The 2711P-RDT10C is Touch display module for the PanelView Plus range: PanelView Plus Display Touch Screen, 10.4-inch TFT Display, Color, No Options.
a display module is the front of the terminal - display, backlight, touch screen or keypad. It is exchanged while the logic module stays in the panel
| 2711P-RDT7C | 700 touch color display, LED backlight | IN STOCK |
| 2711P-RDK7C | 700 keypad color display module, LED backlight | IN STOCK |
| 2711P-RDB7C | PanelView Plus Display Keypad/Touch, 6.5-inch TFT Displays, Color, No Options | IN STOCK |
| 2711P-RDT10C | PanelView Plus Display Touch Screen, 10.4-inch TFT Display, Color, No Options | IN STOCK |
| 2711P-RDT10CM | PanelView Plus Display Touch Screen, 10.4-inch TFT Display, Color, Marine Certified | IN STOCK |
| 2711P-RDK10C | PanelView Plus Display Keypad, 10.4-inch TFT Display, Color, No Options | IN STOCK |
| 2711P-RDB10C | PanelView Plus Display Keypad/Touch, 10.4-inch TFT Display, Color, No Options | IN STOCK |
| 2711P-RDT12C | PanelView Plus Display Touch Screen, 12.1-inch TFT Display, Color, No Options | IN STOCK |
| 2711P-RDT12H | PanelView Plus Display Touch Screen, 12.1-inch TFT Display, None, High Bright | IN STOCK |
| 2711P-RDK12C | PanelView Plus Display Keypad, 12.1-inch TFT Display, Color, No Options | IN STOCK |
| 2711P-RDB12C | PanelView Plus Display Keypad/Touch, 12.1-inch TFT Display, Color, No Options | IN STOCK |
| 2711P-RDT15C | PanelView Plus Display Touch Screen, 15-inch TFT Display, Color, No Options | IN STOCK |
| 2711P-RDB15C | PanelView Plus Display Keypad/Touch, 15-inch TFT Display, Color | IN STOCK |
Application |
PanelView Plus Display Touch Screen, 10.4-inch TFT Display, Color, No Options |
Cat Num |
2711P-RDT10C |
Brand Name |
Rockwell |
Product Type |
Touch display module |
Display |
10.4 in color TFT, touch screen |
Fits |
PanelView Plus 6 1000 touch terminal |
Lifecycle |
Discontinued December 30, 2021 |
Replacement |
Engineering replacement |
Fits Family |
PanelView Plus 6 700...1500 terminals |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 2711P-UM006 (module specifications) and 2711P-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
Official Rockwell description: PanelView Plus Display Touch Screen, 10.4-inch TFT Display, Color, No Options.
Spare-part role: a display module is the front of the terminal - display, backlight, touch screen or keypad. It is exchanged while the logic module stays in the panel.
It is ordered by this catalog number alone; no terminal order is required, and the part is a service item, not a kit that includes a display or a logic module.
Display: 10.4 in color TFT, touch screen.
Fits: PanelView Plus 6 1000 touch terminal.
Rockwell Automation discontinued 2711P-RDT10C on December 30, 2021; the replacement category published for it is: Engineering replacement.
A discontinued spare is bought for one of three reasons: the machine is still in production and must keep the same front, the line is being cloned, or the panel is waiting for a planned migration and needs to run until then.
Check the terminal-side catalog number before ordering a replacement: a display module must match the input style of the front it sits on, and a logic module must match the power input (AC or DC) of the panel it serves.
A display module is the whole front: display, backlight, touch screen or keypad, and the overlay. It is replaced in the panel while the logic module stays mounted.
Input style must match the terminal: a touch display cannot be fitted to a keypad logic-front combination without changing the front, and a keypad/touch module has both surfaces.
High-bright and marine-certified variants are separate catalog numbers; a standard module does not substitute for either, because the certification and the optical stack differ.
The part number, not the terminal model, is what identifies this item; a photograph of the old part and the terminal nameplate settle the match.
For a logic module, confirm the power input letter (A or D) and the operating-system digit (8 or 9) before ordering; for a display module, confirm the input style (touch, keypad, keypad/touch) and whether the terminal is standard, marine or high-bright.
Ask for the date code when the part is a service exchange: an aged electrolytic or a lamp with run hours already on it costs the same as a fresh unit but fails sooner.
The table lists every catalog number of this part family that this site carries, with the official one-line description; the row in red is the item on this page.
Parts within one family are not interchangeable across rows: the description carries the size, the input style or the certification that separates them.
What is 2711P-RDT10C?
PanelView Plus Display Touch Screen, 10.4-inch TFT Display, Color, No Options.
Which terminal does 2711P-RDT10C fit?
PanelView Plus 6 1000 touch terminal.
Is 2711P-RDT10C still available?
Rockwell discontinued it on December 30, 2021; replacement category: Engineering replacement.
Does 2711P-RDT10C include the logic module?
No. The display module is the front assembly; the logic module is ordered separately and stays in the panel during the swap.
Can a standard display replace a high-bright one?
No. High-bright and marine variants carry their own catalog number and optical stack.
