The 2711P-K7C4D9 is the 700-model terminal of the PanelView Plus 6 range: 6.5 in, 640 x 480 (VGA), active area 132 x 99 mm, 300 cd/m2, with keypad and 24V DC input over 18...32V DC.
The 700 model is the smallest of the 700...1500 family and the only size that keeps a 640 x 480 pixel map while shrinking the front to 193 x 290. A 1000-model application transfers to it unchanged, which is why this catalog number is still specified for compact machines.
| 2711P-K10C4A8 | Keypad, color, Ethernet + RS-232 + 2 USB, AC input | IN STOCK |
| 2711P-T10C4A8 | Touch, color, Ethernet + RS-232 + 2 USB, AC input | IN STOCK |
| 2711P-B10C4A8 | Keypad and touch, color, Ethernet + RS-232 + 2 USB, AC | IN STOCK |
| 2711P-K10C4D8 | Keypad, color, Ethernet + RS-232 + 2 USB, DC input | IN STOCK |
| 2711P-T10C4D8 | Touch, color, Ethernet + RS-232 + 2 USB, DC input | IN STOCK |
| 2711P-B10C4D8 | Keypad and touch, color, Ethernet + RS-232 + 2 USB, DC | IN STOCK |
| 2711P-K10C4A9 | Keypad, color, Ethernet + RS-232 + 2 USB, AC, extended CE | IN STOCK |
| 2711P-T10C4A9 | Touch, color, Ethernet + RS-232 + 2 USB, AC, extended CE | IN STOCK |
| 2711P-B10C4A9 | Keypad and touch, color, AC, extended CE features | IN STOCK |
| 2711P-K10C4D9 | Keypad, color, Ethernet + RS-232 + 2 USB, DC, extended CE | IN STOCK |
| 2711P-T10C4D9 | Touch, color, Ethernet + RS-232 + 2 USB, DC, extended CE | IN STOCK |
| 2711P-B10C4D9 | Keypad and touch, color, DC, extended CE features | IN STOCK |
Application |
PanelView Plus 6 operator terminal, 700 model, 6.5 in |
Cat Num |
2711P-K7C4D9 |
Brand Name |
Rockwell |
Display Size |
6.5 in |
Display Type |
Color active-matrix TFT |
Resolution |
640 x 480 (VGA) |
Colour Depth |
18-bit color graphics |
Active Area |
132 x 99 mm |
Brightness |
300 cd/m2 |
Operator Input |
Keypad |
Touch Screen |
Not fitted |
Keypad |
22 function keys F1...F10 and K1...K12, stainless-steel membrane, 1 million presses, 340 g operating force |
Communication Ports |
Ethernet 10/100, RS-232, 2 USB host, plus one communication module slot |
Input Power |
24V DC nom, 18...32V DC range |
Power Consumption |
70 W max, 2.9 A at 24V DC, 39 W typical |
Memory |
512 MB RAM, 512 MB nonvolatile (approx. 79 MB free user memory) |
Operating System |
Windows CE 6.0 with extended features |
Removable Storage |
Hot-swappable SD slot, 1784-SDx / 1784-SDHCx |
Panel Cutout |
167 x 264 mm |
Dimensions |
193 x 290 x 55 mm |
Weight |
1.8 kg approx. |
Backlight |
CCFL, 50,000 h min at 25 deg C, field replaceable |
Clock Battery |
2711P-RY2032 (CR2032), 4 years min at 25 deg C |
Degree of Protection |
NEMA Type 12, 13, 4X indoor and IP54, IP65 |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 2711P-UM006 (module specifications) and 2711P-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
PanelView Plus 6 700 model: 6.5 in color TFT, 640 x 480 (VGA), active area 132 x 99 mm, 300 cd/m2. Operator input is the membrane keypad - 22 function keys F1...F10 and K1...K12, stainless-steel membrane, 1 million presses, 340 g operating force - with no touch layer, so every screen has to be reachable by key navigation.
The front measures 193 x 290 and the cutout is 167 x 264 mm; depth behind the panel is 55 mm, and the communication module in the rear slot adds about 28 mm more.
Only keypad and keypad/touch fronts use the wider 167 x 264 mm opening; a touch front needs 154 x 220 mm. Cutting the touch opening in a panel intended for a keypad model leaves the keypad front unable to seat, so settle the catalog number before the enclosure is fabricated.
Display: 6.5 in, 640 x 480 (VGA), 18-bit color, active area 132 x 99 mm, 300 cd/m2. The backlight is a cold-cathode fluorescent lamp rated 50,000 hours minimum at 25 deg C and is field replaceable on 700...1500 terminals - unlike the LED backlight of the 400 and 600 models.
