The 2711P-K6C20A8 is a PanelView Plus 6 600-model terminal: 5.7 in color display, keypad, Ethernet, RS-232 and USB and 100...240V AC. Windows CE 6.0 is the factory operating system, with 256 MB RAM and 512 MB nonvolatile memory.
Catalog breakdown: 2711P- K = keypad, 6 = 5.7 in display, C = color, 20 = Ethernet + RS-232 + USB, A = AC input, 8 = Windows CE 6.0.
| 2711P-K6M5A8 | Keypad, grayscale 16 levels, RS-232 + USB, AC | IN STOCK |
| 2711P-T6M5A8 | Touch, grayscale 16 levels, RS-232 + USB, AC | IN STOCK |
| 2711P-B6M5A8 | Keypad and touch, grayscale, RS-232 + USB, AC | IN STOCK |
| 2711P-K6M5D8 | Keypad, grayscale 16 levels, RS-232 + USB, DC | IN STOCK |
| 2711P-T6M5D8 | Touch, grayscale 16 levels, RS-232 + USB, DC | IN STOCK |
| 2711P-B6M5D8 | Keypad and touch, grayscale, RS-232 + USB, DC | IN STOCK |
| 2711P-K6C5A8 | Keypad, color 18-bit, RS-232 + USB, AC | IN STOCK |
| 2711P-T6C5A8 | Touch, color 18-bit, RS-232 + USB, AC | IN STOCK |
| 2711P-B6C5A8 | Keypad and touch, color, RS-232 + USB, AC | IN STOCK |
| 2711P-K6C5D8 | Keypad, color 18-bit, RS-232 + USB, DC | IN STOCK |
| 2711P-T6C5D8 | Touch, color 18-bit, RS-232 + USB, DC | IN STOCK |
| 2711P-B6C5D8 | Keypad and touch, color, RS-232 + USB, DC | IN STOCK |
Application |
PanelView Plus 6 operator terminal, 600 model, machine-level HMI |
Cat Num |
2711P-K6C20A8 |
Brand Name |
Rockwell |
Display Size |
5.7 in |
Display Type |
Color active-matrix TFT |
Resolution |
320 x 240 |
Colour Depth |
18-bit color graphics |
Operator Input |
Keypad |
Touch Screen |
Not fitted |
Communication Ports |
Ethernet 10/100, RS-232 and USB |
USB Ports |
One USB 2.0 host port, one USB device port |
Input Power |
100...240V AC, 50...60 Hz |
Power Consumption |
60 VA max |
Memory |
256 MB RAM, 512 MB nonvolatile (approx. 73 MB free user memory) |
Operating System |
Windows CE 6.0 |
Removable Storage |
SD card slot, cat. no. 1784-SDx |
Panel Cutout |
142 x 241 mm (5.61 x 9.50 in) |
Dimensions |
167 x 266 mm front, 68 mm, 98 mm with the AC power module deep |
Weight |
728 g approx. |
Brightness |
440 cd/m2 |
Backlight |
White LED, not replaceable, 25,000 h min at 25 deg C |
Clock Battery |
2711P-RY2032 (CR2032), 4 years min at 25 deg C |
Degree of Protection |
NEMA Type 12, 13, 4X indoor and IP54, IP65 |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 2711P-UM006 (module specifications) and 2711P-TD001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
The 600 model is the smallest PanelView Plus 6 size offered with a touch screen, and it keeps the 320 x 240 pixel layout of the 3.5 in 400 model while raising the display to 5.7 in. Operator input is the membrane keypad with function keys, numeric entry and the arrow/Enter cluster, for panels operated with gloves or where the machine builder standardised on keypad entry.
The front measures 167 x 266 mm and the cutout is 142 x 241 mm (5.61 x 9.50 in); depth to the logic module is 68 mm, 98 mm with the AC power module, and the AC power module adds 30 mm.
Memory is 256 MB RAM and 512 MB nonvolatile, about 73 MB free for the application, with an SD slot for 1784-SDx cards. The 700...1500 terminals use a 512 MB/512 MB logic module, a different figure.
Display: 5.7 in, 320 x 240 pixels, 18-bit color TFT, brightness 440 cd/m2. The white LED backlight is rated 25,000 hours minimum at 25 deg C and is not field replaceable.
Input power: 100...240V AC (50...60 Hz), 60 VA max. The AC variant takes 100...240V AC at 50...60 Hz and needs protective earth on the power terminal block.
