Allen Bradley PLC 1746-IC16 / 1746IC16

China Allen Bradley PLC 1746-IC16 / 1746IC16 supplier
Allen Bradley PLC 1746-IC16 / 1746IC16 supplier Allen Bradley PLC 1746-IC16 / 1746IC16 supplier Allen Bradley PLC 1746-IC16 / 1746IC16 supplier Allen Bradley PLC 1746-IC16 / 1746IC16 supplier Allen Bradley PLC 1746-IC16 / 1746IC16 supplier Allen Bradley PLC 1746-IC16 / 1746IC16 supplier Allen Bradley PLC 1746-IC16 / 1746IC16 supplier

Large Image :  Allen Bradley PLC 1746-IC16 / 1746IC16

Product Details:

Place of Origin: Made in SINGAPORE
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PLC 1746-IC16 / 1746IC16

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $245.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: Paypal, T/T and Western Union.
Supply Ability: 5 PCS
Detailed Product Description

1746-IC16 technical data PDF download 1746-IC16 16 Point 48V DC Input Module

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: SLC 500 DC input module

1746-IC16 is the 16 Point 48V DC Input Module in the Allen-Bradley SLC 500 range: Input Module, Digital, 48V DC, Sinking Input, 16 Point.

It sits in an SLC 500 chassis slot and exchanges data with the processor through the backplane image table; the points, voltage category and backplane current below are what decide whether it fits the slot and the power budget.

1746-IB8 8 Point DC Input Module IN STOCK
1746-IB16 16 Point DC Input Module IN STOCK
1746-IB32 32 Point DC Input Module IN STOCK
1746-IC16 16 Point 48V DC Input Module IN STOCK
1746-IH16 16 Point 125V DC Input Module IN STOCK
1746-ITB16 16 Point Fast Response DC Input Module IN STOCK
1746-ITV16 16 Point Fast Response DC Sourcing Input Module IN STOCK
1746-IV8 8 Point Digital Input Module IN STOCK
1746-IV16 16 Point Digital Input Module IN STOCK
1746-IV32 32 Point Digital Input Module IN STOCK

Product Specifications 1746-IC16 (PDF)
 Application
 Input Module, Digital, 48V DC, Sinking Input, 16 Point
 Cat Num
 1746-IC16
 Brand Name
 Rockwell
 Product Type
 16 Point 48V DC Input Module
 Points
 16 inputs
 Points per common
 16
 Voltage category
 48V DC signal input (sinking)
 Operating voltage
 30...60V DC @ 55 °C, 30...55V DC @ 60 °C (sinking)
 Backplane current, 5V DC
 0.050 A
 Backplane current, 24V DC
 0.0 A
 Signal delay, max
 On = 8 ms, Off = 8 ms
 Isolation
 1500V, electro-optical to control logic
 Lifecycle
 Discontinued
 Discontinued date
 December 31, 2014
 Replacement category
 Engineering Replacement

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1746-IN027 (module specifications) and 1747-UM011 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

1746-IC16 original product photograph 1 1746-IC16 original product photograph 2 1746-IC16 original product photograph 3

What 1746-IC16 is

Official Rockwell description: Input Module, Digital, 48V DC, Sinking Input, 16 Point.

16 Point 48V DC Input Module, with 16 inputs and 16 per common terminal.

Technical data

Application: Input Module, Digital, 48V DC, Sinking Input, 16 Point.

Cat Num: 1746-IC16.

Brand Name: Rockwell.

Product Type: 16 Point 48V DC Input Module.

Points: 16 inputs.

Points per common: 16.

Voltage category: 48V DC signal input (sinking).

Operating voltage: 30...60V DC @ 55 °C, 30...55V DC @ 60 °C (sinking).

Backplane current, 5V DC: 0.050 A.

Backplane current, 24V DC: 0.0 A.

Signal delay, max: On = 8 ms, Off = 8 ms.

Isolation: 1500V, electro-optical to control logic.

Lifecycle: Discontinued.

Discontinued date: December 31, 2014.

Replacement category: Engineering Replacement.

Wiring and commissioning notes

A sinking input expects the field device to pull the terminal to DC common, a sourcing input expects the device to feed +24V DC into the terminal. Mixing the two conventions is the usual reason an input reads ON with nothing connected.

Off-state current is the leakage the input tolerates without turning on, so a two-wire sensor above that figure needs a loading resistor across the input.

Fast-response cards shorten the ON delay from 8 ms to 0.3 ms for a registration mark or a short pulse that a standard card would miss.

Lifecycle and migration route

Rockwell lists 1746-IC16 as Discontinued, with the discontinued date December 31, 2014 and the replacement category Engineering Replacement.

No replacement catalog number is printed on the Rockwell page, so the route is an engineering substitution rather than a direct part-for-part swap.

Rockwell's own migration guidance for Bulletin 1746 I/O points to the Compact 5000 I/O platform with a Logix controller; a machine that stays on SLC 500 is served from the secondary market.

The enclosure, the terminal armature and the address assignment are unchanged when a card is replaced by the same catalog number, which is why the original number keeps a value after the end of sale.

Power budget and slot rules

A modular SLC 500 chassis reserves slot 0 for the processor or the adapter, so this card goes in any other I/O slot; a fixed controller chassis has a published power limit instead of a slot rule.

The backplane current above is added to the draw of every other card in the chassis and compared with the chassis supply before a card is added, which is the check that prevents an intermittent chassis fault after a retrofit.

Electro-optical isolation between the field terminals and the control logic is 1500V, and the operating range of the whole family is 0...60 °C with 5...95% noncondensing humidity and NEMA ICS 2-230 noise immunity.

Related cards in this family

  • 1746-IB8 — 8 Point DC Input Module
  • 1746-IB16 — 16 Point DC Input Module
  • 1746-IB32 — 32 Point DC Input Module
  • 1746-IC16 — 16 Point 48V DC Input Module
  • 1746-IH16 — 16 Point 125V DC Input Module
  • 1746-ITB16 — 16 Point Fast Response DC Input Module
  • 1746-ITV16 — 16 Point Fast Response DC Sourcing Input Module
  • 1746-IV8 — 8 Point Digital Input Module
  • 1746-IV16 — 16 Point Digital Input Module
  • 1746-IV32 — 32 Point Digital Input Module

The card in red in the table at the top is the one on this page.

FAQ — 1746-IC16

What is 1746-IC16?

Input Module, Digital, 48V DC, Sinking Input, 16 Point. 16 Point 48V DC Input Module.

How many points does 1746-IC16 have?

16 inputs, 16 per common.

What voltage does 1746-IC16 work at?

48V DC signal input (sinking), operating range 30...60V DC @ 55 °C, 30...55V DC @ 60 °C (sinking).

Is 1746-IC16 still available?

Rockwell lists it as Discontinued with the discontinued date December 31, 2014, replacement category Engineering Replacement.

What has to be checked before fitting 1746-IC16?

The backplane current against the chassis supply, the sinking or sourcing convention of the field devices, and the terminal block, which is removable and often missing on a used card.


Data sources. Technical values on this page come from Rockwell publication 1746-IN027 (SLC 500 Digital I/O Modules) and the Rockwell product page for this catalog number. Any attribute the publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
