1761-L20BWA-5A is a MicroLogix 1000 20 point controller: (12) 24V dc digital inputs, (4) analog inputs, (8) relay outputs and (1) analog output, on a 120/240V ac power supply.
The MicroLogix 1000 line was Rockwell's compact brick controller for small panels, and it is now discontinued. Everything below is taken from the MicroLogix 1000 user manual and the Rockwell product page of this catalog number, so a maintenance engineer can check the points, the power and the replacement route before ordering.
| 1761-L32BWB | MicroLogix 1000 32 point, (20) 24V dc digital inputs, (12) relay outputs | IN STOCK |
| 1761-L32AAA | MicroLogix 1000 32 point, (20) ac inputs, (10) triac and (2) relay outputs | IN STOCK |
| 1761-L16NWB | MicroLogix 1000 16 point, (10) 24V ac or dc digital inputs, (6) relay outputs | IN STOCK |
| 1761-L16BBB | MicroLogix 1000 16 point, (10) 24V dc digital inputs, (4) MOSFET sourcing outputs and (2) relay outputs | IN STOCK |
| 1761-L32BWA | MicroLogix 1000 32 point, (20) 24V dc digital inputs, (12) relay outputs | IN STOCK |
| 1761-L32BBB | MicroLogix 1000 32 point, (20) 24V dc digital inputs, (10) MOSFET sourcing outputs and (2) relay outputs | IN STOCK |
| 1761-L20BWB-5A | MicroLogix 1000 20 point, (12) 24V dc digital inputs, (4) analog inputs, (8) relay outputs and (1) analog output | IN STOCK |
| 1761-L20BWA-5A | MicroLogix 1000 20 point, (12) 24V dc digital inputs, (4) analog inputs, (8) relay outputs and (1) analog output | IN STOCK |
| 1761-L16NWA | MicroLogix 1000 16 point, (10) 24V ac or dc digital inputs, (6) relay outputs | IN STOCK |
| 1761-L16BWB | MicroLogix 1000 16 point, (10) 24V dc digital inputs, (6) relay outputs | IN STOCK |
| 1761-L16BWA | MicroLogix 1000 16 point, (10) 24V dc digital inputs, (6) relay outputs | IN STOCK |
| 1761-L16AWA | MicroLogix 1000 16 point, (10) 120V ac digital inputs, (6) relay outputs | IN STOCK |
| 1761-L10BWB | MicroLogix 1000 10 point, (6) 24V dc digital inputs, (4) relay outputs | IN STOCK |
| 1761-L10BWA | MicroLogix 1000 10 point, (6) 24V dc digital inputs, (4) relay outputs | IN STOCK |
Catalog number |
1761-L20BWA-5A |
Description |
MicroLogix 1000 20 point controller |
I/O |
(12) 24V dc digital inputs, (4) analog inputs, (8) relay outputs and (1) analog output |
Input signal |
24V DC |
Outputs |
8 relay + 1 analog |
Power supply |
120/240V ac power supply |
Memory |
1 KB EEPROM, approximately 737 instruction words |
Communication |
DF1 full duplex, RS-232 (8-pin mini DIN) |
Program memory |
1 KB, retained in EEPROM, no battery |
Enclosure |
IP20, panel or DIN rail |
Operating temperature |
0…55 °C horizontal mounting, 0…45 °C vertical (discrete) |
Storage temperature |
-40…85 °C |
Humidity |
5…95 %, non-condensing |
Vibration |
2.5 g panel mounted, 5…2 kHz |
Shock |
10 g peak, 11 ms |
Lifecycle status |
Discontinued May 18, 2017 |
Replacement category |
Engineering Replacement |
UPC |
Not published |
Publication |
1761-UM003 |
Attribute values above are reproduced from the manufacturer's product data. For the authoritative technical record see Rockwell publications 1761-UM003 (module specifications) and 1761-SG001 (installation instructions). Certification details, with certificate and file numbers, are listed in the FAQ below.
