Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104

China Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier
Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104 supplier

Large Image :  Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104

Product Details:

Place of Origin: Made in CHINA
Brand Name: PLC Module
Certification: All goods we supply are 100% original factory sealed with 1 year warranty!
Model Number: Allen Bradley PowerFlex 22A-D6P0N104 / 22AD6P0N104

Payment & Shipping Terms:

Minimum Order Quantity: 1 /PCS
Price: $296.00 (USD/PCS)
Packaging Details: 100% original new
Delivery Time: IN STOCK; 4-6 weeks for ordering
Payment Terms: T/T, Western Union and Paypal.
Supply Ability: 5 PCS
Detailed Product Description

22AD6P0N104 technical data PDF download 22AD6P0N104 PowerFlex 4 2.2 kW 3.0 HP AC drive

Category: PLCs, Power Supplies & I/Os
Manufacturer: Rockwell
Group: PowerFlex 70 drives

22AD6P0N104 is an PowerFlex 4 drive: 480 V AC, three phase, 6.0 A output, 2.2 kW / 3.0 HP, frame A.

PowerFlex 4 is the entry member of the PowerFlex family: volts per hertz control, a fixed keypad with speed pot, and the same 4-digit display and parameter set as the larger 4M and 40 drives.

Quick answer. 22AD6P0N104 is a Rockwell Automation PowerFlex 70 drive, 400 V AC, normal duty (), frame A, .

  • Normal duty output current:
  • Motor rating:
  • Frame: A
  • Enclosure:
  • Communication slot:
  • Control and I/O:
22AV6P0H204 1.5 kW / 2.0 HP IN STOCK
22AB8P0N104 1.5 kW / 2.0 HP IN STOCK
22AD1P4H204 0.4 kW / 0.5 HP IN STOCK
22AD1P4N104 0.4 kW / 0.5 HP IN STOCK
22AD2P3F104 0.75 kW / 1.0 HP IN STOCK
22AD2P3H204 0.75 kW / 1.0 HP IN STOCK
22AD4P0H204 1.5 kW / 2.0 HP IN STOCK
22AD4P0N104 1.5 kW / 2.0 HP IN STOCK
22AD6P0H204 2.2 kW / 3.0 HP IN STOCK
22AD6P0N104 2.2 kW / 3.0 HP IN STOCK
22AD8P7H204 3.7 kW / 5.0 HP IN STOCK
22AV6P0N104 1.5 kW / 2.0 HP IN STOCK

Product Specifications 22AD6P0N104 (PDF)
 Catalog number
 22AD6P0N104
 Voltage rating (b)
 D - 480 V AC, three phase
 Output current rating (c)
 6.0 A
 Power rating
 2.2 kW / 3.0 HP
 Frame size
 A
 Enclosure (d N)
 Panel mount, IP20 NEMA/UL Type Open
 Interface module (e 1)
 Fixed keypad with speed pot
 Emission class (f 0)
 not filtered
 Brake IGBT (g 4)
 with brake IGBT
 Rating code
 6P0 - output current in amps
 Source
 22-TD001 p.9 Product Selection table

Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 22-TD001 (Sept 2024) (module specifications) and 22A-UM001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.

22AD6P0N104 22AD6P0N104 22AD6P0N104 22AD6P0N104 22AD6P0N104 22AD6P0N104 22AD6P0N104

How to read this catalog number

22A is the PowerFlex 4 family; position b is the voltage class, here 480 V AC, three phase.

Positions 6 to 8 are the output current code, 6P0, which reads as 6.0 A - the same code means a different kW on another voltage class.

Position d is the enclosure letter, e the interface module, f the emission class, g the brake IGBT; the final two characters are reserved.

What the rating means on this voltage class

At 480 V AC, three phase the drive delivers 6.0 A continuous at 2.2 kW (3.0 HP), with 150% overload for 60 seconds and 200% for 3 seconds.

Control is volts per hertz with auto boost and slip compensation. Sensorless vector and the process PID loop are not part of the PowerFlex 4 feature set - that is what the 4M and 40 add.

Frame A sets the DIN rail and panel mounting options and the space needed around the drive.

Installation and environment

DIN rail mounting is standard on the PowerFlex 4 frames, with an optional panel mount kit.

A removable MOV to ground allows the drive to run on ungrounded distribution systems, and a relay pre-charge limits inrush current.

An integral keypad with speed potentiometer is fitted as standard, so the drive can be commissioned without a PC.

What to verify before buying

The full catalog number, because the enclosure letter (d) and brake digit (g) change the hardware.

Whether the EMC filter digit is 1; unfiltered drives need an external filter to meet EN 61800-3.

The frame size against the panel space, since frame B is wider and needs clearance for heat sinks.

Documented source

Voltage classes, current codes, kW and HP values, frame sizes, enclosure and option codes are transcribed from 22-TD001 (September 2024), Catalog Number Explanation on page 8 and Product Selection on page 9.

Feature statements - V/Hz control, DIN rail mounting, removable MOV, integral keypad with speed pot - come from the feature comparison on page 7.

FAQ — 22AD6P0N104

What is 22AD6P0N104?

PowerFlex 4 AC drive, 480 V AC, three phase, 6.0 A, 2.2 kW / 3.0 HP, frame A.

What is the output current of 22AD6P0N104?

6.0 A at 480 V AC, three phase.

What power rating does 22AD6P0N104 have?

2.2 kW, 3.0 HP.

What frame size is 22AD6P0N104?

Frame A.

What control type does the PowerFlex 4 use?

Volts per hertz with auto boost and slip compensation.

Related catalog numbers in the same rating code. Same A power stage, different option string - the enclosure, HIM, communication and safety positions are what change between them.

22AA1P4N103 (0.2 kW / 0.25 HP) · 22AA1P4N113 (0.2 kW / 0.25 HP) · 22AA1P5F104 (0.2 kW / 0.25 HP) · 22AA1P5H204 (0.2 kW / 0.25 HP) · 22AA1P5N104 (0.2 kW / 0.25 HP) · 22AA1P5N114 (0.2 kW / 0.25 HP) · 22AA2P1N103 (0.4 kW / 0.5 HP) · 22AA2P1N113 (0.4 kW / 0.5 HP) · 22AA2P3H204 (0.4 kW / 0.5 HP) · 22AA2P3N104 (0.4 kW / 0.5 HP)


Data sources. Decoded from Rockwell 22-TD001 p.8-9 Catalog Number Explanation and Product Selection Any attribute a publication does not print is marked Not published rather than taken from a distributor page. Catalog number, packaging and stock status are the stock record of this listing.