Input power: 24V DC nom (18...32V DC), 70 W max (2.9 A at 24V DC), 39 W typical. The DC terminals accept 18...32V DC, a wider window than the 18...30V of the small models, and draw up to 2.9 A at 24V DC, so size the supply for 70 W, not 25 W.
Mass: 1.8 kg approx. for this front. A panel door carrying this size of terminal plus the enclosure load has to be held by the mounting levers, so confirm panel thickness is inside the lever range.
Environment: front rated NEMA Type 12, 13 and 4X indoor and IP54/IP65, relative humidity 5...95%% noncondensing, 15 G shock at 11 ms, operating altitude up to 2000 m.
CCFL thermal behaviour: below 10 deg C internal temperature the backlight is overdriven at full rated current for at least five minutes to warm the display, and above 60 deg C it is underdriven to 40%% or less of full brightness. Temperature control affects intensity only, so a cold cabinet start is not a fault.
Cut the opening 167 x 264 mm from the template shipped with the terminal. Leave at least 100 mm clear behind the panel where a communication module is fitted, and keep the lower rear face clear for the power terminal block and the earth conductor.
The DC terminal is not isolated from functional earth in this range either, so the supply must be SELV or Class 2 and the FE terminal must be wired. An AC supply needs protective earth on the three-position block.
Tighten the mounting levers evenly until the gasket compresses, then re-check the four corners; one uneven lever shows as an IP65 leak at the corner of a 6.5 in front.
DC: 18...32V DC, 70 W maximum, 2.9 A at 24V DC, 39 W typical. AC: 100...240V AC, 50...60 Hz, 160 VA maximum.
Power blocks accept 0.3...2.1 mm2 (22...14 AWG) 90 deg C copper at 0.45...0.56 N m (4...5 lb in); two wires per terminal are allowed up to 1.3 mm2 (16 AWG).
Functional earth is mandatory: the DC negative is internally tied to the FE terminal and the AC input relies on protective earth for EMC. Route the earth conductor first and torque it before closing the terminal cover.
The real-time clock runs from a 2711P-RY2032 coin cell, 4 years minimum at 25 deg C, accurate to about plus or minus 2 minutes per month.
Standard on this catalog number: Ethernet 10/100 with auto MDI/MDI-X, RS-232, two USB 2.0 host ports. The rear slot accepts a communication module for DH+/DH-485 or ControlNet, scheduled or unscheduled.
Ethernet carries EtherNet/IP tag access, FactoryTalk ViewPoint clients and project download; RS-232 covers DF1, ASCII, bar-code readers and printers; a USB flash drive moves applications and data logs without a network.
FactoryTalk View Machine Edition version 6.10 or later is required. The hot-swappable SD slot takes 1784-SDx and 1784-SDHCx cards for file transfer, firmware upgrade and data logging.
USB circuit parameters for nonincendive field wiring are 5.25V DC, 1.68 A short-circuit current, 10 microfarad and 15 microhenry.
Three choices define this terminal: operator input (keypad, touch, or keypad and touch), input power (AC or DC), and the operating system suffix (8 = Windows CE 6.0, 9 = Windows CE 6.0 with extended features). Color, VGA resolution, 512 MB memory and the 55 mm depth are common to every row.
Suffix 9 adds the extended Windows CE 6.0 features; display, power and cutout stay the same, so a 9 model replaces an 8 model on the same panel opening when the application needs the extra features.
Does 2711P-K7C4D9 have a touch screen?
No. This terminal is keypad only; the touch version of the same size and supply is the T counterpart in the catalog table above.
What cutout does 2711P-K7C4D9 need?
167 x 264 mm. The front measures 193 x 290 and the depth is 55 mm.
What is the display resolution of 2711P-K7C4D9?
640 x 480 (VGA), 18-bit color, active area 132 x 99 mm, 300 cd/m2.
How much power does 2711P-K7C4D9 draw?
18...32V DC, 70 W maximum (2.9 A at 24V DC), 39 W typical.
Is the backlight of 2711P-K7C4D9 replaceable?
Yes. The 700...1500 terminals use a field-replaceable CCFL backlight rated 50,000 hours minimum at 25 deg C; the 400 and 600 models use a non-replaceable LED backlight.
What memory does 2711P-K7C4D9 have?
512 MB RAM and 512 MB nonvolatile memory, about 79 MB free for the application.
Can a 700-model application run on a 2711P-K7C4D9 model?
Yes. Both use a 640 x 480 pixel map, so the FactoryTalk View ME application transfers without redesign; the cutout and the front size are what change.
What replaces the clock battery in 2711P-K7C4D9?
2711P-RY2032, an equivalent CR2032 coin cell, 4 years minimum at 25 deg C.
