The 2711P-K12C4D9 is a PanelView Plus 6 1250-model terminal: 12.1 in at 800 x 600 (SVGA) on a color TFT, with keypad input and 24V DC over 18...32V DC.
All 700...1500 terminals carry Ethernet, RS-232 and two USB host ports, a rear communication module slot for DH+/DH-485 or ControlNet, and 512 MB RAM with 512 MB nonvolatile memory. The suffix 9 adds the extended Windows CE 6.0 features; display, power and cutout are unchanged.
| 2711P-K10C4A8 | Keypad, color, Ethernet + RS-232 + 2 USB, AC input | IN STOCK |
| 2711P-T10C4A8 | Touch, color, Ethernet + RS-232 + 2 USB, AC input | IN STOCK |
| 2711P-B10C4A8 | Keypad and touch, color, Ethernet + RS-232 + 2 USB, AC | IN STOCK |
| 2711P-K10C4D8 | Keypad, color, Ethernet + RS-232 + 2 USB, DC input | IN STOCK |
| 2711P-T10C4D8 | Touch, color, Ethernet + RS-232 + 2 USB, DC input | IN STOCK |
| 2711P-B10C4D8 | Keypad and touch, color, Ethernet + RS-232 + 2 USB, DC | IN STOCK |
| 2711P-K10C4A9 | Keypad, color, Ethernet + RS-232 + 2 USB, AC, extended CE | IN STOCK |
| 2711P-T10C4A9 | Touch, color, Ethernet + RS-232 + 2 USB, AC, extended CE | IN STOCK |
| 2711P-B10C4A9 | Keypad and touch, color, AC, extended CE features | IN STOCK |
| 2711P-K10C4D9 | Keypad, color, Ethernet + RS-232 + 2 USB, DC, extended CE | IN STOCK |
| 2711P-T10C4D9 | Touch, color, Ethernet + RS-232 + 2 USB, DC, extended CE | IN STOCK |
| 2711P-B10C4D9 | Keypad and touch, color, DC, extended CE features | IN STOCK |
Application |
PanelView Plus 6 operator terminal, 1250 model, 12.1 in |
Cat Num |
2711P-K12C4D9 |
Brand Name |
Rockwell |
Display Size |
12.1 in |
Display Type |
Color active-matrix TFT |
Resolution |
800 x 600 (SVGA) |
Colour Depth |
18-bit color graphics |
Active Area |
246 x 184 mm |
Brightness |
300 cd/m2 |
Operator Input |
Keypad |
Touch Screen |
Not fitted |
Communication Ports |
Ethernet 10/100, RS-232, 2 USB host, plus one communication module slot |
Input Power |
24V DC nom, 18...32V DC range |
Power Consumption |
70 W max, 2.9 A at 24V DC; 39 W typical |
Memory |
512 MB RAM, 512 MB nonvolatile (approx. 79 MB free user memory) |
Operating System |
Windows CE 6.0 with extended features |
Removable Storage |
Hot-swappable SD slot, 1784-SDx / 1784-SDHCx |
Panel Cutout |
257 x 390 mm (10.11 x 15.35 in) |
Dimensions |
282 x 416 x 55 mm |
Weight |
3.4 kg approx. |
Backlight |
CCFL, 50,000 h min at 25 deg C, field replaceable |
Clock Battery |
2711P-RY2032 (CR2032), 4 years min at 25 deg C |
Degree Of Protection |
NEMA Type 12, 13, 4X indoor and IP54, IP65 (front) |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 2711P-UM006 (module specifications) and 2711P-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
The 1250 model is the 12.1 in size of the PanelView Plus 6 range: 800 x 600 (SVGA), 18-bit color, active area 246 x 184 mm, 300 cd/m2. Operator input is the stainless-steel membrane keypad with numeric, navigation and function keys; there is no touch screen, so the application must be built for key navigation.
The front measures 282 x 416 and sits 55 mm behind the panel; the cutout is 257 x 390 mm (10.11 x 15.35 in).
The larger the front, the more the enclosure carries: 3.4 kg approx. of terminal hangs on the mounting levers together with the door, so check hinge rating and panel thickness before installing.
Display: 12.1 in, 800 x 600 (SVGA), 18-bit color, active area 246 x 184 mm, 300 cd/m2. The backlight is a cold-cathode fluorescent lamp rated 50,000 hours minimum at 25 deg C and is field replaceable on 700...1500 terminals, unlike the LED backlight of the 400 and 600 models.
Input power: 24V DC nom (18...32V DC), 70 W max (2.9 A at 24V DC), 39 W typical. A 1500-model AC terminal is rated 160 VA maximum and 65 VA typical; the DC terminals draw 70 W maximum (2.9 A at 24V DC) and 39 W typical, so size the supply on the maximum figures and the heat budget on the typical ones.