Mass: 728 g approx. for this input style; a touch-only front weighs 594 g, any keypad front 728 g. Leave room for the cable bend radius behind the 68 mm, 98 mm with the AC power module body.
Environment: NEMA Type 12, 13 and 4X indoor, IP54 and IP65 at the front, with the gasket compressed by the mounting levers.
Cut the opening 142 x 241 mm (5.61 x 9.50 in) from the template supplied with the terminal. Keypad and keypad/touch fronts need a wider 142 x 241 mm opening, so an existing 400 cutout cannot take this catalog number.
Depth to the logic module is 68 mm, 98 mm with the AC power module. Keep the lower rear face clear for the power block, the RS-232 connector and the USB ports, and route the earth conductor before clamping the levers.
Tighten the mounting levers evenly until the gasket compresses, then check the seal at all four corners before applying power.
DC terminals work over 18...30V DC at 25 W maximum (1.0 A at 24V DC). PanelView Plus 6 400 and 600 terminals have a nonisolated DC supply with DC negative tied internally to the functional earth terminal, so a floating supply is not permitted.
AC terminals take 100...240V AC at 50...60 Hz and 60 VA maximum, with protective earth on the terminal block.
Power blocks accept 0.3...2.1 mm2 (22...14 AWG) 90 deg C copper at 0.45...0.56 N m (4...5 lb in); two wires per terminal are allowed up to 1.3 mm2 (16 AWG).
The real-time clock is held by a 2711P-RY2032 coin cell rated 4 years minimum at 25 deg C, accurate to about plus or minus 2 minutes per month.
This catalog number carries Ethernet 10/100 with auto MDI/MDI-X, RS-232 and USB, one USB 2.0 host port for a keyboard, mouse or USB drive, and one USB device port for programming.
Ethernet option 20 is what lets the terminal read controller tags over EtherNet/IP or serve a FactoryTalk ViewPoint client; option 5 covers a single serial controller link, a bar-code reader or a printer.
FactoryTalk View Machine Edition version 6.10 or later is required on 400 and 600 terminals; projects built in 5.x must be converted before download. Transfer runs over Ethernet, serial or a 1784-SDx card.
USB circuit parameters for nonincendive field wiring are 5.25V DC, 1.68 A short-circuit current, 10 microfarad and 15 microhenry; peripherals in a classified area must stay within them.
Only two attributes separate the 600 catalog numbers that share a front: the communication option (5 = RS-232 + USB, 20 = Ethernet + RS-232 + USB) and the operating system suffix (8 = Windows CE 6.0, 9 = Windows CE 6.0 with extended features). Display, memory, power and cutout are unchanged, so a suffix 9 terminal drops into a cabinet built for suffix 8.
Color is the only display choice carrying suffix 9 in this size; grayscale catalog numbers are listed with suffix 8 only. Choose color where the HMI uses state colours or trends, grayscale for text, alarm and numeric screens.
AC input is chosen where a 100...240V feed already exists in the enclosure; DC input suits a 24V panel with a Class 2 or SELV supply. Ethernet is required for controller tag access, ViewPoint and network download, while RS-232-only terminals are limited to serial links and USB peripherals.
Does 2711P-K6C20A8 have a touch screen?
No. This catalog number is keypad only; the touch version of the 600 model is 2711P-T6620A8.
What cutout does 2711P-K6C20A8 need?
142 x 241 mm (5.61 x 9.50 in). The front measures 167 x 266 mm and the body is 68 mm, 98 mm with the AC power module deep.
Does 2711P-K6C20A8 have Ethernet?
Yes, 10/100Base-T with auto MDI/MDI-X, plus RS-232 and USB - communication option 20.
What supply does 2711P-K6C20A8 need?
100...240V AC, 50...60 Hz, 60 VA maximum, with protective earth connected.
What does the suffix 9 add on 2711P-K6C20A8?
Windows CE 6.0 with extended features instead of plain Windows CE 6.0. Display, memory, power and cutout are identical to the suffix 8 terminal.
How heavy is 2711P-K6C20A8?
728 g approx.; the touch-only front is listed at 594 g and any keypad front at 728 g.
Is the backlight of 2711P-K6C20A8 replaceable?
No. It is a white LED rated 25,000 hours minimum at 25 deg C and is not a field-replaceable part.
What replaces the clock battery in 2711P-K6C20A8?
2711P-RY2032, an equivalent CR2032 coin cell, 4 years minimum at 25 deg C.