MicroLogix 1000 came in 10, 16, 20 and 32 point bricks. Point count is the first two digits of the catalog suffix, so 1761-L20BWA-5A is a 20 point unit. The point mix is (12) 24V dc digital inputs, (4) analog inputs, (8) relay outputs and (1) analog output.
The 20 point members of the family are the two "-5A" variants, which add four analog inputs and one analog output to the twelve digital inputs and eight relay outputs. That makes them the only MicroLogix 1000 bricks with analog on board, and it is the reason they still command a premium on the secondary market when a machine needs a couple of 4…20 mA signals and nothing more.
Catalog numbers ending in A take a 120/240V ac supply; those ending in B take 24V dc. 1761-L20BWA-5A uses the 120/240V ac power supply. The ac versions accept 85…264V ac at 47…63 Hz, the dc versions 20.4…26.4V dc.
Inputs are 24V DC and outputs are 8 relay + 1 analog. DC inputs on the MicroLogix 1000 can be wired sinking or sourcing by the way the DC COM terminal is connected, which is why the same brick appears in both sinking and sourcing diagrams in the manual.
Relay outputs are dry contacts and will switch either ac or dc loads within the contact rating. Triac outputs on 1761-L32AAA are ac only, and the MOSFET sourcing outputs on 1761-L16BBB and 1761-L32BBB are dc only — they give a faster, longer-lived output for solenoids and indicator lamps but will not pass an ac circuit.
Memory is 1 KB EEPROM, about 737 instruction words with 437 data words. The program lives in EEPROM, so there is no battery to replace and no retention period to track — a detail that matters when a controller has been sitting in a spares cage for years.
Programming is over the RS-232 port with DF1 full duplex. The 1761-CBL-PM02 cable connects the controller to a personal computer; 1761-CBL-HM02 connects it to the hand-held programmer, which is a separate and also discontinued product.
Operating range is 0…55 °C with the brick mounted horizontally, and drops to 45 °C for discrete and 40 °C for analog when mounted vertically. Storage is -40…85 °C, humidity 5…95 % non-condensing, vibration 2.5 g and shock 10 g.
Depth is 73 mm and height 80 mm on the 10 and 16 point bricks; the 32 point units are 200 mm long against 120 or 133 mm for the smaller ones. Add about 13 mm when a 1761-CBL-PM02 or 1761-CBL-HM02 connector is plugged in.
The 24V dc powered variants internally connect the user 24V dc supply to chassis ground. That is worth checking before a brick is dropped into a panel where the sensor supply is already referenced elsewhere.
Rockwell discontinued 1761-L20BWA-5A on May 18, 2017 with an Engineering Replacement as the replacement category. Engineering Replacement means the successor is a different platform, not a drop-in: wiring, terminal numbering and often the program itself have to be reworked.
The functional successor for this class of machine is the Micro800 family, programmed with Connected Components Workbench rather than RSLogix 500. For an existing panel the practical options are a tested spare, a documented migration, or a like-for-like replacement from stock — which is what this listing supplies.
How many I/O points does 1761-L20BWA-5A have?
It is a 20 point controller: (12) 24V dc digital inputs, (4) analog inputs, (8) relay outputs and (1) analog output.
What power supply does 1761-L20BWA-5A need?
The 120/240V ac power supply: 85…264V ac at 47…63 Hz or 20.4…26.4V dc.
How much program memory does 1761-L20BWA-5A have?
1 KB EEPROM, about 737 instruction words and 437 data words. No battery is needed.
Is 1761-L20BWA-5A still available from Rockwell?
No. It was discontinued on May 18, 2017 and the replacement category is Engineering Replacement.
Can 1761-L20BWA-5A inputs be wired sinking or sourcing?
Yes. Any 24V dc input on the MicroLogix 1000 can be either, depending on how DC COM is wired.