CCFL thermal control: when the internal temperature falls below 10 deg C the backlight runs at full rated current for at least five minutes to warm the display, and above 60 deg C it is underdriven to 40% or less of full brightness. This changes intensity only, so a dim screen in a cold or hot cabinet is normal behaviour, not a failure.
Front protection is NEMA Type 12, 13 and 4X indoor plus IP54 and IP65; relative humidity 5...95% noncondensing, 15 G shock at 11 ms, operating altitude up to 2000 m.
Cut 257 x 390 mm (10.11 x 15.35 in) using the template supplied with the terminal. Depth to the rear of the logic module is 55 mm and the communication module adds more, so keep at least 100 mm clear where a module is fitted.
A touch front and a keypad front need different openings in this size as well: 257 x 338 mm (10.11 x 13.29 in) against 257 x 390 mm (10.11 x 15.35 in). Decide the catalog number before the enclosure is cut.
Torque the mounting levers evenly and re-check the corners; on a 12.1 in front one slack lever shows up as an IP65 leak at the gasket.
DC: 18...32V DC, 70 W maximum, 2.9 A at 24V DC, 39 W typical. AC: 100...240V AC, 50...60 Hz, 160 VA maximum, 65 VA typical.
Power terminal blocks accept 0.3...2.1 mm2 (22...14 AWG) 90 deg C copper at 0.45...0.56 N m (4...5 lb in), two wires per terminal up to 1.3 mm2 (16 AWG).
Functional earth is mandatory: the DC negative is internally tied to the FE terminal and the AC input relies on protective earth. Land the earth conductor first and torque it before the terminal cover goes back on.
The real-time clock is backed by a 2711P-RY2032 coin cell, 4 years minimum at 25 deg C, and drifts about plus or minus 2 minutes per month.
Standard: Ethernet 10/100 with auto MDI/MDI-X, RS-232, two USB 2.0 host ports, and a rear slot for a DH+/DH-485 or ControlNet communication module, scheduled or unscheduled.
Ethernet serves EtherNet/IP tag access, FactoryTalk ViewPoint clients and project download; RS-232 covers DF1, ASCII, bar-code readers and printers; a USB flash drive moves applications and data logs without touching the network.
FactoryTalk View Machine Edition 6.10 or later is required. The hot-swappable SD slot takes 1784-SDx and 1784-SDHCx cards for file transfer, firmware upgrade and data logging.
USB circuit parameters for nonincendive field wiring: 5.25V DC, 1.68 A short-circuit current, 10 microfarad, 15 microhenry.
Three choices separate the rows in this size: operator input (keypad, touch, or keypad and touch), input power (AC or DC), and the operating system suffix (8 = Windows CE 6.0, 9 = Windows CE 6.0 with extended features). Display, memory and communication are identical across the size.
Touch-only keeps the smaller opening (257 x 338 mm (10.11 x 13.29 in)) and the lighter 3.2 kg approx. front; any keypad front moves to 257 x 390 mm (10.11 x 15.35 in) and 3.4 kg approx.. If the application is already written for touch, adding a keypad buys nothing except panel area and mass.
AC input suits a cabinet that already has 100...240V; DC input at 70 W maximum is the lighter load where a 24V supply with the current headroom exists. Suffix 9 adds the extended Windows CE features needed by some older FactoryTalk View ME projects.
Does 2711P-K12C4D9 have a touch screen?
No. This terminal is keypad only; the touch 1250 model is 2711P-T12C4D9.
What cutout does 2711P-K12C4D9 need?
257 x 390 mm (10.11 x 15.35 in). The front measures 282 x 416 with a 55 mm depth.
What resolution does 2711P-K12C4D9 display?
800 x 600 (SVGA) with 18-bit color on a 246 x 184 mm active area.
How much power does 2711P-K12C4D9 draw?
18...32V DC, 70 W maximum (2.9 A at 24V DC) and 39 W typical.
Is the backlight of 2711P-K12C4D9 replaceable?
Yes. 700...1500 terminals use a field-replaceable CCFL backlight rated 50,000 hours minimum at 25 deg C; the 400 and 600 models use a non-replaceable LED backlight.
How heavy is 2711P-K12C4D9?
3.4 kg approx. for this front; the touch version of the same size is 3.2 kg approx..
Which communication options does 2711P-K12C4D9 support?
Ethernet 10/100, RS-232 and two USB host ports are standard; the rear slot accepts a DH+/DH-485 or ControlNet communication module.
What memory does 2711P-K12C4D9 have?
512 MB RAM and 512 MB nonvolatile memory, about 79 MB free for the application, on Windows CE 6.0 with extended features.
What replaces the clock battery in 2711P-K12C4D9?
2711P-RY2032, an equivalent CR2032 coin cell, 4 years minimum at 25 deg C.
