Color, Series B.
Light Type: Replacement backlight.
Rockwell Automation discontinued 2711-NL6 on April 30, 2021; replacement category: Engineering Replacement.
This is a standard-range accessory, and the terminals it serves are themselves out of production, so the spare is either bought from remaining stock or the whole front is replaced by a PanelView Plus unit with its own accessory numbering.
The colour series letter is part of the match: a Series B display and a Series C display of the same screen size take different backlight assemblies.
Replace the lamp with the terminal powered down and the front bezel removed; the assembly is held by screws on the display chassis, not by the logic board.
The page states the catalog number, the terminal series it fits and the published discontinuation date; nothing else is presented as specification.
A photograph of the terminal nameplate beside the old part settles the match, because both the screen size and the series letter belong to the identity of the part.
The row in red in the table at the top is the item on this page; the other rows are the rest of the same family carried by this site.
What is 2711-NL6?
2711 PanelView Standard Terminal Accessories, Replacement Backlight for PanelView 1000 Color Terminals (Series B).
What does 2711-NL6 fit?
PanelView 1000 Color, Series B.
Is 2711-NL6 discontinued?
Rockwell discontinued it on April 30, 2021; replacement category: Engineering Replacement.
Can 2711-NL6 be replaced by another catalog number in the same family?
No: the family is split by screen size, series letter or cable length, and each number holds its own place in it.
What has to be checked before ordering 2711-NL6?
The terminal nameplate: model, series letter and, for a cable, the installed run length.
